TERMINATION DATE
30Sep2019
PROBLEM
The existing plastic 469-9108 Diesel Exhaust Fuel (DEF) Injector Cooling Tank can leak on certain 525D, 535D, 545D, and 555D Wheeled Skidders.
AFFECTED PRODUCT
Model Identification Number
525D GKP00416-00465
535D MTP00331-00379
545D KGP00221-00250
555D PGY00143-00150
PARTS NEEDED
Qty
Part Number Description
1 4719926 TANK AS-ALUMINUM
In order to allow equitable parts availability to all participating dealers, please limit your initial parts order to not exceed 7% of dealership population. This is an initial order recommendation only, and the ultimate responsibility for ordering the total number of parts needed to satisfy the program lies with the dealer.
ACTION REQUIRED
If the existing plastic 469-9108 DEF Tank leaks, replace it with the improved 471-9926 Aluminum Tank Assembly. Refer to Image1.
Note: Ensure that all safety information, warnings, and instructions are read and understood before any operation or any maintenance procedures are performed. Refer to the Operation and Maintenance Manual "Safety Section".
Refer to the Service Manual if/as necessary.
SERVICE CLAIM ALLOWANCES
Product smu/age whichever comes first Caterpillar Dealer Suggested Customer Suggested
Parts % Labor Hrs% Parts % Labor Hrs% Parts % Labor Hrs%
0-2000 hrs,
0-24 mo 100.0% 100.0% 0.0% 0.0% 0.0% 0.0%
2001-4000 hrs,
25-36 mo 35.0% 50.0% 0.0% 0.0% 50.0% 50.0%
This is a 0.7-hour job
PARTS DISPOSITION
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
