PARTS NEEDED
Qty
Part Number Description
2 1W6917 ADAPTER
38 3V3308 WASHER-HARD
4 6V1454 SEAL-O RING
2 6V3908 SEAL-O-RING
3 6V5049 SEAL-O-RING
1 6V5063 SEAL-O-RING
1 7E3101 HOUSING-AFTCLR
1 7E3103 SEAL
2 7H4412 SPACER
2 7X0791 BOLT
1 9S4183 PLUG-O-RING
3 9S4191 PLUG-STOR
38 0310219 BOLT-SELF LCK
2 1236256 ADAPTER
1 2995625 CORE AS-AFTCLR
ACTION REQUIRED
Using either the Service Manual module RENR2287-02 (3608 Aftercooler Remove & Install), or SENR4259-09 (3606 and 3608 Aftercooler Install)as your guide, Remove the failed aftercooler from the 3606 or 3608 diesel marine engine.
Install the new 299-5625 core as. aftercooler, 7E3103 aftercooler flange seal, and the 7E3101 housing using the hardware and seals given in the parts list.
SERVICE CLAIM ALLOWANCES
Product smu/age whichever comes first Caterpillar Dealer Suggested Customer Suggested
Parts % Labor Hrs% Parts % Labor Hrs% Parts % Labor Hrs%
0-10000 hrs,
0-48 mo 100.0% 100.0% 0.0% 0.0% 0.0% 0.0%
10001-20000 hrs,
49-60 mo 50.0% 50.0% 0.0% 0.0% 50.0% 50.0%
This is a 16.0-hour job
PARTS DISPOSITION
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
