105487-0920 ZEXEL F 019 Z4E 707 BOSCH GOVERNOR f019z4e707 1054870920 1157203770

PARTS NEEDED
Qty
Part Number Description
1 5462154 HARNESS AS
In order to allow equitable parts availability to all participating dealers, please limit your initial parts order to not exceed 8% of dealership population. This is an initial order recommendation only, and the ultimate responsibility for ordering the total number of parts needed to satisfy the program lies with the dealer.
ACTION REQUIRED
Remove the valve cover as outlined in RENR9579, "Valve Mechanism Cover - Remove and Install".
Remove the existing harness and replace with the 546-2154 Harness.
Route the harness as shown in Image 1.
Reinstall the valve cover.
SERVICE CLAIM ALLOWANCES
Product smu/age whichever comes first Caterpillar Dealer Suggested Customer Suggested
Parts % Labor Hrs% Parts % Labor Hrs% Parts % Labor Hrs%
0-6000 hrs,
0-60 mo 100.0% 100.0% 0.0% 0.0% 0.0% 0.0%
6001-8000 hrs,
61-72 mo 33.0% 50.0% 0.0% 0.0% 50.0% 50.0%
This is a 2.0-hour job
PARTS DISPOSITION
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
