131154-6620 ZEXEL 9 413 614 476 BOSCH PLUNGER-AND-BARREL ASSY 9413614476 1311546620 16760z9307




Information plunger-and-barrel assy

BOSCH 9 413 614 476 9413614476
ZEXEL 131154-6620 1311546620
NISSAN-DIESEL 16760Z9307 16760z9307
131154-6620 PLUNGER-AND-BARREL ASSY
Rating:
29
Buy PLUNGER-AND-BARREL ASSY 131154-6620 zexel genuine, new aftermarket engine parts with delivery

Include in ###:

Number on scheme 30
PLUNGER-AND-BARREL ASSY
1010494091 as PLUNGER-AND-BARREL ASSY

Cross reference number

Zexel num
Bosch num
Firm num
Name
131154-6620
9 413 614 476
16760Z9307  NISSAN-DIESEL
PLUNGER-AND-BARREL ASSY
C 14EL PLUNGER ASSY PL(A) PL




Information:

1. Disconnect fuel line (3) from the fuel transfer pump. Cap or plug immediately.2. Disconnect fuel line (4) from the fuel transfer pump. Cap or plug immediately.3. Remove bolts (1).4. Remove fuel transfer pump (2). Check the condition of the O-ring seal on the fuel transfer pump. If necessary, make a replacement. Put clean engine oil on the O-ring seal when assembling fuel transfer pump. For installation of the fuel transfer pump, reverse the removal steps.Disassemble & Assemble Fuel Transfer Pump
Start By:a. remove fuel transfer pump 1. Remove seal (1) from the fuel transfer pump.
Cover (2) is under spring tension. Remove the bolts that hold cover (2) slowly to prevent injury.
2. Remove bolts (3) and cover (2) the housing. 3. Remove seals (4) and valve (5) from cover (2). 4. Remove spring (6) from the piston.
Mark the orientation of valve (8) as to its location in the housing.
5. Remove washer (7) and valve (8) from the housing. 6. Remove piston (9) and sleeve (10) from the housing. 7. Remove seal (11) from sleeve (12). 8. Remove guide and tappet assembly (13) from the housing. 9. Remove seal (14) from guide (15).
If tappet (17) or guide (15) are damaged or worn, they must be replaced as a unit.
10. Remove ring (16) from tappet (17) and the tappet from guide (15). 11. Remove the bolts and cover (18) from the housing. 12. Remove seal (19) from cover (18). 13. Remove valve (20) from the housing. The following steps are for the assembly of the fuel transfer pump.14. Install valve (20) in the housing. Put clean fuel on seal (19) and install it on cover (18). Install the cover on the housing.15. Install tappet (17) in guide (15). Install ring (16) on tappet (17) to hold the tappet in the guide.16. Put clean fuel on seal (14) and install it on the guide and tappet assembly (13). Install guide and tappet assembly (13) in the housing.17. Put clean fuel on seal (11) and install it on sleeve (12). Install sleeve (12) in the housing.18. Install piston (9) in the housing. Install valve (8) and washer (7) in the housing. Install spring (6) in the piston.19. Install valve (5) in cover (2).20. Put clean fuel on seals (4) and put them in position on cover (2). Install cover (2) on the housing.21. Put seal (1) in position on the fuel transfer pump.End By:a. install fuel transfer pump

Have questions with 131154-6620?





Group cross 131154-6620 ZEXEL

Nissan-Diesel

131154-6620
9 413 614 476
16760Z9307
PLUNGER-AND-BARREL ASSY
