107750-0190 ZEXEL 9 443 614 098 BOSCH INJECTOR 9443614098 1077500190 2367033020b0

1. Remove cylinder head bolts (1) and (2).
When lifting cylinder head, care must be taken to keep cylinder head level to prevent damage to the two cylinder head-to-spacer block dowels.
2. Lift the cylinder head off the spacer block. The approximate weight of the cylinder head is 236 Kg (520 Lbs.). The following steps are for the installation of the cylinder head.3. Thoroughly clean cylinder head and spacer block surfaces.4. Position the head gasket and the cylinder head onto the dowels in the spacer block. Lower the cylinder head onto the spacer block.5. Put engine oil on the threads of bolts (1) and (2), then install bolts. Tighten bolts (1) and (2) as follows:
Cylinder Head Tightening Sequencea. Tighten bolts 1 thru 26 in number sequence shown to a torque of 150 15 N m (110 11 lb.ft.).b. Tighten bolts 1 thru 26 in number sequence shown to a torque of 275 15 N m (200 11 lb.ft.).c. Retorque bolts 1 thru 26 in number sequence shown to 275 15 N m (200 11 lb.ft.).d. Tighten bolts 27 thru 33 in number sequence shown, to a torque of 34 7 N m (25 5 lb.ft.).End By:a. install valve cover baseb. install (ECU) fuel injectorsc. install rocker arm assemblies and push rodsd. adjust all the valve rocker arm clearances.e. install water outlet manifoldf. install exhaust manifold
