104749-2103 ZEXEL 9 460 614 700 BOSCH INJECTION-PUMP ASSEMBLY 9460614700 1047492103 1670005e10

Do not operate or work on this product unless you have read and understood the instruction and warnings in the relevant Operation and Maintenance Manuals and relevant service literature. Failure to follow the instructions or heed the warnings could result in injury or death. Proper care is your responsibility.
Illustration 1 g06531932
Typical example
(1) 310-4948 Clip
(2) 310-4947 Clip
(3) 536-7106 Grommet
Illustration 2 g06533545
Typical view of DEF lines group in 794 AC/ 796 AC/ 798 AC machines
Table 1
Required Parts
Item Qty New Part Number Part Name Former Part Number(1)
1 12(2) 310-4948 Clip 3G-8054
2 12(2) 310-4947 Clip 3G-8057
3 12(2) 536-7106 Grommet 3G-8047
(1) The former part number listed is for reference only and may differ.
(2) 785G machines require only 8 quantity.New 310-4948 Clip (1) replaces the former 3G-8054 Clip in the DEF lines group/heater lines group.New 310-4947 Clip (2) replaces the former 3G-8057 Clip in the DEF lines group/heater lines group.New 536-7106 Grommet (3) replaces the former 3G-8047 Grommet in the DEF lines group/heater lines group.
