140254-1100 ZEXEL 9 411 617 455 BOSCH SLOTTED WASHER 9411617455 1402541100 ez40078xx052




Information slotted washer

BOSCH 9 411 617 455 9411617455
ZEXEL 140254-1100 1402541100
M.BISHI-HI.-NAG EZ40078XX052 ez40078xx052
140254-1100 SLOTTED WASHER
Rating:
43
Buy SLOTTED WASHER 140254-1100 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

Zexel num
Bosch num
Firm num
Name
140254-1100
9 411 617 455
EZ40078XX052  M.BISHI-HI.-NAG
SLOTTED WASHER
C 24XX SPRING SEAT PF parts PF
140254-1100
9 411 617 455
EZ40045XX052  M.BISHI-HI.-NAG
SLOTTED WASHER
A C 24XX SPRING SEAT PF parts PF




Information:

(1) Bore in connecting rod for piston pin bearing ... 55.436 0.013 mm (2.1825 .0005 in.)Tight fit between connecting rod eye and piston pin bearing ... 0.05 to 0.10 mm (.002 to .004 in.) Connecting rod must be heated for installation of piston pin bearing. Do not use a torch.Heat connecting rod for piston pin bearing installation to a temperature of ... 177 to 260° C (350 to 500° F)Position of pin bearing:
Positioning Pin Bearing (Type A)Type A (Narrow Taper) - Bearing junction and locating hole are 180° apart (directly across from each other). Bearing junction and locating hole must be assembled within either area "A" (90 10° from centerline through the connecting rod bores) as shown.
Positioning Pin Bearing (Type B)Type B (Wide Taper) - Bearing junction and locating hole are 155° apart (not directly across from each other). Bearing junction and locating holes must be assembled in the top half of connecting rod eye area "A" (12.5 1° above the horizontal centerline) as shown.Make reference to Special Instruction Form No. SMHS7295 for use of pin bearing removal and installation tools and procedures.(2) Bore in connecting rod for bearing with nuts tight to specifications (6) ... 103.500 0.013 mm (4.0748 .0005 in.)(3) Distance between center of bearings ... 261.62 0.05 mm (10.300 .002 in.)(4) Bore in bearing for piston pin (new) ... 50.830 0.008 mm (2.0012 .0003 in.)Diameter of piston pin (new) ... 50.795 0.005 mm (1.9998 .0002 in.)Maximum permissible clearance between bearing and piston pin (worn) ... 0.08 mm (.003 in.)(5) Bore in bearing for crankshaft ... 97.119 to 97.175 mm (3.8236 to 3.8258 in.)Clearance between bearing and crankshaft (new) ... 0.071 to 0.168 mm (.0028 to .0066 in.)Maximum permissible clearance between bearing and crankshaft (worn) ... 0.25 mm (.010 in.) Bearings are available in 0.63 mm (.025 in.) and 1.27 mm (.050 in.) smaller than original size.
Marks For Tightening Connecting Rod Bolts(6) Tightening procedure for connecting rod bolts:a. Put 2P2506 Thread Lubricant on bolt threads and contact surfaces of nut and cap.b. Tighten both nuts to ... 80 8 N m (60 6 lb.ft.)c. Put a mark on each nut and end of bolt as shown.d. Tighten each nut from mark ... 120 5° The connecting rod must be installed so the chamfer on the edge of bore (5) is near the corner on the crankshaft. The side opposite the chamfered edge must be against the other connecting rod on the same crankshaft pin.Side clearance between two connecting rods on the same crankshaft pin (new) ... 0.28 to 0.84 mm (.011 to .033 in.)Make reference to Special Instruction Form Nos. GMG02394 & SMHS7366 for information to check and recondition connecting rods. Also see, Guideline For Reusable Parts; Salvage Of Non-Serrated Connecting Rods, Form No. SEBF8064.

Have questions with 140254-1100?





Group cross 140254-1100 ZEXEL

M.Bishi-Hi.-Nag

140254-1100
9 411 617 455
EZ40078XX052
SLOTTED WASHER
140254-1100
9 411 617 455
EZ40045XX052
SLOTTED WASHER
