105480-0310 ZEXEL F 019 Z1E 410 BOSCH GOVERNOR f019z1e410 1054800310 3006116012

Information governor

BOSCH F 019 Z1E 410 f019z1e410

ZEXEL 105480-0310 1054800310

MITSUBISHI 3006116012 3006116012

Price: query

Buy now
Add to cart Go to cart

Rating:

Buy GOVERNOR 105480-0310 zexel genuine, new aftermarket engine parts with delivery

Scheme ###:

1.	[1]	154000-3820	GOVERNOR HOUSING
1/1.	[1]	154000-3800	GOVERNOR HOUSING
1/2.	[1]	155012-0700	ADAPTOR
1/3.	[1]	029010-6010	CAPSULE M6P1.0L7
1/4.	[1]	026506-1040	GASKET D9.9&6.2T1
2.	[1]	155406-0120	AIR FILTER
3.	[1]	026512-1540	GASKET D15.4&12.2T1.50
4.	[1]	154007-2600	ADAPTOR
6.	[1]	154007-0200	ADAPTOR
7.	[1]	020018-1840	BLEEDER SCREW M8P1.25L18
9.	[1]	154350-1800	PLATE
10.	[5]	029010-6810	BLEEDER SCREW
11.	[1]	020106-1640	BLEEDER SCREW M6P1.0L14
12.	[1]	154010-2200	BLEEDER SCREW
13.	[1]	029240-6010	UNION NUT M6P1.0H5*
14.	[2]	154011-0100	HEXAGON NUT
14.	[2]	154011-0100	HEXAGON NUT
35.	[1]	154512-7720	GOVERNOR COVER
35/2.	[1]	154321-1800	BUSHING
35/3.	[1]	029621-0080	PACKING RING
38.	[1]	154031-3200	FLAT-HEAD SCREW
39.	[1]	154011-1600	UNION NUT
47.	[2]	154036-0300	CAPSULE
47.	[2]	154036-0300	CAPSULE
48.	[1]	154010-2500	BLEEDER SCREW
49.	[1]	029240-8000	UNION NUT
50.	[1]	155615-0300	FLAT-HEAD SCREW
51.	[4]	020106-3840	BLEEDER SCREW
52.	[2]	020106-5040	BLEEDER SCREW
53.	[1]	154010-0100	FLAT-HEAD SCREW
65.	[1]	154050-1720	STOPPING DEVICE
80.	[1]	154060-4620	COVER
81.	[1]	131030-2520	LEVEL INDICATOR
82.	[1]	020006-1640	BLEEDER SCREW M6P1L16 4T
83.	[1]	029020-6210	BLEEDER SCREW
84.	[1]	020006-1640	BLEEDER SCREW M6P1L16 4T
86.	[1]	029020-6210	BLEEDER SCREW
100.	[1]	154100-5020	FLYWEIGHT ASSEMBLY
101.	[1]	025803-1610	WOODRUFF KEY
102.	[1]	029321-2020	LOCKING WASHER
103.	[1]	029231-2030	UNION NUT
117.	[1]	154123-0420	SLIDING PIECE
118/1.	[0]	029311-0010	SHIM D14&10.1T0.2
118/1.	[0]	029311-0180	SHIM D14&10.1T0.3
118/1.	[0]	029311-0190	SHIM D14&10.1T0.40
118/1.	[0]	029311-0210	SHIM D14&10.1T1
118/1.	[0]	139410-0000	SHIM D14.0&10.1T0.5
118/1.	[0]	139410-0100	SHIM D14.0&10.1T1.5
118/1.	[0]	139410-3000	SHIM D14&10.1T2.0
118/1.	[0]	139410-3100	SHIM D14&10.1T3.0
118/1.	[0]	139410-3200	SHIM D14&10.1T4.0
130.	[1]	154150-6000	GOVERNOR SPRING
132.	[1]	154154-1300	COILED SPRING
140.	[1]	154170-7720	HEADLESS SCREW
141.	[1]	029201-6010	UNION NUT
150.	[1]	154200-3701	SWIVELLING LEVER
151.	[1]	154204-2001	BUSHING
152.	[2]	029631-8020	O-RING
152.	[2]	029631-8020	O-RING
153.	[2]	154354-3900	LOCKING WASHER
153.	[2]	154354-3900	LOCKING WASHER
154.	[1]	139611-0000	PACKING RING
155.	[1]	139411-0000	SHIM
156/1.	[0]	029311-1110	SHIM D17&11T0.1
156/1.	[0]	029311-1120	SHIM D17&11T0.2
156/1.	[0]	029311-1130	SHIM D17&11T0.3
157.	[1]	154204-3400	BUSHING
159.	[1]	025803-1310	WOODRUFF KEY
160.	[1]	154206-0900	BUSHING
161.	[0]	154206-0200	PLAIN WASHER D19.5&11.2T1.0
170.	[1]	154210-7920	FORK LEVER
173.	[1]	016010-0540	LOCKING WASHER
174.	[1]	154230-3920	STRAP
181.	[1]	154236-1220	TENSIONING LEVER
182.	[1]	154237-0400	BEARING PIN
183.	[2]	154237-0600	BUSHING
190.	[1]	154305-7820	CONTROL LEVER
191.	[1]	154340-0020	CONTROL LEVER
192.	[1]	013020-8040	UNION NUT M8P1.25H7
198.	[1]	014110-8440	LOCKING WASHER
203/1.	[0]	029311-0640	SHIM D26.0&10.2T0.95
203/1.	[0]	029311-0650	SHIM D26.0&10.2T0.20
203/1.	[0]	029311-0660	SHIM D26.0&10.2T0.25
203/1.	[0]	029311-0670	SHIM D26.0&10.2T0.30
203/1.	[0]	029311-0680	SHIM D26.0&10.2T0.35
203/1.	[0]	029311-0690	SHIM D26.0&10.2T0.40
203/1.	[0]	029311-0700	SHIM D26.0&10.2T0.50
203/1.	[0]	139410-1400	SHIM D26&10.2T0.7
203/1.	[0]	139410-1500	SHIM D26&10.2T0.9
203/1.	[0]	139410-1600	SHIM D26&10.2T0.8
203/1.	[0]	139410-2700	SHIM D26&10.2T0.6
205.	[1]	154324-1200	LEVER SHAFT
207.	[1]	154326-0300	CONTROL LEVER
211.	[1]	016010-0840	LOCKING WASHER
220.	[1]	154050-1220	HEADLESS SCREW
221.	[1]	029201-2140	UNION NUT
222.	[2]	026512-1540	GASKET D15.4&12.2T1.50
223.	[1]	154159-1200	CAP NUT
235.	[1]	029621-7010	PACKING RING
236.	[1]	154390-0000	GASKET
237.	[1]	154390-0300	GASKET
238.	[1]	029635-2020	O-RING

Include in #1:

101671-1370 as GOVERNOR

101671-6200

Cross reference number

Zexel num

Bosch num

Firm num

Name

105480-0310

F 019 Z1E 410
NP-EP/RFD200/1350AF7BORN82

3006116012 MITSUBISHI

GOVERNOR
K 14JN MECHANICAL GOVERNOR GOV RFD GOV

Information:

Caterpillar: Confidential Yellow
PSP FOR INSTALLING NEW FUEL INJECTION LINE BRACKETS AND CLAMPS ON CERTAIN D8L TRACTORS, D9N TRACTORS, 589 PIPELAYERS, 631E SCR APERS, 637E SCRAPERS, 657E SCRAPERS, 768C TRACTORS, 769C TRUCKS, 834B TRACTORS, AND 988B LOADERS - PS4428 - MAILED US AND CA NADA, CACO, COFA, BRAZIL, CFEL, COSA
The information supplied in this service letter may not be valid after the termination date of this program. Do not perform the work outlined in this Service Letter after the termination date without first contacting your Caterpillar product analyst.
U-63 A-35 AU-38 B-13 E-39 O-54 1252 PS4428 This Program can be administered either before or after a failure. In either case the decision whether to apply the Program is made by the dealer. When reporting the repair, use "PS4428" as Part Number, "7755" as Group Number, and "96" as Description Code. Termination Date
March 31, 1991
Problem
The fuel lines on certain D8L Tractors, D9N Tractors, 589 Pipelayers, 631E Scrapers, 637E Scrapers, 657E Scrapers, 768C Tractors, 769C Trucks, 834B Tractors, and 988B Loaders may fail. New brackets and clamps can be installed to increase the service life of the fuel injection lines.
Affected Product
Model Identification Number D8L 7YB962 7JC778 D9N 1JD1288, 1295, 1296, 1298-1356, 1358, 1361-2039, 2045, 2048, 2049, 2052 589 31Z423-452 631E 1AB965-1198, 1209 637E 1FB361-416, 418, 422 1JB612-724 657E
