104748-0134 ZEXEL 9 460 610 188 BOSCH INJECTION-PUMP ASSEMBLY 9460610188 1047480134




Information injection-pump assembly

BOSCH 9 460 610 188 9460610188
ZEXEL 104748-0134 1047480134
104748-0134 INJECTION-PUMP ASSEMBLY
Rating:
15
Buy INJECTION-PUMP ASSEMBLY 104748-0134 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

BOSCH 9 460 610 188 9460610188
ZEXEL 104748-0134 1047480134


Zexel num
Bosch num
Firm num
Name
104748-0134
104748-0139
9 460 610 188
  MAZDA
INJECTION-PUMP ASSEMBLY
RF *

Calibration Data:

Adjustment conditions
Test oil
1404 Test oil
  ISO4113orSAEJ967d
Test oil temperature degC   45 45 50
Nozzle   105000-2010
Bosch type code   NP-DN12SD12TT
Nozzle holder   105780-2080
Opening pressure MPa   14.7 14.7 15.19
Opening pressure kgf/cm2   150 150 155
Injection pipe
Inside diameter - outside diameter - length (mm)
mm   2-6-840
Transfer pump pressure kPa   20 20 20
Transfer pump pressure kgf/cm2   0.2 0.2 0.2
Direction of rotation (viewed from drive side)
Right
  R
Injection timing adjustment
Pump speed r/min   1375 1375 1375
Average injection quantity mm3/st.   36.1 35.6 36.6
Difference in delivery mm3/st.   2.5
Basic   *
Injection timing adjustment_02
Pump speed r/min   2500 2500 2500
Average injection quantity mm3/st.   21.1 18.1 24.1
Injection timing adjustment_03
Pump speed r/min   2325 2325 2325
Average injection quantity mm3/st.   32.2 30.2 34.2
Injection timing adjustment_04
Pump speed r/min   1375 1375 1375
Average injection quantity mm3/st.   36.1 35.1 37.1
Injection timing adjustment_05
Pump speed r/min   500 500 500
Average injection quantity mm3/st.   30 28 32
Injection quantity adjustment
Pump speed r/min   2500 2500 2500
Average injection quantity mm3/st.   21.1 19.1 23.1
Basic   *
Injection quantity adjustment_02
Pump speed r/min   2750 2750 2750
Average injection quantity mm3/st.   4
Governor adjustment
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   8 6 10
Difference in delivery mm3/st.   2
Basic   *
Governor adjustment_02
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   8 6 10
Governor adjustment_03
Pump speed r/min   450 450 450
Average injection quantity mm3/st.   4
Timer adjustment
Pump speed r/min   100 100 100
Average injection quantity mm3/st.   42 42
Basic   *
Speed control lever angle
Pump speed r/min   350 350 350
Average injection quantity mm3/st.   0 0 0
Remarks
Magnet OFF

0000000901
Pump speed r/min   1375 1375 1375
Overflow quantity cm3/min   410 278 542
Stop lever angle
Pump speed r/min   1375 1375 1375
Pressure kPa   460.5 431 490
Pressure kgf/cm2   4.7 4.4 5
Basic   *
Stop lever angle_02
Pump speed r/min   500 500 500
Pressure kPa   215.5 186 245
Pressure kgf/cm2   2.2 1.9 2.5
Stop lever angle_03
Pump speed r/min   1375 1375 1375
Pressure kPa   460.5 431 490
Pressure kgf/cm2   4.7 4.4 5
Stop lever angle_04
Pump speed r/min   2325 2325 2325
Pressure kPa   715.5 686 745
Pressure kgf/cm2   7.3 7 7.6
0000001101
Pump speed r/min   1375 1375 1375
Timer stroke mm   4.7 4.5 4.9
Basic   *
_02
Pump speed r/min   1375 1375 1375
Timer stroke mm   4.7 4.4 5
_03
Pump speed r/min   1750 1750 1750
Timer stroke mm   6.7 6.1 7.3
_04
Pump speed r/min   2325 2325 2325
Timer stroke mm   7.8 7.2 8.4
0000001201
Max. applied voltage V   8 8 8
Test voltage V   13 12 14
0000001401
Pump speed r/min   1375 1375 1375
Average injection quantity mm3/st.   28.2 27.2 29.2
Timer stroke TA mm   4.1 3.9 4.3
Basic   *
_02
Pump speed r/min   1375 1375 1375
Average injection quantity mm3/st.   28.2 26.7 29.7
Timer stroke TA mm   4.1 3.8 4.4
_03
Pump speed r/min   1375 1375 1375
Average injection quantity mm3/st.   16.1 14.6 17.6
Timer stroke TA mm   2.9 2.2 3.6
Timing setting
K dimension mm   3.3 3.2 3.4
KF dimension mm   5.8 5.7 5.9
MS dimension mm   1.5 1.4 1.6
Control lever angle alpha deg.   30 28 32
Control lever angle beta deg.   45 40 50

Test data Ex:

0000001801 M-CSD ADJUSTMENT

Test data 104748-0134
M-CSD adjustment 1. Fixing the M-CSD (1)At roller holder advance angle a adjust the lever shaft ball pin so that it contacts the roller holder. (2)At this time, adjust the position of the M-CSD lever (A) using adjusting screw (C) so that the clearance between the M-CSD lever (A) and the stopper (B) becomes L1. Then fix using nut (D). TT 2. M-FICD adjustment (1)Move the CSD lever (A) through its full stroke. (2)Adjust screw (E) so that the control lever (G)'s position is b (the clearance between the control lever and the idling set screw is L2). Then fix using the nut (F). TT Pump speed NE H = from idle to position b
----------
L1=0.5+2mm L2=4.8+-1mm a=0deg b=7deg T=6~9N-m(0.6~0.9kgf-m)
----------
L1=0.5+2mm L2=4.8+-1mm T=6~9N-m(0.6~0.9kgf-m) b=7deg
