Information injection-pump assembly
ZEXEL
104749-1130
1047491130
ISUZU
8942415621
8942415621
Rating:
Cross reference number
ZEXEL
104749-1130
1047491130
ISUZU
8942415621
8942415621
Zexel num
Bosch num
Firm num
Name
Calibration Data:
Adjustment conditions
(Note)
For Japan: year/month/day (change sequence) 1988/11/24 (2)
For Japan: year/month/day (change sequence) 1988/11/24 (2)
Test oil
1404 Test oil ISO4113orSAEJ967d
1404 Test oil ISO4113orSAEJ967d
Test oil temperature
degC
45
45
50
Nozzle
105000-2010
Bosch type code
NP-DN12SD12TT
Nozzle holder
105780-2080
Opening pressure
MPa
14.7
14.7
15.19
Opening pressure
kgf/cm2
150
150
155
Injection pipe
Inside diameter - outside diameter - length (mm) mm 2-6-840
Inside diameter - outside diameter - length (mm) mm 2-6-840
Transfer pump pressure
kPa
20
20
20
Transfer pump pressure
kgf/cm2
0.2
0.2
0.2
Direction of rotation (viewed from drive side)
Left L
Left L
Injection timing adjustment
Pump speed
r/min
1500
1500
1500
Average injection quantity
mm3/st.
39.35
38.8
39.9
Difference in delivery
mm3/st.
3
Basic
*
Injection timing adjustment_02
Pump speed
r/min
2440
2440
2440
Average injection quantity
mm3/st.
13.7
10.7
16.7
Injection timing adjustment_03
Pump speed
r/min
2175
2175
2175
Average injection quantity
mm3/st.
36.25
34.1
38.4
Injection timing adjustment_04
Pump speed
r/min
1500
1500
1500
Average injection quantity
mm3/st.
39.35
38.3
40.4
Injection timing adjustment_05
Pump speed
r/min
600
600
600
Average injection quantity
mm3/st.
31.15
29.1
33.2
Injection timing adjustment_06
Pump speed
r/min
1500
1500
1500
Average injection quantity
mm3/st.
38.4
37.9
38.9
Difference in delivery
mm3/st.
3
Basic
*
Remarks
For Japan
For Japan
Injection timing adjustment_07
Pump speed
r/min
2440
2440
2440
Average injection quantity
mm3/st.
13.4
10.4
16.4
Remarks
For Japan
For Japan
Injection timing adjustment_08
Pump speed
r/min
2175
2175
2175
Average injection quantity
mm3/st.
35.4
33.3
37.5
Remarks
For Japan
For Japan
Injection timing adjustment_09
Pump speed
r/min
1500
1500
1500
Average injection quantity
mm3/st.
38.4
37.4
39.4
Remarks
For Japan
For Japan
Injection timing adjustment_10
Pump speed
r/min
600
600
600
Average injection quantity
mm3/st.
30.4
28.4
32.4
Remarks
For Japan
For Japan
Injection quantity adjustment
Pump speed
r/min
2440
2440
2440
Average injection quantity
mm3/st.
13.7
10.7
16.7
Basic
*
Injection quantity adjustment_02
Pump speed
r/min
2550
2550
2550
Average injection quantity
mm3/st.
6.2
Injection quantity adjustment_03
Pump speed
r/min
2440
2440
2440
Average injection quantity
mm3/st.
13.4
10.4
16.4
Basic
*
Remarks
For Japan
For Japan
Injection quantity adjustment_04
Pump speed
r/min
2550
2550
2550
Average injection quantity
mm3/st.
6
Remarks
For Japan
For Japan
Governor adjustment
Pump speed
r/min
350
350
350
Average injection quantity
mm3/st.
7.7
5.7
9.7
Difference in delivery
mm3/st.
2
Basic
*
Governor adjustment_02
Pump speed
r/min
350
350
350
Average injection quantity
mm3/st.
7.7
5.7
9.7
Governor adjustment_03
Pump speed
r/min
450
450
450
Average injection quantity
mm3/st.
3.1
Governor adjustment_04
Pump speed
r/min
350
350
350
Average injection quantity
mm3/st.
7.5
5.5
9.5
Difference in delivery
mm3/st.
2
Basic
*
Remarks
For Japan
For Japan
Governor adjustment_05
Pump speed
r/min
350
350
350
Average injection quantity
mm3/st.
7.5
5.5
9.5
Remarks
For Japan
For Japan
Governor adjustment_06
Pump speed
r/min
450
450
450
Average injection quantity
mm3/st.
3
Remarks
For Japan
For Japan
Timer adjustment
Pump speed
r/min
100
100
100
Average injection quantity
mm3/st.
65
65
Basic
*
Timer adjustment_02
Pump speed
r/min
100
100
100
Average injection quantity
mm3/st.
63
63
Basic
*
Remarks
For Japan
For Japan
Speed control lever angle
Pump speed
r/min
350
350
350
Average injection quantity
mm3/st.
0
0
0
Remarks
Magnet OFF
Magnet OFF
Speed control lever angle_02
Pump speed
r/min
350
350
350
Average injection quantity
mm3/st.
0
0
0
Remarks
For Japan: Magnet OFF
For Japan: Magnet OFF
0000000901
Pump speed
r/min
1000
1000
1000
Overflow quantity
cm3/min
417
288
546
_02
Pump speed
r/min
1000
1000
1000
Overflow quantity
cm3/min
441
312
570
Remarks
For Japan
For Japan
Stop lever angle
Pump speed
r/min
1500
1500
1500
Pressure
kPa
539.5
520
559
Pressure
kgf/cm2
5.5
5.3
5.7
Basic
*
Stop lever angle_02
Pump speed
r/min
1000
1000
1000
Pressure
kPa
411.5
382
441
Pressure
kgf/cm2
4.2
3.9
4.5
Stop lever angle_03
Pump speed
r/min
1500
1500
1500
Pressure
kPa
539.5
520
559
Pressure
kgf/cm2
5.5
5.3
5.7
Stop lever angle_04
Pump speed
r/min
2175
2175
2175
Pressure
kPa
686.5
657
716
Pressure
kgf/cm2
7
6.7
7.3
Stop lever angle_05
Pump speed
r/min
1500
1500
1500
Pressure
kPa
529.5
510
549
Pressure
kgf/cm2
5.4
5.2
5.6
Basic
*
Remarks
For Japan
For Japan
Stop lever angle_06
Pump speed
r/min
1000
1000
1000
Pressure
kPa
402
373
431
Pressure
kgf/cm2
4.1
3.8
4.4
Remarks
For Japan
For Japan
Stop lever angle_07
Pump speed
r/min
1500
1500
1500
Pressure
kPa
529.5
510
549
Pressure
kgf/cm2
5.4
5.2
5.6
Remarks
For Japan
For Japan
Stop lever angle_08
Pump speed
r/min
2175
2175
2175
Pressure
kPa
676.5
647
706
Pressure
kgf/cm2
6.9
6.6
7.2
Remarks
For Japan
For Japan
0000001101
Pump speed
r/min
1500
1500
1500
Timer stroke
mm
4.1
3.9
4.3
Basic
*
_02
Pump speed
r/min
1000
1000
1000
Timer stroke
mm
2.1
1.5
2.7
_03
Pump speed
r/min
1500
1500
1500
Timer stroke
mm
4.1
3.8
4.4
_04
Pump speed
r/min
2175
2175
2175
Timer stroke
mm
6.6
6.2
7
_05
Pump speed
r/min
1500
1500
1500
Timer stroke
mm
4
3.8
4.2
Basic
*
Remarks
For Japan
For Japan
_06
Pump speed
r/min
1000
1000
1000
Timer stroke
mm
2
1.4
2.6
Remarks
For Japan
For Japan
_07
Pump speed
r/min
1500
1500
1500
Timer stroke
mm
4
3.7
4.3
Remarks
For Japan
For Japan
_08
Pump speed
r/min
2175
2175
2175
Timer stroke
mm
6.55
6.1
7
Remarks
For Japan
For Japan
0000001201
Max. applied voltage
V
8
8
8
Test voltage
V
13
12
14
Timing setting
K dimension
mm
3.3
3.2
3.4
KF dimension
mm
5.8
5.7
5.9
MS dimension
mm
1.8
1.7
1.9
Control lever angle alpha
deg.
25
21
29
Control lever angle beta
deg.
41.5
36.5
46.5
Information:
