  3. #1047624010

Buy 104762-4010 ZEXEL 9 460 611 576 BOSCH INJECTION-PUMP ASSEMBLY 9460611576 1047624010 6734711240




Information injection-pump assembly

BOSCH 9 460 611 576 9460611576
ZEXEL 104762-4010 1047624010
KOMATSU 6734711240 6734711240
104762-4010 INJECTION-PUMP ASSEMBLY
Rating:
8
Buy INJECTION-PUMP ASSEMBLY 104762-4010 zexel genuine, new aftermarket engine parts with delivery

Compare Prices: .

As an associate, we earn commssions on qualifying purchases through the links below
VE Fuel Injection Pump NP-VE6/12F1125RNP170 6734711240 104662-4010，Compatible With KOMATSU 6D102E
$1,033.62

17 Mar 2025
0.1102[0.05] Pounds
CN: JIARUIQIPEIDIAN
VE Fuel Injection Pump NP-VE6/12F1125RNP170 6734711240 104662-4010，Compatible With KOMATSU 6D102E
IUVPTAF The performance of high-pressure fuel pumps is strong, reflected in efficient atomization, rapid response, and precise fuel supply || Stable pressure, one-way valve and buffer at the oil outlet to prevent fuel backflow and reduce oil pressure pulse || Equipped with safety valves and pressure limiters to achieve multiple protections. Can work stably in complex environments || Integrated design, energy-saving and environmentally friendly, reduces fuel consumption, and the fuel pump also achieves intelligent control || VE Fuel Injection Pump NP-VE6/12F1125RNP170 6734711240 104662-4010，Compatible With KOMATSU 6D102E
WZCNLXLX Fuel Injection Pump 6734-71-1240 6734711240 For Komatsu 6D102E-1 Engine
$675.55

17 Mar 2025

CN: LONGXUN
WZCNLXLX Fuel Injection Pump 6734-71-1240 6734711240 For Komatsu 6D102E-1 Engine
WZCNLXLX Item Name:Fuel Injection Pump || Item Number:6734-71-1240, 6734711240, 9460611576 || Application:For Komatsu Engine:6D102E-1, 6D102E-1F-D1 || Note: If you are unsure if the product is suitable.In order not to delay your use of the parts, please provide your engine nameplate or serial number and part number, and we will help you confirm if it is suitable. To avoid unnecessary returns, please check the product image and part number to ensure it is the product you want. || Tip: Please contact us - we are a professional sales team and we have many products to offer to you. Many buyers are very satisfied with our service. You can get first-class products and high-quality services from us, believe me, you will have a pleasant shopping experience here.
YIHETOP Fuel Injection Pump 6734-71-1240 6734711240 Compatible For Komatsu 6D102E-1 6D102E-1F-D1 Engine
$699.00

03 Jan 2025

CN: YIHETOP
YIHETOP Fuel Injection Pump 6734-71-1240 6734711240 Compatible For Komatsu 6D102E-1 6D102E-1F-D1 Engine
YIHETOP Part Number:6734-71-1240, 6734711240, 9460611576 || Compatible For Komatsu Engine:6D102E-1, 6D102E-1F-D1

Components :

0. INJECTION-PUMP ASSEMBLY 104762-4010
1. _
2. FUEL INJECTION PUMP 104662-4010
3. NUMBER PLATE 146972-9800
4. _
5. CAPSULE
6. ADJUSTING DEVICE
7. NOZZLE AND HOLDER ASSY
8. Nozzle and Holder
9. Open Pre:MPa(Kqf/cm2) 19.6{200}
10. NOZZLE-HOLDER
11. NOZZLE

Scheme ###:

PACKING RING
1/6. [1] 146601-1100 PACKING RING
6. [1] 146100-0120 SUPPLY PUMP
9. [1] 146103-0000 COVER
10. [2] 139104-0000 FLAT-HEAD SCREW
12. [1] 146200-1820 DRIVE SHAFT
12/1. [1] 146200-1800 DRIVE SHAFT
12/2. [1] 146201-0000 WOODRUFF KEY
12/3. [2] 146202-0100 DAMPER
12/4. [1] 146203-0000 TOOTHED GEAR
17. [1] 146204-0000 PLAIN WASHER
20. [1] 146210-0020 ROLLER SET
24. [1] 146303-0000 BEARING PIN
25. [1] 146304-0000 BEARING PIN
26. [1] 146305-0000 CLAMPING BAND
27. [1] 146205-0100 SLOTTED WASHER
29. [1] 146221-1820 CAM PLATE
30. [1] 146600-0800 O-RING
31. [1] 146300-4300 PUMP PLUNGER
32. [1] 146301-0000 SLIDING PIECE
33. [1] 146603-0700 SHIM D17.5&7.5T0.60
34. [1] 146302-2600 COMPRESSION SPRING K=2.05KG/MM
34B. [1] 146302-1800 COMPRESSION SPRING K=2.25KG/MM
34C. [1] 146302-8100 COMPRESSION SPRING
34D. [1] 146306-2000 COMPRESSION SPRING
35/1. [0] 146603-0700 SHIM D17.5&7.5T0.60
35/1. [0] 146603-0800 SHIM D17.5&7.5T0.70
35/1. [0] 146603-0900 SHIM D17.5&7.5T0.90
35/1. [0] 146603-1000 SHIM D17.5&7.5T1.00
35/1. [0] 146603-1100 SHIM D17.5&7.5T1.20
35/1. [0] 146603-3600 SHIM D17.5&7.5T2.40
36. [1] 146600-0800 O-RING
37. [1] 146310-0700 COVER
38. [2] 146620-5000 BLEEDER SCREW
39. [1] 146310-5100 COVER
40. [2] 146620-5000 BLEEDER SCREW
43. [1] 146230-0000 SHIM
44. [1] 146230-0100 PLAIN WASHER
45. [1] 146231-0001 SLOTTED WASHER
47. [2] 146233-0000 SLOTTED WASHER
48/1. [1] 146603-0000 SHIM D17.0&5.2T0.50
48/1. [1] 146603-0100 SHIM D17.0&5.2T0.80
48/1. [1] 146603-0200 SHIM D17.0&5.2T1.00
48/1. [1] 146603-0300 SHIM D17.0&5.2T1.20
48/1. [1] 146603-0400 SHIM D17.0&5.2T1.50
48/1. [1] 146603-0500 SHIM D17.0&5.2T1.80
48/1. [1] 146603-0600 SHIM D17.0&5.2T2.00
48/1. [1] 146690-1400 SHIM D17&5.2T0.9
48/1. [1] 146690-1500 SHIM D17&5.2T1.1
48/1. [1] 146690-1600 SHIM D17&5.2T1.3
48/1. [1] 146690-1700 SHIM D17&5.2T1.4
48/1. [1] 146690-1800 SHIM D17&5.2T1.6
48/1. [1] 146690-1900 SHIM D17&5.2T1.7
48/1. [1] 146690-5800 SHIM
48/1. [1] 146690-5900 SHIM
48/1. [1] 146690-6000 SHIM
48/1. [1] 146690-6100 SHIM
48/1. [1] 146690-6200 SHIM
48/1. [1] 146690-6300 SHIM
48/1. [1] 146690-6400 SHIM
48/1. [1] 146690-6500 SHIM
48/1. [1] 146690-6600 SHIM
48/1. [1] 146690-6700 SHIM
48/1. [1] 146690-6800 SHIM
48/1. [1] 146690-6900 SHIM
48/1. [1] 146690-7000 SHIM
48/1. [1] 146690-7100 SHIM
48/1. [1] 146690-7200 SHIM
48/1. [1] 146690-7300 SHIM
48/1. [1] 146690-7400 SHIM
48/1. [1] 146690-7500 SHIM
48/1. [1] 146690-7800 SHIM
49. [2] 146234-0600 GUIDE PIN
50. [1] 146406-0820 HYDRAULIC HEAD
50. [1] 146406-0820 HYDRAULIC HEAD
50. [1] 146406-0820 HYDRAULIC HEAD
51. [1] 146600-0000 O-RING
52/1. [1] 146420-0000 SHIM D9.5&3.0T1.90
52/1. [1] 146420-0100 SHIM D9.5&3.0T1.92
52/1. [1] 146420-0200 SHIM D9.5&3.0T1.94
52/1. [1] 146420-0300 SHIM D9.5&3.0T1.96
52/1. [1] 146420-0400 SHIM D9.5&3.0T1.98
52/1. [1] 146420-0500 SHIM D9.5&3.0T2.00
52/1. [1] 146420-0600 SHIM D9.5&3.0T2.02
52/1. [1] 146420-0700 SHIM D9.5&3.0T2.04
52/1. [1] 146420-0800 SHIM D9.5&3.0T2.06
52/1. [1] 146420-0900 SHIM D9.5&3.0T2.08
52/1. [1] 146420-1000 SHIM D9.5&3.0T2.10
52/1. [1] 146420-1100 SHIM D9.5&3.0T2.12
52/1. [1] 146420-1200 SHIM D9.5&3.0T2.14
52/1. [1] 146420-1300 SHIM D9.5&3.0T2.16
52/1. [1] 146420-1400 SHIM D9.5&3.0T2.18
52/1. [1] 146420-1500 SHIM D9.5&3.0T2.20
52/1. [1] 146420-1600 SHIM D9.5&3.0T2.22
52/1. [1] 146420-1700 SHIM D9.5&3.0T2.24
52/1. [1] 146420-1800 SHIM D9.5&3.0T2.26
52/1. [1] 146420-1900 SHIM D9.5&3.0T2.28
52/1. [1] 146420-2000 SHIM D9.5&3.0T2.30
52/1. [1] 146420-2100 SHIM D9.5&3.0T2.32
52/1. [1] 146420-2200 SHIM D9.5&3.0T2.34
52/1. [1] 146420-2300 SHIM D9.5&3.0T2.36
52/1. [1] 146420-2400 SHIM D9.5&3.0T2.38
52/1. [1] 146420-2500 SHIM D9.5&3.0T2.40
52/1. [1] 146420-2600 SHIM D9.5&3.0T2.42
52/1. [1] 146420-2700 SHIM D9.5&3.0T2.44
52/1. [1] 146420-2800 SHIM D9.5&3.0T2.46
52/1. [1] 146420-2900 SHIM D9.5&3.0T2.48
52/1. [1] 146420-3000 SHIM D9.5&3.0T2.50
52/1. [1] 146420-3100 SHIM D9.5&3.0T2.52
52/1. [1] 146420-3200 SHIM D9.5&3.0T2.54
52/1. [1] 146420-3300 SHIM D9.5&3.0T2.56
52/1. [1] 146420-3400 SHIM D9.5&3.0T2.58
52/1. [1] 146420-3500 SHIM D9.5&3.0T2.60
52/1. [1] 146420-3600 SHIM D9.5&3.0T2.62
52/1. [1] 146420-3700 SHIM D9.5&3.0T2.64
52/1. [1] 146420-3800 SHIM D9.5&3.0T2.66
52/1. [1] 146420-3900 SHIM D9.5&3.0T2.68
52/1. [1] 146420-4000 SHIM D9.5&3.0T2.70
52/1. [1] 146420-4100 SHIM D9.5&3.0T2.72
52/1. [1] 146420-4200 SHIM D9.5&3.0T2.74
52/1. [1] 146420-4300 SHIM D9.5&3.0T2.76
52/1. [1] 146420-4400 SHIM D9.5&3.0T2.78
52/1. [1] 146420-4500 SHIM D9.5&3.0T2.80
52/1. [1] 146420-4600 SHIM D9.5&3.0T2.82
52/1. [1] 146420-4700 SHIM D9.5&3.0T2.84
52/1. [1] 146420-4800 SHIM D9.5&3.0T2.86
52/1. [1] 146420-4900 SHIM D9.5&3.0T2.88
52/1. [1] 146420-5000 SHIM D9.5&3.0T2.90
52/1. [1] 146420-5100 SHIM D9.5&3.0T1.74
52/1. [1] 146420-5200 SHIM D9.5&3.0T1.76
52/1. [1] 146420-5300 SHIM D9.5&3.0T1.78
52/1. [1] 146420-5400 SHIM D9.5&3.0T1.80
52/1. [1] 146420-5500 SHIM D9.5&3.0T1.82
52/1. [1] 146420-5600 SHIM D9.5&3.0T1.84
52/1. [1] 146420-5700 SHIM D9.5&3.0T1.86
52/1. [1] 146420-5800 SHIM D9.5&3.0T1.88
54. [6] 146433-0100 GASKET D12&6.4T1.00
55. [6] 146430-6920 DELIVERY-VALVE ASSEMBLY
56. [6] 146432-0200 COMPRESSION SPRING
58. [6] 146440-0720 FITTING
60. [4] 139106-0100 FLAT-HEAD SCREW
67. [1] 146821-3420 GOVERNOR COVER
67/1. [1] 146508-1022 GOVERNOR COVER
67/2. [1] 146515-0220 CONTROL SHAFT
67/3. [1] 146600-0100 O-RING
67/4. [2] 139310-0200 PLAIN WASHER
67/4. [2] 139310-0200 PLAIN WASHER
67/5. [1] 146530-0000 CONTROL LEVER
67/5B. [1] 146530-0100 CONTROL LEVER
67/6. [2] 014110-6440 LOCKING WASHER
67/6. [2] 014110-6440 LOCKING WASHER
67/7. [1] 013020-6040 UNION NUT M6P1H5
67/8. [1] 146515-1820 LEVER SHAFT
67/9. [1] 146587-4500 COILED SPRING
67/10. [1] 146600-0200 O-RING
67/11. [1] 146602-0100 PLAIN WASHER D14&10.1T1.50
67/12. [1] 146540-1300 CONTROL LEVER
67/12B. [1] 146540-1400 CONTROL LEVER
67/13. [1] 146621-1700 UNION NUT
67/14. [1] 146621-1700 UNION NUT
67/15. [1] 146526-2800 BLEEDER SCREW
67/16. [1] 146526-2800 BLEEDER SCREW
67/18. [1] 146587-2000 COILED SPRING
67/19. [1] 146541-0000 ANGLE PIECE
67/23. [1] 146925-2520 BRACKET
67/24. [2] 139006-4500 BLEEDER SCREW
67/25. [1] 013020-6040 UNION NUT M6P1H5
67/26. [1] 146925-2920 BRACKET
67/78. [1] 146600-4400 SEAL RING
67/200. [1] 139308-0300 PLAIN WASHER
67/201. [1] 146545-3400 THREADED PIN L53.00
67/201B. [1] 146545-3500 THREADED PIN L55.00
67/201C. [1] 146545-3600 THREADED PIN L57.00
67/202. [1] 139208-0900 UNION NUT
67/203. [1] 146600-1200 O-RING
95. [1] 146871-0720 FULCRUM LEVER
104. [2] 146568-0000 SLOTTED SPRING PIN
105. [2] 026508-1140 GASKET D11.4&8.2T1
106. [2] 146588-0500 COILED SPRING
107. [1] 146569-0300 UNION NUT
108. [1] 146570-0420 GOVERNOR SHAFT
109. [1] 146600-0400 O-RING
110/1. [1] 146571-0000 SHIM D20.2&8.3T1.05
110/1. [1] 146571-0100 SHIM D20.2&8.3T1.25
110/1. [1] 146571-0200 SHIM D20.2&8.3T1.45
110/1. [1] 146571-0300 SHIM D20.2&8.3T1.65
110/1. [1] 146571-0400 SHIM D20.2&8.3T1.85
110/1. [1] 146571-0500 SHIM D20.2&8.3T1.15
110/1. [1] 146571-0600 SHIM D20.2&8.3T1.35
110/1. [1] 146571-0700 SHIM D20.2&8.3T1.55
110/1. [1] 146571-0800 SHIM D20.2&8.3T1.75
111. [1] 146602-0600 PLAIN WASHER D20&8.4T1.40
112. [1] 146572-0020 FLYWEIGHT ASSEMBLY
114. [1] 146602-2600 PLAIN WASHER D34&13T1.0
115. [1] 146975-6800 SLIDING SLEEVE
116. [1] 146576-0400 CAP
117/1. [1] 146877-0820 PLUG
117/1. [1] 146877-0920 PLUG
117/1. [1] 146877-1020 PLUG
117/1. [1] 146877-1120 PLUG
117/1. [1] 146877-1220 PLUG
117/1. [1] 146877-1320 PLUG
117/1. [1] 146877-1420 PLUG
117/1. [1] 146877-1520 PLUG
117/1. [1] 146877-1620 PLUG
117/1. [1] 146877-1720 PLUG
117/1. [1] 146877-1820 PLUG
117/1. [1] 146877-1920 PLUG
117/1. [1] 146877-2020 PLUG
117/1. [1] 146877-2120 PLUG
117/1. [1] 146877-2220 PLUG
117/1. [1] 146877-2320 PLUG
117/1. [1] 146877-2420 PLUG
117/1. [1] 146877-2520 PLUG
117/1. [1] 146877-2620 PLUG
117/1. [1] 146877-2720 PLUG
117/1. [1] 146877-2820 PLUG
117/1. [1] 146877-2920 PLUG
117/1. [1] 146877-3020 PLUG
117/1. [1] 146877-3120 PLUG
117/1. [1] 146877-3220 PLUG
117/1. [1] 146877-3320 PLUG
117/1. [1] 146877-3420 PLUG
117/1. [1] 146877-3520 PLUG
117/1. [1] 146877-3620 PLUG
117/1. [1] 146877-3720 PLUG
117/1. [1] 146877-3820 PLUG
117/1. [1] 146877-3920 PLUG
117/1. [1] 146877-4020 PLUG
117/1. [1] 146877-4120 PLUG
117/1. [1] 146877-4220 PLUG
120. [1] 146879-1920 RETAINING PIN
122. [1] 146580-2800 GOVERNOR SPRING
123. [4] 139106-0200 FLAT-HEAD SCREW
130. [1] 146421-1120 CAPSULE
130/2. [1] 139508-0200 GASKET D11.4&8.2T1
130/3. [1] 146422-0300 BLEEDER SCREW
130/4. [1] 146600-0500 O-RING
133. [1] 146600-0600 O-RING
134. [1] 146600-0700 O-RING
135. [1] 146110-3320 CONTROL VALVE
135/5. [1] 146114-0000 SPRING WASHER
136. [1] 146120-1820 OVER FLOW VALVE
137. [2] 029341-2140 GASKET
205. [1] 029470-4030 WOODRUFF KEY
240. [1] 146650-1320 PULLING ELECTROMAGNET
240/8. [1] 146600-1700 O-RING
242. [1] 146662-0120 WIRE
243. [1] 146621-4901 UNION NUT
245. [2] 029341-2140 GASKET
246. [1] 027412-2440 EYE BOLT
800S. [1] 146018-8520 PUMP HOUSING
800S/1/6. [1] 146601-1100 PACKING RING
800S/1/6. [1] 146601-1100 PACKING RING
804S. [1] 146232-0720 COMPRESSION SPRING
805S. [1] 146574-0320 PARTS SET
810S. [1] 146600-1120 REPAIR SET
821S. [1] 146210-5720 ROLLER SET
835S. [1] 146598-1000 CAP
836S/1. [1] 146598-0600 CAP L18
836S/1. [1] 146598-0700 CAP L21
836S/1. [1] 146598-0800 CAP L24
836S/1. [1] 146598-0900 CAP L27
903. [1] 146620-0120 CAPSULE
903/2. [1] 146600-1300 O-RING &13W1.9
906. [1] 146972-9800 NAMEPLATE

Include in #2:

104762-4010 as INJECTION-PUMP ASSEMBLY

Cross reference number

BOSCH 9 460 611 576 9460611576
ZEXEL 104762-4010 1047624010
KOMATSU 6734711240 6734711240


Zexel num
Bosch num
Firm num
Name
104762-4010
9 460 611 576
6734711240  KOMATSU
INJECTION-PUMP ASSEMBLY
6D102E K 11CK INJECTION PUMP ASSY VE6 VE

Calibration Data:

Adjustment conditions
Test oil
1404 Test oil   ISO4113orSAEJ967d
Test oil temperature degC   45 45 50
Nozzle   105780-0060
Bosch type code   NP-DN0SD1510
Nozzle holder   105780-2150
Opening pressure MPa   13 13 13.3
Opening pressure kgf/cm2   133 133 136
Injection pipe   157805-7320
Injection pipe
Inside diameter - outside diameter - length (mm) mm   2-6-450
Joint assembly   157641-4720
Tube assembly   157641-4020
Transfer pump pressure kPa   20 20 20
Transfer pump pressure kgf/cm2   0.2 0.2 0.2
Direction of rotation (viewed from drive side)
Right   R
Injection timing adjustment
Pump speed r/min   800 800 800
Average injection quantity mm3/st.   69.3 68.8 69.8
Difference in delivery mm3/st.   5.5
Basic   *
Oil temperature degC   50 48 52
Injection timing adjustment_02
Pump speed r/min   500 500 500
Average injection quantity mm3/st.   70.8 66.3 75.3
Oil temperature degC   48 46 50
Injection timing adjustment_03
Pump speed r/min   800 800 800
Average injection quantity mm3/st.   69.3 68.3 70.3
Difference in delivery mm3/st.   6
Basic   *
Oil temperature degC   50 48 52
Injection timing adjustment_04
Pump speed r/min   1000 1000 1000
Average injection quantity mm3/st.   72.2 68.7 75.7
Oil temperature degC   50 48 52
Injection timing adjustment_05
Pump speed r/min   1125 1125 1125
Average injection quantity mm3/st.   70.9 68.4 73.4
Oil temperature degC   50 48 52
Injection quantity adjustment
Pump speed r/min   1250 1250 1250
Average injection quantity mm3/st.   20.3 16.3 24.3
Difference in delivery mm3/st.   4
Basic   *
Oil temperature degC   50 48 52
Injection quantity adjustment_02
Pump speed r/min   1250 1250 1250
Average injection quantity mm3/st.   20.3 15.8 24.8
Basic   *
Oil temperature degC   50 48 52
Injection quantity adjustment_03
Pump speed r/min   1350 1350 1350
Average injection quantity mm3/st.   5
Oil temperature degC   50 48 52
Governor adjustment
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   14.9 12.9 16.9
Difference in delivery mm3/st.   2
Basic   *
Oil temperature degC   48 46 50
Governor adjustment_02
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   14.9 12.4 17.4
Difference in delivery mm3/st.   2.5
Basic   *
Oil temperature degC   48 46 50
Timer adjustment
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   97.3 92.3 102.3
Basic   *
Oil temperature degC   48 46 50
Remarks
Full
Timer adjustment_02
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   97.3 92.3 102.3
Basic   *
Oil temperature degC   48 46 50
Remarks
Full
Speed control lever angle
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   0 0 0
Oil temperature degC   48 46 50
Remarks
Magnet OFF at full-load position
Speed control lever angle_02
Pump speed r/min   250 250 250
Average injection quantity mm3/st.   10
Oil temperature degC   48 46 50
Remarks
Magnet OFF at idling position
Speed control lever angle_03
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   0 0 0
Oil temperature degC   48 46 50
Remarks
Magnet OFF at full-load position
0000000901
Pump speed r/min   900 900 900
Overflow quantity cm3/min   780 650 910
Oil temperature degC   50 48 52
_02
Pump speed r/min   900 900 900
Overflow quantity cm3/min   780 650 910
Oil temperature degC   50 48 52
Stop lever angle
Pump speed r/min   900 900 900
Pressure kPa   598 559 637
Pressure kgf/cm2   6.1 5.7 6.5
Basic   *
Oil temperature degC   50 48 52
Stop lever angle_02
Pump speed r/min   900 900 900
Pressure kPa   598 549 647
Pressure kgf/cm2   6.1 5.6 6.6
Basic   *
Oil temperature degC   50 48 52
0000001101
Pump speed r/min   900 900 900
Timer stroke mm   2.4 2.1 2.7
Basic   *
Oil temperature degC   50 48 52
_02
Pump speed r/min   800 800 800
Timer stroke mm   0.9 0.4 1.4
Oil temperature degC   50 48 52
_03
Pump speed r/min   900 900 900
Timer stroke mm   2.4 2 2.8
Basic   *
Oil temperature degC   50 48 52
_04
Pump speed r/min   1125 1125 1125
Timer stroke mm   3.7 3.3 4.2
Oil temperature degC   50 48 52
0000001201
Max. applied voltage V   16 16 16
Test voltage V   25 24 26
0000001401
Pump speed r/min   1125 1125 1125
Average injection quantity mm3/st.   51.8 49.3 54.3
Timer stroke TA mm   2.8 2.3 3.3
Timer stroke variation dT mm   0.9 0.9 0.9
Basic   *
Oil temperature degC   50 48 52
_02
Pump speed r/min   1125 1125 1125
Average injection quantity mm3/st.   51.8 49.3 54.3
Timer stroke TA mm   2.8 2.3 3.3
Basic   *
Oil temperature degC   50 48 52
_03
Pump speed r/min   1125 1125 1125
Average injection quantity mm3/st.   36 33 39
Timer stroke TA mm   1.1 0.5 1.7
Oil temperature degC   50 48 52
_04
Pump speed r/min   1125 1125 1125
Average injection quantity mm3/st.   20 17 23
Timer stroke TA mm   2 1 3
Oil temperature degC   50 48 52
Timing setting
K dimension mm   2.8 2.7 2.9
KF dimension mm   5.77 5.67 5.87
MS dimension mm   2 1.9 2.1
Control lever angle alpha deg.   22 18 26
Control lever angle beta deg.   30 25 35

Test data Ex:

0000001801 STARTING I/Q ADJUSTMENT

Test data 104762-4010
Starting Q decrease lever adjustment Adjust using the screw so that the standards are satisfied, then fix using the nut (A). Bolt (B) protrusion: L mm
----------
L=7.4~11.1mm
----------
L=7.4~11.1mm T=5.9~8.8Nm(0.6~0.9kgfm)




Information:

4.236 Engines
(1) Inside diameter of rod for small end bushing ... 38.8938 to 38.9192 mm (1.53125 to 1.53225 in)(2) Outside diameter of bushing for piston pin ... 38.989 to 39.027 mm (1.5350 to 1.5365 in) Inside diameter of bushing for piston pin (after reaming) ... 34.9441 to 34.9631 mm (1.37575 to 1.37650 in)Clearance between small end bushing and piston pin ... 0.0191 to 0.0432 mm (.00075 to .00170 in)(3) Distance between center of piston pin and center of crankshaft bearing ... 219.05 to 219.10 mm (8.624 to 8.626 in)(4) Outside diameter of connecting rod bearing ... 67.221 mm (2.6465 in) Inside diameter of connecting rod bearing (standard) ... 63.520 to 63.548 mm (2.5008 to 2.5019 in)Bearings available for reground (machined) journals of crankshaft with undersize ... 0.25, 0.51 and 0.76 mm (.010, .020 and .030 in)Shell thickness ... 1.836 to 1.844 mm (.0723 to .0726 in)(5) Inside diameter of rod for big end bearing ... 67.208 to 67.221 mm (2.6460 to 2.6465 in)(6) Torque for connecting rod nuts: Cadmium plated nuts (silver color) ... 100 N m (75 lb ft)Phosphated nuts (dull black color) ... 130 N m (95 lb ft)T4.236 Engines
(1) Inside diameter of rod for small end bushing ... 42.0688 to 42.0942 mm (1.65625 to 1.65725 in)(2) Outside diameter of bushing for piston pin ... 42.1577 to 42.1958 mm (1.65975 to 1.66125 in) Inside diameter of bushing for piston pin (after reaming) ... 38.1191 to 38.1381 mm (1.50075 to 1.50150 in)Clearance between small end bushing and piston pin ... 0.0191 to 0.0432 mm (.00075 to .00170 in)(3) Distance between center of piston pin and center of crankshaft bearing ... 219.05 to 219.10 mm (8.624 to 8.626 in)(4) Outside diameter of connecting rod bearing ... 67.221 mm (2.6465 in) Inside diameter of connecting rod bearing (standard) ... 63.520 to 63.548 mm (2.5008 to 2.5019 in)Bearings available for reground (machined) journals of crankshaft with undersize ... 0.25, 0.51 and 0.76 mm (.010, .020 and .030 in)Shell thickness ... 1.836 to 1.844 mm (.0723 to .0726 in)(5) Inside diameter of rod for big end bearing ... 67.208 to 67.221 mm (2.6460 to 2.6465 in)(6) Torque for connecting rod nuts: Cadmium plated nuts (silver color) ... 100 N m (75 lb ft)Phosphated nuts (dull black color) ... 130 N m (95 lb ft)
