105031-4380 ZEXEL 9 430 615 141 BOSCH NOZZLE-HOLDER ASSEMBLY 9430615141 1050314380

Caterpillar Dealer Suggested Customer Suggested
Parts % Labor Hrs% Parts % Labor Hrs% Parts % Labor Hrs%
100% 100% 0% 0% 0% 0%
This is a 2.0-hour job for Group 3
Dealer to perform most economical repair.
Description________________________SMCS Code__Hours
Wash_______________________________1091-074___.3
Remove and replace DPF brackets____1091-010___1.7
PARTS DISPOSITION
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
MAKE EVERY EFFORT TO COMPLETE THIS PROGRAM AS SOON AS POSSIBLE.
COPY OF OWNER NOTIFICATION FOR U.S. AND CANADIAN OWNERS
XYZ Corporation
3240 Arrow Drive
Anywhere, YZ 99999
IMPORTANT: SAFETY
SAFETY ? RECALL ? REPLACEMENT OF THE DIESEL PARTICULATE FILTER BRACKETS AND STRAPS
MODELS INVOLVED - CERTAIN C7, C9, C13, AND C15 TRUCK ENGINES
Dear Caterpillar Product Owner:
This notice is sent to you in accordance with the requirements of the National Traffic and Motor Vehicle Safety Act. This notice is also in accordance with the requirements of the Canadian Motor Vehicle Safety Act. Caterpillar has decided that a defect which relates to motor vehicle safety exists in 2007, 2008, and 2009 model year trucks equipped with certain Caterpillar C7, C9, C13, and C15 truck engines.
A failure of the Diesel Particulate Filter (DPF) chassis attachment bracket and straps may allow the DPF to separate from the chassis and become a road hazard, which may result in a situation where a vehicle crash could occur. New DPF chassis attachment brackets and straps will be installed on the products listed below. You will not be charged for the service performed.
If you are a lessor of these vehicles, you must forward this letter to your lessee within ten days.
If you have had your vehicle repaired for this condition prior to receipt of this notice and incurred any costs, you may be eligible for reimbursement. Please contact Caterpillar at this toll free number (800) 447-4986.
If you no longer own the truck with this engine, please contact Caterpillar at this toll free number (800) 447-4986.
Contact your local Caterpillar dealer immediately to schedule this service. The dealer will advise you of the time required to complete this service.
If the dealer is unable to have the inspection and repair made, please contact:
Caterpillar Inc.
PO Box 610
Mossville, IL 61552-610
Attn: Engine Products Division
Truck Engine Call Center
Telephone: (800) 447-4986
If you are unable to have the inspection and repair made within 60 days or without charge, you may submit a complaint to:
In the U.S.
Administrator
National Highway Traffic Safety Administration
1200 New Jersey Avenue, S.E.
Washington, D.C. 20590
Telephone: 1-888-327-4236 (TTY:1-800-424-9153)or
go to http://www.safercar.gov
In Canada
Transport Canada
Road Safety and Motor Vehicle Regulation
Ottawa, Ontario KIA 0N5
Telephone: (613) 993-9851
Caterpillar Inc.
Please refer the dealer to their Service Letter dated 05Dec2008 when scheduling this service.
We regret the inconvenience this may cause you, but urge you to have this service performed for your added safety and satisfaction.
Caterpillar Inc.
Identification #(s)
Attached to 05Dec2008 Service Letter
Rework Procedure
1) Wash debris from Diesel Particulate Filter (DPF) and adjacent exhaust piping as necessary.
2) Remove exhaust piping from DPF inlet, DPF outlet, and the CGI port.
3) Disconnect the electrical harness from the DPF sensor box.
4) Place a transmission jack or similar lifting device under the DPF center section.
5) Loosen and remove the DPF chassis attachment bracket straps that are located on the inlet and outlet sections of the DPF. Do
