101606-6751 ZEXEL INJECTION-PUMP ASSEMBLY Calibration Data 1016066751 me076550




Information injection-pump assembly

ZEXEL 101606-6751 1016066751
MITSUBISHI ME076550 me076550
101606-6751 INJECTION-PUMP ASSEMBLY
Rating:
83
Buy INJECTION-PUMP ASSEMBLY 101606-6751 zexel genuine, new aftermarket engine parts with delivery

Cross reference number

ZEXEL 101606-6751 1016066751
MITSUBISHI ME076550 me076550


Zexel num
Bosch num
Firm num
Name
101606-6751
101607-1030

ME076550  MITSUBISHI
INJECTION-PUMP ASSEMBLY
6D16 * K

Calibration Data:

Adjustment conditions
Test oil
1404 Test oil
  ISO4113 or {SAEJ967d}
Test oil temperature degC   40 40 45
Nozzle and nozzle holder   105780-8140
Bosch type code   EF8511/9A
Nozzle   105780-0000
Bosch type code   DN12SD12T
Nozzle holder   105780-2080
Bosch type code   EF8511/9
Opening pressure MPa   17.2
Opening pressure kgf/cm2   175
Injection pipe
Outer diameter - inner diameter - length (mm)
mm   6-2-600
Overflow valve   131424-5520
Overflow valve opening pressure kPa   255 221 289
Overflow valve opening pressure kgf/cm2   2.6 2.25 2.95
Tester oil delivery pressure kPa   157 157 157
Tester oil delivery pressure kgf/cm2   1.6 1.6 1.6
RED3 control unit part number   407910-2 470
RED3 rack sensor specifications mm   15
Direction of rotation (viewed from drive side)
Left
  L
Injection timing adjustment
Direction of rotation (viewed from drive side)
Left
  L
Injection order   1-5-3-6- 2-4
Pre-stroke mm   4.2 4.15 4.25
Beginning of injection position
Governor side
  NO.1
Difference between angles 1
Cal 1-5
deg.   60 59.5 60.5
Difference between angles 2
Cal 1-3
deg.   120 119.5 120.5
Difference between angles 3
Cal 1-6
deg.   180 179.5 180.5
Difference between angles 4
Cyl.1-2
deg.   240 239.5 240.5
Difference between angles 5
Cal 1-4
deg.   300 299.5 300.5
Injection quantity adjustment
Rack position   (8.5)
Vist V   2.3 2.3 2.3
Pump speed r/min   850 850 850
Average injection quantity mm3/st.   74.5 73.5 75.5
Max. variation between cylinders %   0 -3 3
Basic   *
Injection quantity adjustment_02
Rack position   (6.7)
Vist V   2.7 2.6 2.8
Pump speed r/min   275 275 275
Average injection quantity mm3/st.   8 6.4 9.6
Max. variation between cylinders %   0 -15 15
Governor adjustment
Pump speed r/min   1150
Advance angle deg.   0.5
Governor adjustment_02
Pump speed r/min   1200
Advance angle deg.   0.9 0.4 1.4
Governor adjustment_03
Pump speed r/min   1380
Advance angle deg.   5 4.5 5.5
Remarks
Finish


Test data Ex:

Speed control lever angle

Test data 101606-6751
N:Pump normal S:Stop the pump. (1)Rack position = aa (2)Rack position bb
----------
aa=1mm bb=16mm
----------
a=31deg+-5deg b=29deg+-5deg

0000000901

Test data 101606-6751
(1)Pump vertical direction (2)Position of timer's tooth at No 1 cylinder's beginning of injection (3)B.T.D.C.: aa (4)-
----------
aa=11deg
----------
a=(1deg)

Stop lever angle

Test data 101606-6751
(Rs) rack sensor specifications (C/U) control unit part number (V) Rack sensor output voltage (R) Rack position (mm) 1. Confirming governor output characteristics (rack 15 mm, span 6 mm) (1)When the output voltages of the rack sensor are V1 and V2, check that the rack positions R1 and R2 in the table above are satisfied.
----------

----------
