104740-3450 ZEXEL 9 460 614 294 BOSCH INJECTION-PUMP ASSEMBLY 9460614294 1047403450 md074541




Information injection-pump assembly

BOSCH 9 460 614 294 9460614294
ZEXEL 104740-3450 1047403450
MITSUBISHI MD074541 md074541
104740-3450 INJECTION-PUMP ASSEMBLY
Rating:
77
Buy INJECTION-PUMP ASSEMBLY 104740-3450 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

BOSCH 9 460 614 294 9460614294
ZEXEL 104740-3450 1047403450
MITSUBISHI MD074541 md074541


Zexel num
Bosch num
Firm num
Name
104740-3450
104740-3580
9 460 614 294
MD074541  MITSUBISHI
INJECTION-PUMP ASSEMBLY
4D55 K

Calibration Data:

Adjustment conditions
Test oil
1404 Test oil
  ISO4113orSAEJ967d
Test oil temperature degC   45 45 50
Nozzle   105000-2010
Bosch type code   NP-DN12SD12TT
Nozzle holder   105780-2080
Opening pressure MPa   14.7 14.7 15.19
Opening pressure kgf/cm2   150 150 155
Injection pipe
Inside diameter - outside diameter - length (mm)
mm   2-6-840
Transfer pump pressure kPa   20 20 20
Transfer pump pressure kgf/cm2   0.2 0.2 0.2
Direction of rotation (viewed from drive side)
Right
  R
Injection timing adjustment
Pump speed r/min   600 600 600
Boost pressure kPa   46.65 46 47.3
Boost pressure mmHg   350 345 355
Average injection quantity mm3/st.   38.2 37.7 38.7
Basic   *
Injection timing adjustment_02
Pump speed r/min   1250 1250 1250
Boost pressure kPa   115.95 114.6 117.3
Boost pressure mmHg   870 860 880
Average injection quantity mm3/st.   57.3 56.8 57.8
Difference in delivery mm3/st.   4.5
Basic   *
Injection timing adjustment_03
Pump speed r/min   2650 2650 2650
Boost pressure kPa   115.95 114.6 117.3
Boost pressure mmHg   870 860 880
Average injection quantity mm3/st.   19.6 14.6 24.6
Injection timing adjustment_04
Pump speed r/min   2100 2100 2100
Boost pressure kPa   115.95 114.6 117.3
Boost pressure mmHg   870 860 880
Average injection quantity mm3/st.   51.8 49.3 54.3
Injection timing adjustment_05
Pump speed r/min   1250 1250 1250
Boost pressure kPa   115.95 114.6 117.3
Boost pressure mmHg   870 860 880
Average injection quantity mm3/st.   57.3 56.3 58.3
Injection timing adjustment_06
Pump speed r/min   750 750 750
Boost pressure kPa   70.65 69.3 72
Boost pressure mmHg   530 520 540
Average injection quantity mm3/st.   46.3 43.8 48.8
Injection timing adjustment_07
Pump speed r/min   600 600 600
Boost pressure kPa   46.65 46 47.3
Boost pressure mmHg   350 345 355
Average injection quantity mm3/st.   38.2 37.2 39.2
Injection quantity adjustment
Pump speed r/min   2650 2650 2650
Boost pressure kPa   115.95 114.6 117.3
Boost pressure mmHg   870 860 880
Average injection quantity mm3/st.   19.6 16.6 22.6
Difference in delivery mm3/st.   5.5
Basic   *
Injection quantity adjustment_02
Pump speed r/min   3050 3050 3050
Boost pressure kPa   115.95 114.6 117.3
Boost pressure mmHg   870 860 880
Average injection quantity mm3/st.   5
Governor adjustment
Pump speed r/min   375 375 375
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Average injection quantity mm3/st.   8 6.5 9.5
Difference in delivery mm3/st.   2
Basic   *
Governor adjustment_02
Pump speed r/min   600 600 600
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Average injection quantity mm3/st.   3
Governor adjustment_03
Pump speed r/min   375 375 375
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Average injection quantity mm3/st.   8 6 10
Timer adjustment
Pump speed r/min   100 100 100
Boost pressure kPa   0 0 0
Boost pressure mmHg   0 0 0
Average injection quantity mm3/st.   73 63 83
Basic   *
Speed control lever angle
Pump speed r/min   375 375 375
Boost pressure kPa   0 0 0
Boost pressure mmHg   0 0 0
Average injection quantity mm3/st.   0 0 0
Remarks
Magnet OFF

0000000901
Pump speed r/min   1250 1250 1250
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Overflow quantity cm3/min   420 288 552
Stop lever angle
Pump speed r/min   1250 1250 1250
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Pressure kPa   470.5 441 500
Pressure kgf/cm2   4.8 4.5 5.1
Basic   *
Stop lever angle_02
Pump speed r/min   600 600 600
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Pressure kPa   313.5 284 343
Pressure kgf/cm2   3.2 2.9 3.5
Stop lever angle_03
Pump speed r/min   1250 1250 1250
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Pressure kPa   470.5 441 500
Pressure kgf/cm2   4.8 4.5 5.1
Stop lever angle_04
Pump speed r/min   2100 2100 2100
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Pressure kPa   666.5 637 696
Pressure kgf/cm2   6.8 6.5 7.1
0000001101
Pump speed r/min   1250 1250 1250
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Timer stroke mm   2.9 2.7 3.1
Basic   *
_02
Pump speed r/min   750 750 750
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Timer stroke mm   1 0.4 1.6
_03
Pump speed r/min   1250 1250 1250
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Timer stroke mm   2.9 2.5 3.3
_04
Pump speed r/min   1750 1750 1750
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Timer stroke mm   4.8 4.2 5.4
_05
Pump speed r/min   2350 2350 2350
Boost pressure kPa   46.65 45.3 48
Boost pressure mmHg   350 340 360
Timer stroke mm   6.6 6.2 7
0000001201
Max. applied voltage V   8 8 8
Test voltage V   13 12 14
Timing setting
K dimension mm   3.3 3.2 3.4
KF dimension mm   5.8 5.7 5.9
MS dimension mm   0.9 0.8 1
BCS stroke mm   7.4 7.3 7.5
Control lever angle alpha deg.   59 55 63
Control lever angle beta deg.   46 41 51

Test data Ex:

0000001801 M-FICD ADJUSTMENT

M-FICD adjustment 1. Position the control lever in the idle position. 2. Adjust the M-FICD installation position so that the distance from the FICD lever is L1.
----------
L1=1+1mm
----------

0000001901 ADJUSTMENT PRECAUTIONS

Adjustment precautions 1. After adjusting at full injection quantity and speed N1, at speed N2 set the boost pressure to P1and adjust the injection quantity using the BCS spring setscrew. 2. At boost pressure of at least P2, confirm that the injection quantity is as specified.
----------
N1=1250r/min N2=600r/min P1=46.7kPa(350mmHg) P2=133.3kPa(1000mmHg)
----------




Information:

Commercial Oils
If oils other than Caterpillar oils are used, the following oil specifications provide guidelines for the selection of commercial products.* API specifications CF-4, CF-4/SF, or CF-4/SG
Failure to follow the commercial oil recommendation for API CF-4 performance oils can cause shortened engine life due to piston carbon deposits, liner bore polish and/or abnormally higher increasing oil consumption.API CC and CD oils are unacceptable in this Caterpillar diesel engine.
Lubricant Viscosity Recommendations
The proper SAE grade of oil to select is determined by the minimum outside temperature at which the engine will be started and the maximum outside temperature in which the engine will be operating. This recommendation is to ensure the correct viscosity is used until the next oil change.The recommendation would be to use the highest viscosity oil possible. Even though the ambient temperature may be low, operating engines can still be subjected to normal oil temperatures because of regulated temperature components. The higher viscosity oils will provide better protection to all components which it contacts during the full operating cycle.The use of API CF-4 multi-viscosity oils is recommended because of full protection through a wider temperature range. See chart for recommended viscosity and temperature range.To determine if the oil in the crankcase will flow in cold weather, remove the oil dipstick before starting. If the oil will flow off, the oil is fluid enough to circulate properly. Air Starting Motor Oiler
A lubricator should be used with the starting system.* Use 10 weight non-detergent engine oil above 0°C (32°F) or* diesel fuel or kerosene at temperatures below 0°C (32°F).Lubricant Total Base Number (TBN)
New engine oil must have a TBN of 10 times (for direct injection engines) the percent fuel sulfur as measured by ASTM (American Society of Testing Materials) D2896 method. Refer to the Fuel Specifications in this manual for additional information. Additional Notes
The percentage of sulfur in the fuel will affect the engine oil recommendations. For fuel sulfur effects, the Infrared Analysis or the ASTM D2896 procedure can be used to evaluate the residual neutralization properties of an engine oil. The sulfur products formation depends on the fuel sulfur content, oil formulation, crankcase blowby, engine operating conditions and ambient temperature.The fuel sulfur neutralization of today's new oil formulations along with direct injection (DI) system engines are more effective. Field results indicate that direct injection combustion (DI) systems and the oils now recommended for these engines will operate at an oil TBN equal to 10 times the fuel sulfur. Therefore, the Caterpillar requirements reflect this value of 10 times instead of the previous 20 times for oil TBN when related to fuel sulfur for Cat DI engines and API CF-4 oils. Used oil analysis should be a part of the overall program to provide the assurance that a particular engine installation with all its parameters (engine, oil, operation, maintenance and fuel) are under control. Consult with your Caterpillar dealer for the latest lubrication recommendations.Synthetic Base Stock Oils (SPC)
The performance characteristics of the oil depends on the base oil and
