154055-0520 ZEXEL 9 421 610 531 BOSCH HEADLESS SCREW 9421610531 1540550520 224011750a

Table 1
CAT DATA LINK CABLE SPECIFICATIONS, RESISTANCE AND CAPACITANCE
    Measured Parameter
C to C (1) C to S (2)     SCSR (3)
Nominal Capacitance per meter (foot)
75 pF (23 pF)
144 pF (44 pF)     -
Total Nominal Capacitance
455 m (1500 ft)     0.035 µF     0.066 µF     -
Nominal Resistance per meter (foot) at
20 °C (68 °F)     -     -
14.0 mOhms (4.27 mOhms)
Total Nominal Resistance
455 m (1500 ft) at
20 °C (68 °F)     -     -     6.41 mOhms
( 1 ) Conductor to Conductor
( 2 ) Conductor to Shield
( 3 ) Single Conductor Series Resistance (16 AWG, 19/29 stranding)
