159252-0521 ZEXEL 9 421 613 225 BOSCH LEVER GROUP 9421613225 1592520521 1157255260

(1) Tension of brush spring ... 80 to 90 oz.(2.27 to 2.55 kg)(2) Torque for bolts ... 8 lb. ft.(1.11 mkg)(3) Torque for terminal nuts ... 20 to 25 lb. ft.(2.8 to 3.5 mkg)(4) Clearance for the pinion ... .020 to .050 in.(0.51 to 1.27 mm)2P6162 24V (Prestolite Number MES 6301 K) 3P110 24V (Prestolite Number MFY 6401 I)
Rotation is clockwise when seen from drive end.Minimum speed with no load ... 5000 rpmCurrent consumption (draw) with no load: Maximum at 20 V ... 77 A(1) Tension of brush spring ... 80 to 90 oz.(2.27 to 2.55 kg)(2) Torque for housing bolts ... 8 lb. ft.(1.11 mkg)(3) Torque for terminal nuts ... 20 to 25 lb. ft.(2.8 to 3.5 mkg)(4) Clearance between pinion and housing (pinion clearance) ... .020 to .050 in.(0.51 to 1.27 mm)2P2502 24V (Delco-Remy Number 1113393)
Rotation is clockwise when seen from drive end. Minimum speed with no load ... 5500 rpmMaximum speed with no load ... 7500 rpmCurrent consumption (draw) at no load: Minimum with solenoid at 20 V ... 92.5 AMaximum with solenoid at 20 V ... 120.1 AClearance between pinion and housing (pinion clearance) ... .36 in.(9.1 mm) (1) Tension of brush spring* ... 36 to 40 oz.(1.01 to 1.14 kg)(2) Torque for terminal nuts ... 20 to 25 lb. ft.(2.8 to 3.5 mkg) ... 80 oz.(2.27 kg)*Minimum for leaf springs 4N3182 24V (Delco-Remy Number 1114711)
Rotation is clockwise when seen from drive end.Minimum speed with no load ... 5500 rpmMaximum speed with no load ... 7500 rpmCurrent consumption (draw) at no load: Minimum with solenoid at 20V ... 108.5 AMaximum with solenoid at 20V ... 135.1 AClearance between pinion and housing (pinion clearance) ... .36 in.(9.1 mm) (1) Tension of brush spring ... 80 oz.(2.26 kg)(2) Torque for screws holding nose housing to lever housing ... 13 to 17 lb. ft.(1.8 to 2.4 mkg)(3) Torque for terminal nuts ... 20 to 25 lb. ft.(2.8 to 3.5 mkg)
