104780-9790 ZEXEL 9 460 614 799 BOSCH INJECTION-PUMP ASSEMBLY 9460614799 1047809790 1670063g71




Information injection-pump assembly

BOSCH 9 460 614 799 9460614799
ZEXEL 104780-9790 1047809790
NISSAN-DIESEL 1670063G71 1670063g71
104780-9790 INJECTION-PUMP ASSEMBLY
Rating:
70
Buy INJECTION-PUMP ASSEMBLY 104780-9790 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

BOSCH 9 460 614 799 9460614799
ZEXEL 104780-9790 1047809790
NISSAN-DIESEL 1670063G71 1670063g71


Zexel num
Bosch num
Firm num
Name
104780-9790
9 460 614 799
1670063G71  NISSAN-DIESEL
INJECTION-PUMP ASSEMBLY
TD27 K

Calibration Data:

Adjustment conditions
Test oil
1404 Test oil   ISO4113orSAEJ967d
Test oil temperature degC   45 45 50
Nozzle   105780-0060
Bosch type code   NP-DN0SD1510
Nozzle holder   105780-2150
Opening pressure MPa   13 13 13.3
Opening pressure kgf/cm2   133 133 136
Injection pipe   157805-7320
Injection pipe
Inside diameter - outside diameter - length (mm) mm   2-6-450
Joint assembly   157641-4720
Tube assembly   157641-4020
Transfer pump pressure kPa   20 20 20
Transfer pump pressure kgf/cm2   0.2 0.2 0.2
Direction of rotation (viewed from drive side)
Right   R
Injection timing adjustment
Pump speed r/min   1100 1100 1100
Average injection quantity mm3/st.   48.5 48 49
Difference in delivery mm3/st.   4
Basic   *
Oil temperature degC   50 48 52
Injection timing adjustment_02
Pump speed r/min   500 500 500
Average injection quantity mm3/st.   40.3 37.8 42.8
Oil temperature degC   48 46 50
Injection timing adjustment_03
Pump speed r/min   1100 1100 1100
Average injection quantity mm3/st.   48.5 47.5 49.5
Difference in delivery mm3/st.   4.5
Basic   *
Oil temperature degC   50 48 52
Injection timing adjustment_04
Pump speed r/min   2150 2150 2150
Average injection quantity mm3/st.   47 44 50
Oil temperature degC   52 50 54
Injection quantity adjustment
Pump speed r/min   2550 2550 2550
Average injection quantity mm3/st.   10.9 8.9 12.9
Difference in delivery mm3/st.   3
Basic   *
Oil temperature degC   55 52 58
Injection quantity adjustment_02
Pump speed r/min   2700 2700 2700
Average injection quantity mm3/st.   5
Oil temperature degC   55 52 58
Injection quantity adjustment_03
Pump speed r/min   2350 2350 2350
Average injection quantity mm3/st.   38.5 34 43
Oil temperature degC   52 50 54
Injection quantity adjustment_04
Pump speed r/min   2550 2550 2550
Average injection quantity mm3/st.   10.9 8.4 13.4
Difference in delivery mm3/st.   3.5
Basic   *
Oil temperature degC   55 52 58
Governor adjustment
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   7.4 5.4 9.4
Difference in delivery mm3/st.   2
Basic   *
Oil temperature degC   48 46 50
Governor adjustment_02
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   7.4 4.9 9.9
Difference in delivery mm3/st.   2.5
Basic   *
Oil temperature degC   48 46 50
Timer adjustment
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   60 45 80
Basic   *
Oil temperature degC   48 46 50
Remarks
Full
Timer adjustment_02
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   60 45 80
Oil temperature degC   48 46 50
Remarks
Full
Speed control lever angle
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   0 0 0
Oil temperature degC   48 46 50
Remarks
Magnet OFF at idling position
0000000901
Pump speed r/min   1100 1100 1100
Overflow quantity cm3/min   390 260 520
Oil temperature degC   50 48 52
Stop lever angle
Pump speed r/min   1100 1100 1100
Pressure kPa   432 403 461
Pressure kgf/cm2   4.4 4.1 4.7
Basic   *
Oil temperature degC   50 48 52
Stop lever angle_02
Pump speed r/min   1100 1100 1100
Pressure kPa   432 393 471
Pressure kgf/cm2   4.4 4 4.8
Basic   *
Oil temperature degC   50 48 52
Stop lever angle_03
Pump speed r/min   1700 1700 1700
Pressure kPa   559 520 598
Pressure kgf/cm2   5.7 5.3 6.1
Oil temperature degC   50 48 52
0000001101
Pump speed r/min   1100 1100 1100
Timer stroke mm   1.9 1.7 2.1
Basic   *
Oil temperature degC   50 48 52
_02
Pump speed r/min   850 850 850
Timer stroke mm   0.8 0.2 1.4
Oil temperature degC   50 48 52
_03
Pump speed r/min   1100 1100 1100
Timer stroke mm   1.9 1.6 2.2
Basic   *
Oil temperature degC   50 48 52
_04
Pump speed r/min   1700 1700 1700
Timer stroke mm   4.4 3.9 4.9
Oil temperature degC   50 48 52
_05
Pump speed r/min   2300 2300 2300
Timer stroke mm   6.1 5.6 6.5
Oil temperature degC   52 50 54
0000001201
Max. applied voltage V   8 8 8
Test voltage V   13 12 14
0000001501
Pump speed r/min   1100 1100 1100
Height m   2000 2000 2000
Atmospheric pressure difference kPa   -21.9 -21.9 -21.9
Atmospheric pressure difference mmHg   -164 -164 -164
Average injection quantity mm3/st.   39.5 38 41
Decrease qty mm3/st.   9 9 9
Decrease rate %   19 19 19
Basic   *
Oil temperature degC   50 48 52
_02
Pump speed r/min   1100 1100 1100
Height m   0 0 0
Atmospheric pressure difference kPa   0 0 0
Atmospheric pressure difference mmHg   0 0 0
Average injection quantity mm3/st.   48.5 47.5 49.5
Oil temperature degC   50 48 52
_03
Pump speed r/min   1100 1100 1100
Height m   500 500 500
Atmospheric pressure difference kPa   -5.9 -9.2 -2.6
Atmospheric pressure difference mmHg   -44 -69 -19
Average injection quantity mm3/st.   48.5 48.5 48.5
Oil temperature degC   50 48 52
_04
Pump speed r/min   1100 1100 1100
Height m   2000 2000 2000
Atmospheric pressure difference kPa   -21.9 -21.9 -21.9
Atmospheric pressure difference mmHg   -164 -164 -164
Average injection quantity mm3/st.   39.5 37.5 41.5
Basic   *
Oil temperature degC   50 48 52
_05
Pump speed r/min   1100 1100 1100
Height m   4000 4000 4000
Atmospheric pressure difference kPa   -29.7 -29.7 -29.7
Atmospheric pressure difference mmHg   -298 -298 -298
Average injection quantity mm3/st.   29 29 29
Oil temperature degC   50 48 52
Timing setting
K dimension mm   3.3 3.2 3.4
KF dimension mm   5.8 5.7 5.9
MS dimension mm   0.9 0.8 1
Pre-stroke mm   0.1 0.08 0.12
Control lever angle alpha deg.   55.5 51.5 59.5
Control lever angle beta deg.   36 31 41




Information:

Cat ELC
Caterpillar provides Cat ELC (Extended Life Coolant) for use in the following applications:
Heavy-duty diesel engines
Automotive applicationsWhen Cat ELC is compared to conventional coolants, the Cat ELC anti-corrosion package is based on a different additive system. Cat ELC has been formulated with the correct amounts of additives. Superior corrosion protection is provided for all metals that are in engine cooling systems.Cat ELC extends the service life of the coolant to 12000 service hours or 6 years. Cat ELC does not require the frequent addition of the Cat ELC Extender additive. An Extender is the only additional maintenance that is needed at 6000 service hours or one half of the Cat ELC service life.Cat ELC is available in a 1:1 premixed cooling solution with distilled water. The premixed Cat ELC provides freeze protection to −37 °C (−34 °F). The premixed Cat ELC is recommended for the initial fill of the cooling system. The premixed Cat ELC is also recommended for topping off the cooling system.Cat ELC Concentrate is also available. Cat ELC Concentrate can be used to lower the freezing point to −52 °C (−62 °F) for arctic conditions.Containers of several sizes are available. Refer to this Special Publication, "Coolant Recommendations" article for available quantities and part numbers.Note: Cat ELC can be used in most diesel and gasoline OEM engines. Cat ELC meets
