104740-0220 ZEXEL INJECTION-PUMP ASSEMBLY Calibration Data 1047400220 483613800

Information Cross number Calibration Data Calibration Data Ex

Information injection-pump assembly

ZEXEL 104740-0220 1047400220

MAZDA 483613800 483613800

Price: query

Buy now
Add to cart Go to cart

Rating:

Buy INJECTION-PUMP ASSEMBLY 104740-0220 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

ZEXEL 104740-0220 1047400220

MAZDA 483613800 483613800

Zexel num

Bosch num

Firm num

Name

104740-0220
104740-0222

483613800 MAZDA

INJECTION-PUMP ASSEMBLY
NEWHA *

Calibration Data:

Adjustment conditions

(Note)
For Japan: year/month/day (change sequence) 1988/08/05 (1)

Test oil
1404 Test oil ISO4113orSAEJ967d

Test oil temperature degC 45 45 50

Nozzle 105000-2010

Bosch type code NP-DN12SD12TT

Nozzle holder 105780-2080

Opening pressure MPa 14.7 14.7 15.19

Opening pressure kgf/cm2 150 150 155

Injection pipe
Inside diameter - outside diameter - length (mm) mm 2-6-840

Transfer pump pressure kPa 20 20 20

Transfer pump pressure kgf/cm2 0.2 0.2 0.2

Direction of rotation (viewed from drive side)
Right R

Injection timing adjustment

Pump speed r/min 900 900 900

Average injection quantity mm3/st. 51.4 50.9 51.9

Difference in delivery mm3/st. 3

Basic *

Injection timing adjustment_02

Pump speed r/min 1000 1000 1000

Average injection quantity mm3/st. 17.5 14.5 20.5

Injection timing adjustment_03

Pump speed r/min 900 900 900

Average injection quantity mm3/st. 51.4 50.4 52.4

Injection timing adjustment_04

Pump speed r/min 500 500 500

Average injection quantity mm3/st. 48 46 50

Injection timing adjustment_05

Pump speed r/min 900 900 900

Average injection quantity mm3/st. 50.2 49.7 50.7

Difference in delivery mm3/st. 3

Basic *

Remarks
For Japan

Injection timing adjustment_06

Pump speed r/min 1000 1000 1000

Average injection quantity mm3/st. 17.1 14.1 20.1

Remarks
For Japan

Injection timing adjustment_07

Pump speed r/min 900 900 900

Average injection quantity mm3/st. 50.2 49.2 51.2

Remarks
For Japan

Injection timing adjustment_08

Pump speed r/min 500 500 500

Average injection quantity mm3/st. 46.9 44.9 48.9

Remarks
For Japan

Injection quantity adjustment

Pump speed r/min 1000 1000 1000

Average injection quantity mm3/st. 17.5 15.5 19.5

Basic *

Injection quantity adjustment_02

Pump speed r/min 1040 1040 1040

Average injection quantity mm3/st. 6.2

Injection quantity adjustment_03

Pump speed r/min 1000 1000 1000

Average injection quantity mm3/st. 17.1 14.1 20.1

Basic *

Remarks
For Japan

Injection quantity adjustment_04

Pump speed r/min 1040 1040 1040

Average injection quantity mm3/st. 6

Remarks
For Japan

Governor adjustment

Pump speed r/min 475 475 475

Average injection quantity mm3/st. 13.1 11.1 15.1

Difference in delivery mm3/st. 2.5

Basic *

Governor adjustment_02

Pump speed r/min 475 475 475

Average injection quantity mm3/st. 13.1 11.1 15.1

Governor adjustment_03

Pump speed r/min 475 475 475

Average injection quantity mm3/st. 12.8 10.8 14.8

Difference in delivery mm3/st. 2.5

Basic *

Remarks
For Japan

Governor adjustment_04

Pump speed r/min 475 475 475

Average injection quantity mm3/st. 12.8 10.8 14.8

Remarks
For Japan

Timer adjustment

Pump speed r/min 100 100 100

Average injection quantity mm3/st. 80.4

Basic *

Timer adjustment_02

Pump speed r/min 100 100 100

Average injection quantity mm3/st. 78

Basic *

Remarks
For Japan

Speed control lever angle

Pump speed r/min 475 475 475

Average injection quantity mm3/st. 0 0 0

Remarks
Magnet OFF

Speed control lever angle_02

Pump speed r/min 475 475 475

Average injection quantity mm3/st. 0 0 0

Remarks
For Japan: Magnet OFF

0000000901

Pump speed r/min 500 500 500

Overflow quantity cm3/min 300 168 432

_02

Pump speed r/min 500 500 500

Overflow quantity cm3/min 300 168 432

Remarks
For Japan

Stop lever angle

Pump speed r/min 900 900 900

Pressure kPa 402 373 431

Pressure kgf/cm2 4.1 3.8 4.4

Basic *

Stop lever angle_02

Pump speed r/min 500 500 500

Pressure kPa 264.5 235 294

Pressure kgf/cm2 2.7 2.4 3

Stop lever angle_03

Pump speed r/min 900 900 900

Pressure kPa 402 373 431

Pressure kgf/cm2 4.1 3.8 4.4

Stop lever angle_04

Pump speed r/min 900 900 900

Pressure kPa 392.5 363 422

Pressure kgf/cm2 4 3.7 4.3

Basic *

Remarks
For Japan

Stop lever angle_05

Pump speed r/min 500 500 500

Pressure kPa 255 226 284

Pressure kgf/cm2 2.6 2.3 2.9

Remarks
For Japan

Stop lever angle_06

Pump speed r/min 900 900 900

Pressure kPa 392.5 363 422

Pressure kgf/cm2 4 3.7 4.3

Remarks
For Japan

0000001101

Pump speed r/min 900 900 900

Timer stroke mm 1.6 1.4 1.8

Basic *

_02

Pump speed r/min 900 900 900

Timer stroke mm 1.6 1.3 1.9

_03

Pump speed r/min 900 900 900

Timer stroke mm 1.6 1.4 1.8

Basic *

Remarks
For Japan

_04

Pump speed r/min 900 900 900

Timer stroke mm 1.6 1.3 1.9

Remarks
For Japan

0000001201

Max. applied voltage V 8 8 8

Test voltage V 13 12 14

Timing setting

K dimension mm 3.3 3.2 3.4

KF dimension mm 5.8 5.7 5.9

MS dimension mm 1.8 1.7 1.9

Pre-stroke mm 0.2 0.18 0.22

Control lever angle alpha deg. 20 16 24

Control lever angle beta deg. 41 36 46
