Cross reference number

ZEXEL 104748-1740 1047481740

ISUZU 8944593810 8944593810

Zexel num

Bosch num

Firm num

Name

104748-1740

8944593810 ISUZU

INJECTION-PUMP ASSEMBLY
4FE1 * K

Calibration Data:

Adjustment conditions

Test oil
1404 Test oil ISO4113orSAEJ967d

Test oil temperature degC 45 45 50

Nozzle 105000-2010

Bosch type code NP-DN12SD12TT

Nozzle holder 105780-2080

Opening pressure MPa 14.7 14.7 15.19

Opening pressure kgf/cm2 150 150 155

Injection pipe
Inside diameter - outside diameter - length (mm) mm 2-6-840

Transfer pump pressure kPa 20 20 20

Transfer pump pressure kgf/cm2 0.2 0.2 0.2

Direction of rotation (viewed from drive side)
Right R

Injection timing adjustment

Pump speed r/min 1000 1000 1000

Average injection quantity mm3/st. 23.3 22.8 23.8

Difference in delivery mm3/st. 2

Basic *

Oil temperature degC 50 48 52

Injection timing adjustment_02

Pump speed r/min 600 600 600

Average injection quantity mm3/st. 22.2 20.7 23.7

Oil temperature degC 50 48 52

Injection timing adjustment_03

Pump speed r/min 1000 1000 1000

Average injection quantity mm3/st. 23.3 22.3 24.3

Difference in delivery mm3/st. 2

Basic *

Oil temperature degC 50 48 52

Injection timing adjustment_04

Pump speed r/min 1025 1025 1025

Oil temperature degC 50 48 52

Remarks
MEASURE

Injection quantity adjustment

Pump speed r/min 1150 1150 1150

Average injection quantity mm3/st. 4.7 1.7 7.7

Difference in delivery mm3/st. 2

Basic *

Oil temperature degC 50 48 52

Injection quantity adjustment_02

Pump speed r/min 1200 1200 1200

Average injection quantity mm3/st. 0 0 0

Oil temperature degC 50 48 52

Injection quantity adjustment_03

Pump speed r/min 1150 1150 1150

Average injection quantity mm3/st. 4.7 1.7 7.7

Difference in delivery mm3/st. 2

Oil temperature degC 50 48 52

Governor adjustment

Pump speed r/min 375 375 375

Average injection quantity mm3/st. 5.3 3.3 7.3

Difference in delivery mm3/st. 2

Basic *

Oil temperature degC 48 46 50

Governor adjustment_02

Pump speed r/min 375 375 375

Average injection quantity mm3/st. 5.3 3.3 7.3

Difference in delivery mm3/st. 2

Oil temperature degC 48 46 50

Timer adjustment

Pump speed r/min 100 100 100

Average injection quantity mm3/st. 47 47 54

Basic *

Oil temperature degC 48 46 50

Remarks
Full

Timer adjustment_02

Pump speed r/min 100 100 100

Average injection quantity mm3/st. 47 47 54

Oil temperature degC 48 46 50

Speed control lever angle

Pump speed r/min 375 375 375

Average injection quantity mm3/st. 0 0 0

Oil temperature degC 48 46 50

Remarks
Magnet OFF at idling position

0000000901

Pump speed r/min 1000 1000 1000

Overflow quantity cm3/min 360 230 490

Oil temperature degC 50 48 52

Stop lever angle

Pump speed r/min 1000 1000 1000

Pressure kPa 392 372 412

Pressure kgf/cm2 4 3.8 4.2

Basic *

Oil temperature degC 50 48 52

Stop lever angle_02

Pump speed r/min 1000 1000 1000

Pressure kPa 392 372 412

Pressure kgf/cm2 4 3.8 4.2

Basic *

Oil temperature degC 50 48 52

0000001101

Pump speed r/min 1000 1000 1000

Timer stroke mm 1.1 0.9 1.3

Basic *

Oil temperature degC 50 48 52

_02

Pump speed r/min 850 750 950

Timer stroke mm 0.5 0.5 0.5

Oil temperature degC 50 48 52

_03

Pump speed r/min 1000 1000 1000

Timer stroke mm 1.1 0.9 1.3

Basic *

Oil temperature degC 50 48 52

_04

Pump speed r/min 1500 1500 1500

Timer stroke mm 3.3 3 3.7

Oil temperature degC 50 48 52

0000001201

Max. applied voltage V 8 8 8

Test voltage V 13 12 14

Timing setting

K dimension mm 3.3 3.2 3.4

KF dimension mm 5.8 5.7 5.9

MS dimension mm 2.5 2.4 2.6

Control lever angle alpha deg. 25 21 29

Control lever angle beta deg. 33.5 28.5 38.5
