155616-3020 ZEXEL 9 481 610 005 BOSCH JOINT CONNECTION 9481610005 1556163020 9813151900

See FLYWHEEL RUNOUT for the correct method of flywheel inspection.(1) Maximum permissible temperature of the gear for installation on the flywheel (do not use a torch) ... 315°C (600°F)(2) Put 2P2506 Thread Lubricant on all bolt threads that hold flywheel to crankshaft and tighten to a torque of ... 270 25 N m (200 20 lb. ft.)(3) Diameter of bushing ... 69.723 0.013 mm (2.7450 .0005 in.) Bore in flywheel ... 69.875 0.013 mm (2.7510 .0005 in.)Maximum permissible temperature of the bushing for installation on torque converter hub ... 315°C (600°F) See Special Instruction, Form No. SMHS6942 for the complete procedure for installation of the 6N9829 Flywheel Adapter Group.6N1299 Flywheel Group for use with SAE No. 1 Flywheel Housing and Clark No. 14, 15 or 16 Twin Disc Torque Converter Without Clutch.
See FLYWHEEL RUNOUT for the correct method of flywheel inspection. Use the specifications for flywheels without BrakeSaver.(1) Put 2P2506 Thread Lubricant on all bolt threads that hold flywheel to crankshaft and tighten to a torque of ... 270 25 N m (200 20 lb. ft.)(2) Maximum permissible temperature of the gear for installation on the flywheel (do not use a torch) ... 315°C (600°F)9N2518 and 4W7370 Flywheel Group for use with SAE No. 1 Flywheel Housing and Clark C and CL8000 Series Torque Converter. Can not be used with BrakeSaver.
See FLYWHEEL RUNOUT for the correct method of flywheel inspection. Use Specifications for flywheels without BrakeSaver.(1) Maximum permissible temperature of the gear for installation on the flywheel (do not use a torch) ... 315°C (600°F)(2) Put 2P2506 Thread Lubricant on all bolt threads that hold flywheel to crankshaft and tighten to a torque of ... 270 25 N (200 20 lb. ft.)(3) Bore in bushing ... 52.007 0.013 mm (2.0475 .0005 in.)(4) Diameter of bushing ... 72.022 0.015 mm (2.8355 .0006 in.) Bore in flywheel ... 71.971 0.015 mm (2.8335 .0006 in.)
