152350-3320 ZEXEL 9 441 610 347 BOSCH PIPE 9441610347 1523503320

Illustration 1 g03206556
(1) Location of protective sleeveAdaptable To: The new unit injector wiring group replaces the existing wiring group on the serial numbers listed above. Refer to Table 1 for a list of the new part numbers and the part numbers that are being replaced.
Table 1
New Part Number Former Part Number
399-4012 353-5939
399-4009 353-6013 That table below contains the mounting hardware that is needed with the injector harness change to maintain valve cover clearance.
Table 2
Qty Part Number Part Name
5 282-3736 Stud
1 6V-5843 Bolt This new injector wiring harness is effective for the engine serial numbers listed in Table 3.
Table 3
Effective Serial Numbers
S/N:C9N1275-UP
S/N:D9N1-UP
