104749-1150 ZEXEL INJECTION-PUMP ASSEMBLY Calibration Data 1047491150 8942425570




Information injection-pump assembly

ZEXEL 104749-1150 1047491150
ISUZU 8942425570 8942425570
104749-1150 INJECTION-PUMP ASSEMBLY
Rating:
52
Buy INJECTION-PUMP ASSEMBLY 104749-1150 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

ZEXEL 104749-1150 1047491150
ISUZU 8942425570 8942425570


Zexel num
Bosch num
Firm num
Name
104749-1150
104749-1152

8942425570  ISUZU
INJECTION-PUMP ASSEMBLY
C223 *

Calibration Data:

Adjustment conditions
(Note)
For Japan: year/month/day (change sequence)
  1989/1/26 (2)
Test oil
1404 Test oil
  ISO4113orSAEJ967d
Test oil temperature degC   45 45 50
Nozzle   105000-2010
Bosch type code   NP-DN12SD12TT
Nozzle holder   105780-2080
Opening pressure MPa   14.7 14.7 15.19
Opening pressure kgf/cm2   150 150 155
Injection pipe
Inside diameter - outside diameter - length (mm)
mm   2-6-840
Transfer pump pressure kPa   20 20 20
Transfer pump pressure kgf/cm2   0.2 0.2 0.2
Direction of rotation (viewed from drive side)
Left
  L
Injection timing adjustment
Pump speed r/min   1500 1500 1500
Average injection quantity mm3/st.   39.35 38.8 39.9
Difference in delivery mm3/st.   3
Basic   *
Injection timing adjustment_02
Pump speed r/min   2440 2440 2440
Average injection quantity mm3/st.   13.7 10.7 16.7
Injection timing adjustment_03
Pump speed r/min   2175 2175 2175
Average injection quantity mm3/st.   36.25 34.1 38.4
Injection timing adjustment_04
Pump speed r/min   1500 1500 1500
Average injection quantity mm3/st.   39.35 38.3 40.4
Injection timing adjustment_05
Pump speed r/min   600 600 600
Average injection quantity mm3/st.   31.15 29.1 33.2
Injection timing adjustment_06
Pump speed r/min   1500 1500 1500
Average injection quantity mm3/st.   38.4 37.9 38.9
Difference in delivery mm3/st.   3
Basic   *
Remarks
For Japan

Injection timing adjustment_07
Pump speed r/min   2440 2440 2440
Average injection quantity mm3/st.   13.4 10.4 16.4
Remarks
For Japan

Injection timing adjustment_08
Pump speed r/min   2175 2175 2175
Average injection quantity mm3/st.   35.4 33.3 37.5
Remarks
For Japan

Injection timing adjustment_09
Pump speed r/min   1500 1500 1500
Average injection quantity mm3/st.   38.4 37.4 39.4
Remarks
For Japan

Injection timing adjustment_10
Pump speed r/min   600 600 600
Average injection quantity mm3/st.   30.4 28.4 32.4
Remarks
For Japan

Injection quantity adjustment
Pump speed r/min   2440 2440 2440
Average injection quantity mm3/st.   13.7 10.7 16.7
Basic   *
Injection quantity adjustment_02
Pump speed r/min   2550 2550 2550
Average injection quantity mm3/st.   6.2
Injection quantity adjustment_03
Pump speed r/min   2440 2440 2440
Average injection quantity mm3/st.   13.4 10.4 16.4
Basic   *
Remarks
For Japan

Injection quantity adjustment_04
Pump speed r/min   2550 2550 2550
Average injection quantity mm3/st.   6
Remarks
For Japan

Governor adjustment
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   7.7 5.7 9.7
Difference in delivery mm3/st.   2
Basic   *
Governor adjustment_02
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   7.7 5.7 9.7
Governor adjustment_03
Pump speed r/min   450 450 450
Average injection quantity mm3/st.   3.1
Governor adjustment_04
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   7.5 5.5 9.5
Difference in delivery mm3/st.   2
Basic   *
Remarks
For Japan

Governor adjustment_05
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   7.5 5.5 9.5
Remarks
For Japan

Governor adjustment_06
Pump speed r/min   450 450 450
Average injection quantity mm3/st.   3
Remarks
For Japan

Timer adjustment
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   65 65
Basic   *
Timer adjustment_02
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   63 63
Basic   *
Remarks
For Japan

Speed control lever angle
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   0 0 0
Remarks
Magnet OFF

Speed control lever angle_02
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   0 0 0
Remarks
For Japan: Magnet OFF

0000000901
Pump speed r/min   1000 1000 1000
Overflow quantity cm3/min   417 288 546
_02
Pump speed r/min   1000 1000 1000
Overflow quantity cm3/min   441 312 570
Remarks
For Japan

Stop lever angle
Pump speed r/min   1500 1500 1500
Pressure kPa   539.5 520 559
Pressure kgf/cm2   5.5 5.3 5.7
Basic   *
Stop lever angle_02
Pump speed r/min   1000 1000 1000
Pressure kPa   411.5 382 441
Pressure kgf/cm2   4.2 3.9 4.5
Stop lever angle_03
Pump speed r/min   1500 1500 1500
Pressure kPa   539.5 520 559
Pressure kgf/cm2   5.5 5.3 5.7
Stop lever angle_04
Pump speed r/min   2175 2175 2175
Pressure kPa   686.5 657 716
Pressure kgf/cm2   7 6.7 7.3
Stop lever angle_05
Pump speed r/min   1500 1500 1500
Pressure kPa   529.5 510 549
Pressure kgf/cm2   5.4 5.2 5.6
Basic   *
Remarks
For Japan

Stop lever angle_06
Pump speed r/min   1000 1000 1000
Pressure kPa   402 373 431
Pressure kgf/cm2   4.1 3.8 4.4
Remarks
For Japan

Stop lever angle_07
Pump speed r/min   1500 1500 1500
Pressure kPa   529.5 510 549
Pressure kgf/cm2   5.4 5.2 5.6
Remarks
For Japan

Stop lever angle_08
Pump speed r/min   2175 2175 2175
Pressure kPa   676.5 647 706
Pressure kgf/cm2   6.9 6.6 7.2
Remarks
For Japan

0000001101
Pump speed r/min   1500 1500 1500
Timer stroke mm   4.1 3.9 4.3
Basic   *
_02
Pump speed r/min   1000 1000 1000
Timer stroke mm   2.1 1.5 2.7
_03
Pump speed r/min   1500 1500 1500
Timer stroke mm   4.1 3.8 4.4
_04
Pump speed r/min   2175 2175 2175
Timer stroke mm   6.6 6.2 7
_05
Pump speed r/min   1500 1500 1500
Timer stroke mm   4 3.8 4.2
Basic   *
Remarks
For Japan

_06
Pump speed r/min   1000 1000 1000
Timer stroke mm   2 1.4 2.6
Remarks
For Japan

_07
Pump speed r/min   1500 1500 1500
Timer stroke mm   4 3.7 4.3
Remarks
For Japan

_08
Pump speed r/min   2175 2175 2175
Timer stroke mm   6.55 6.1 7
Remarks
For Japan

0000001201
Max. applied voltage V   8 8 8
Test voltage V   13 12 14
Timing setting
K dimension mm   3.3 3.2 3.4
KF dimension mm   5.8 5.7 5.9
MS dimension mm   1.8 1.7 1.9
Control lever angle alpha deg.   25 21 29
Control lever angle beta deg.   41.5 36.5 46.5




Information:


Table 3
Injector Resistance Measurement
Step Instruction Completed
(Yes/No) Results
Comments Units
1 Turn the keyswitch to the OFF position. Allow 2 minutes to elapse before proceeding.
2 Disconnect the DEF injector from the applicable harness.
3 Inspect the connector for damage or debris (if damaged take photo)
4 Measure the temperature of the injector (aluminum body) C
5 Connect two 398-4987 connectors to the DEF injector. The connectors must be used to prevent damage to the DEF injector connector.
6 Measure the resistance of the DEF injector. Ohms
Table 4
Dosing Accuracy Test
Step Instruction Completed
(Yes/No) Results
Comments Units
1 Follow the Testing and Adjusting, Aftertreatment SCR System Dosing - Test.
2 Remove the injector from the DPF outlet.
3 Take a photograph of the DEF injector mount on the DPF outlet and the tip of the DEF injector.
4 Install the injector on the beaker.
5 Run the DEF System Dosing Accuracy test through Cat ET.
6 Use the breaker to measure the amount of fluid from the dosing test. ml
7 Repeat the test to verify consistency. ml
8 Install the injector back onto the DPF outlet.
Illustration 2 g06068068
DEF Injector Resistance Measurement
Illustration 3 g06067706
Injector Mount on DPF (Outlet Sample Picture)
Illustration 4 g06067753
DEF Injector Tip (Sample Picture)
When troubleshooting requests the DEF quality check, DEF injector resistance measurement or Dosing Accuracy Test, please document results in the Tables shown above.
After completing troubleshooting and performing the Aftertreatment System Functional Test, download a new Product Status Report with all ECM's.
Table 5
Injector Failure Report
Step Instruction Completed
(Yes/No) Results
Comments Units
1 Download "Product Status Report" (PSR) from the engine ECM and send to the email address in the instructions.
2 Download "Warranty Report" (WR) from the engine ECM and send to the email address in the instructions.
3 Take a picture of the injector part number / serial number.
4 Follow the correct TSG based on Table 1 and complete tables 2 through 4 when they apply.
5 Perform an "Aftertreatment System Functional Test".
6 Download "Product Status Report" (PSR) from the engine ECM and send to the email address in the instructions.
7 Submit "TIB Check List", "Product Status Reports", DEF injector deposits photographs, CEM deposit photographs, and DEF injector part number and serial number photograph to the email address in the instructions.
Fill out the Injector Failure Report and send all information including product status reports, warranty reports, DEF injector and mount photos, DEF injector part number and serial number and test results to the email address provided above.
