104742-1130 ZEXEL INJECTION-PUMP ASSEMBLY Calibration Data 1047421130 8943256050

Information Cross number Calibration Data Calibration Data Ex

Information injection-pump assembly

ZEXEL 104742-1130 1047421130

ISUZU 8943256050 8943256050

Price: query

Buy now
Add to cart Go to cart

Rating:

Buy INJECTION-PUMP ASSEMBLY 104742-1130 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

ZEXEL 104742-1130 1047421130

ISUZU 8943256050 8943256050

Zexel num

Bosch num

Firm num

Name

104742-1130
104742-1131

8943256050 ISUZU

INJECTION-PUMP ASSEMBLY
4BE1 *

Calibration Data:

Adjustment conditions

Test oil
1404 Test oil ISO4113orSAEJ967d

Test oil temperature degC 45 45 50

Nozzle 105000-2010

Bosch type code NP-DN12SD12TT

Nozzle holder 105780-2080

Opening pressure MPa 14.7 14.7 15.19

Opening pressure kgf/cm2 150 150 155

Injection pipe
Inside diameter - outside diameter - length (mm) mm 2-6-840

Transfer pump pressure kPa 20 20 20

Transfer pump pressure kgf/cm2 0.2 0.2 0.2

Direction of rotation (viewed from drive side)
Right R

Injection timing adjustment

Pump speed r/min 1050 1050 1050

Average injection quantity mm3/st. 60.8 60.3 61.3

Difference in delivery mm3/st. 4

Basic *

Oil temperature degC 50 48 52

Injection timing adjustment_02

Pump speed r/min 400 400 400

Average injection quantity mm3/st. 60.8 56.3 65.3

Oil temperature degC 48 46 50

Injection timing adjustment_03

Pump speed r/min 700 700 700

Average injection quantity mm3/st. 49.4 45.9 52.9

Oil temperature degC 50 48 52

Injection timing adjustment_04

Pump speed r/min 1050 1050 1050

Average injection quantity mm3/st. 60.8 59.8 61.8

Difference in delivery mm3/st. 4

Basic *

Oil temperature degC 50 48 52

Injection timing adjustment_05

Pump speed r/min 1400 1400 1400

Average injection quantity mm3/st. 59.1 55.1 63.1

Oil temperature degC 50 48 52

Injection timing adjustment_06

Pump speed r/min 1750 1750 1750

Average injection quantity mm3/st. 58 52.5 63.5

Difference in delivery mm3/st. 6

Oil temperature degC 50 48 52

Injection quantity adjustment

Pump speed r/min 2100 2100 2100

Average injection quantity mm3/st. 13.4 10.4 16.4

Difference in delivery mm3/st. 7

Basic *

Oil temperature degC 52 50 54

Injection quantity adjustment_02

Pump speed r/min 2200 2200 2200

Average injection quantity mm3/st. 8

Oil temperature degC 52 50 54

Injection quantity adjustment_03

Pump speed r/min 2100 2100 2100

Average injection quantity mm3/st. 13.4 10.4 16.4

Difference in delivery mm3/st. 7

Oil temperature degC 52 50 54

Governor adjustment

Pump speed r/min 350 350 350

Average injection quantity mm3/st. 9.4 7.4 11.4

Difference in delivery mm3/st. 2

Basic *

Oil temperature degC 48 46 50

Governor adjustment_02

Pump speed r/min 350 350 350

Average injection quantity mm3/st. 9.4 7.4 11.4

Difference in delivery mm3/st. 2

Oil temperature degC 48 46 50

Timer adjustment

Pump speed r/min 100 100 100

Average injection quantity mm3/st. 75 75

Basic *

Oil temperature degC 48 46 50

Remarks
Full

Timer adjustment_02

Pump speed r/min 100 100 100

Average injection quantity mm3/st. 75 75

Oil temperature degC 48 46 50

Speed control lever angle

Pump speed r/min 350 350 350

Average injection quantity mm3/st. 0 0 0

Oil temperature degC 48 46 50

Remarks
Magnet OFF at idling position

Speed control lever angle_02

Pump speed r/min 100 100 100

Average injection quantity mm3/st. 0 0 0

Oil temperature degC 48 46 50

Remarks
Magnet OFF at idling position

0000000901

Pump speed r/min 1600 1600 1600

Overflow quantity with S/T OFF cm3/min 620 490 750

Oil temperature degC 50 48 52

Stop lever angle

Pump speed r/min 1600 1600 1600

Pressure with S/T OFF kPa 588 568 608

Pressure with S/T OFF kgf/cm2 6 5.8 6.2

Basic *

Oil temperature degC 50 48 52

Stop lever angle_02

Pump speed r/min 1600 1600 1600

Pressure with S/T OFF kPa 588 568 608

Pressure with S/T OFF kgf/cm2 6 5.8 6.2

Oil temperature degC 50 48 52

Stop lever angle_03

Pump speed r/min 1750 1750 1750

Pressure with S/T OFF kPa 637 608 666

Pressure with S/T OFF kgf/cm2 6.5 6.2 6.8

Oil temperature degC 50 48 52

0000001101

Pump speed r/min 1600 1600 1600

Timer stroke with S/T OFF mm 3 2.8 3.2

Basic *

Oil temperature degC 50 48 52

_02

Pump speed r/min 850 850 850

Timer stroke with S/T ON mm 0.5 0.5

Oil temperature degC 50 48 52

_03

Pump speed r/min 1450 1450 1450

Timer stroke with S/T OFF mm 0.5

Oil temperature degC 50 48 52

_04

Pump speed r/min 1500 1500 1500

Timer stroke with S/T OFF mm 0.9 0.5 1.2

Oil temperature degC 50 48 52

_05

Pump speed r/min 1600 1600 1600

Timer stroke with S/T OFF mm 3 2.8 3.2

Oil temperature degC 50 48 52

_06

Pump speed r/min 1750 1750 1750

Timer stroke with S/T OFF mm 5.7 5.4 6.1

Oil temperature degC 50 48 52

0000001201

Max. applied voltage V 16 16 16

Test voltage V 25 24 26

Timing setting

K dimension mm 3.1 3 3.2

KF dimension mm 5.5 5.4 5.6

MS dimension mm 0.9 0.8 1

Pre-stroke mm 0.45 0.43 0.47

Control lever angle alpha deg. 50 46 54

Control lever angle beta deg. 35 30 40

Test data Ex:

0000001801 Temp. adjust full-load screw

Temporary full load screw adjustment Set the full load screw protrusion at L mm at assembly.
----------
L=14.0+-0.5mm
----------
L=14.0+-0.5mm
