106871-7860 ZEXEL INJECTION-PUMP ASSEMBLY Cross 1068717860

Information injection-pump assembly

ZEXEL 106871-7860 1068717860

Price: query

Buy now
Add to cart Go to cart

Rating:

Buy INJECTION-PUMP ASSEMBLY 106871-7860 zexel genuine, new aftermarket engine parts with delivery

Service parts 106871-7860 INJECTION-PUMP ASSEMBLY:

1. _

2. FUEL INJECTION PUMP 106087-7420

3. GOVERNOR 105487-3380

4. SUPPLY PUMP 105207-1140

5. AUTOM. ADVANCE MECHANIS 105636-1660

6. COUPLING PLATE 105663-0260

7. COUPLING PLATE

8. _

9. _

10. NOZZLE AND HOLDER ASSY 105100-5570

11. Nozzle and Holder

12. Open Pre:MPa(Kqf/cm2) 17.7(180)/21.6(220)

13. NOZZLE-HOLDER 105031-4500

14. NOZZLE

105015-5070

15. NOZZLE SET

Include in #1:

106871-7860 as INJECTION-PUMP ASSEMBLY

Cross reference number

Zexel num

Bosch num

Firm num

Name

106871-7860

INJECTION-PUMP ASSEMBLY

Information:

Camshaft rotation counterclockwise in view shown.Firing order (injection sequence) ... 1, 5, 3, 6, 2, 4Injection timing before TC (top center):Precombustion Chamber (PC) ... 10 1°*Direct Injection (DI) ... 29 1°*Direct Injection (DI) ... 28 1°*Direct Injection (DI) ... 26.5 1°*Direct Injection (DI) ... 22.5 1°*Make reference to DI FUEL SYSTEM CHART in FUEL SYSTEM IDENTIFICATION section to find correct injection pump groups.(1) Torque for bushing ... 150 10 lb. ft.(205 14 N m)
A - 8S7167 GAUGE
B - 5P4158 GAUGE (5) Bore for the rack and diameter of the rack: Bearing at the rear (new) ... .5018 .0018 in.(12.746 0.046 mm)Bearing at the front (new) ... .5023 .0018 in.(12.758 0.046 mm)Diameter of fuel rack (new) ... .4985 .0002 in.(12.662 0.005 mm)Maximum permissible clearance between rack and bearings (worn) ... .007 in.(0.18 mm)(6) Bore in bearings for the camshaft (new) ... 2.1255 .0015 in.(53.988 0.038 mm) Diameter of bearing surfaces of the camshaft (new) ... 2.1220 .0005 in.(53.899 0.013 mm)Maximum permissible clearance between the bearings and the camshaft ... .010 in.(0.25 mm)
PRECHAMBER(9) Torque for all nuts that hold the fuel lines ... 30 5 lb. ft.(40 7 N m)(10) Torque for the nuts that hold the nozzles ... 55 5 lb. ft.(75 7 N m)(11) Body.
DIRECT INJECTION(12) Nozzle. Tighten nozzle finger tight on body (11).(13) Torque for precombustion chamber or direct injection adapter ... 150 10 lb. ft.(205 14 N m)(14) Torque for glow plug ... 120 24 lb. in.(13.6 2.8 N m)
