Illustration 1 g00293000
Junction Box-ETR Switchgear Required (OP, WT, OS)
(1) Electronic speed switch ("ESS").
(2) Lockwire (for seal screw plugs).
(3) Identification foil.
(4) Diode ("D4").
(5) Diode ("D3").
(6) Slave relay ("SR1").
(7) Slave relay ("SR2").
(8) Emergency stop switch ("ES").
(9) Circuit breakers.
Illustration 2 g00293001
Junction Box-ETS Switchgear Not Required (OP, WT, OS)
(1) Electronic speed switch ("ESS").
(2) Lockwire (for seal screw plugs).
(3) Identification foil.
(4) Slave relay ("SR1").
(5) Emergency stop switch ("ES").
(6) Time delay relay ("TD1").
(7) Start-stop switch ("SSS").
Illustration 3 g00293002
Junction Box-ETS Switchgear Required (OP, WT, OS)
(1) Electronic speed switch ("ESS").
(2) Lockwire (for seal screw plugs).
(3) Slave relay ("SR1").
(4) Emergency stop switch ("ES").
(5) Time delay relay ("TD1").
(6) Circuit breakers.
(7) Engine mounted start-stop switch ("EMSS."
Illustration 4 g00293003
Junction Box-ETS Switchgear Not Required (OP, WT)
(1) Time delay relay ("TD2").
(2) Emergency stop switch ("ES").
(3) Identification foil.
(4) Slave relay ("SR1").
(5) Slave relay ("SR2").
(6) Time delay relay ("TD1").
(7) Circuit breakers.
Illustration 5 g00293004
Junction Box With Start-stop Switch ("SSS")
(1) Emergency stop switch ("ES").
(2) Circuit breaker reset buttons.
(3) Start-stop switch ("SSS").
Illustration 6 g00293005
(1) Power distribution box. (2) Circuit breaker reset button.
Illustration 7 g00293006
(1) Hour meter.
Illustration 8 g00293007
(1) Air starting motor. (2) Air starting valve. (3) Air supply pipe.
