Information governor
BOSCH
9 420 611 740
9420611740
ZEXEL
105447-2210
1054472210

Rating:
Scheme ###:
1. | [1] | 154002-3920 | GOVERNOR HOUSING |
5. | [1] | 154007-1600 | CAPSULE |
10. | [8] | 139006-4100 | BLEEDER SCREW |
12. | [1] | 154034-0800 | BLEEDER SCREW |
13. | [2] | 154011-0100 | HEXAGON NUT |
13. | [2] | 154011-0100 | HEXAGON NUT |
14. | [1] | 020006-1440 | BLEEDER SCREW M6P1L14 |
15. | [1] | 154012-4520 | BLEEDER SCREW |
16. | [1] | 154332-1900 | COILED SPRING |
35. | [1] | 154520-6820 | GOVERNOR COVER |
35/2. | [1] | 154321-0200 | BUSHING |
38. | [1] | 154031-2400 | FLAT-HEAD SCREW |
39. | [1] | 139206-0600 | UNION NUT |
47. | [1] | 154036-0300 | CAPSULE |
51. | [4] | 020106-5040 | BLEEDER SCREW |
52. | [3] | 020106-2840 | BLEEDER SCREW |
53. | [1] | 154034-0800 | BLEEDER SCREW |
65. | [1] | 154421-7920 | MANIFOLD-PRESSURE COMP. |
65/1. | [1] | 154412-7820 | DIAPHRAGM HOUSING |
65/1A. | [1] | 154408-2901 | SPACER BUSHING |
65/1B. | [1] | 134009-0000 | SPACER BUSHING |
65/4. | [1] | 154413-0500 | BUSHING |
65/9. | [1] | 154412-4300 | COILED SPRING |
65/10. | [1] | 154400-8220 | DIAPHRAGM |
65/11. | [1] | 154400-6101 | STOP PIN |
65/14. | [1] | 154406-5500 | SLOTTED WASHER |
65/15. | [1] | 013020-6040 | UNION NUT M6P1H5 |
65/16. | [1] | 154416-3400 | COILED SPRING |
65/17. | [2] | 154413-2600 | GASKET |
65/18. | [1] | 154404-5000 | COVER |
65/19. | [1] | 020106-2040 | BLEEDER SCREW M6P1L20 |
65/20. | [2] | 029010-6310 | BLEEDER SCREW |
65/21. | [2] | 014110-6440 | LOCKING WASHER |
65/24. | [2] | 020106-2040 | BLEEDER SCREW M6P1L20 |
65/27. | [1] | 029731-0180 | EYE BOLT |
65/28. | [2] | 029341-0110 | GASKET |
65/29. | [1] | 154390-1700 | GASKET |
65/43. | [1] | 154390-1800 | GASKET |
65/45. | [1] | 029331-8040 | GASKET |
65/46. | [1] | 154406-5800 | FLAT-HEAD SCREW |
65/47. | [1] | 014110-6440 | LOCKING WASHER |
65/50. | [1] | 154406-6800 | PLAIN WASHER |
65/51. | [1] | 154406-6901 | CONTROL LEVER |
65/52. | [1] | 014110-4440 | LOCKING WASHER |
65/53. | [1] | 010234-0820 | HEX-SOCKET-HEAD CAP SCREW |
65/54. | [1] | 013030-6040 | UNION NUT M6P1H3.6 |
65/55. | [1] | 154404-1500 | FLAT-HEAD SCREW L22.00 |
65/56. | [1] | 029331-2130 | GASKET |
65/57. | [1] | 154406-6500 | FLAT-HEAD SCREW |
65/58. | [1] | 020106-2540 | BLEEDER SCREW M6P1L25 |
65/59. | [2] | 010006-7040 | BLEEDER SCREW M6P1L70 |
65/60. | [2] | 014110-6440 | LOCKING WASHER |
65/61. | [1] | 154035-1600 | CAP NUT |
65/62. | [1] | 154404-4400 | FLAT-HEAD SCREW |
65/63. | [1] | 013030-6040 | UNION NUT M6P1H3.6 |
65/64. | [2] | 026506-1040 | GASKET D9.9&6.2T1 |
65/66. | [1] | 139006-0900 | BLEEDER SCREW |
65/67. | [1] | 014110-6440 | LOCKING WASHER |
65/70. | [1] | 029240-6010 | UNION NUT M6P1.0H5* |
65/71. | [1] | 153141-1600 | BLEEDER SCREW |
65/72. | [1] | 139608-0000 | PACKING RING |
65/73. | [1] | 139605-0100 | PACKING RING |
65/74. | [1] | 154408-9000 | CONTROL LEVER |
65/75. | [1] | 154406-7500 | CONTROL LEVER |
65/76. | [1] | 154406-8000 | LEVER SHAFT |
65/77. | [1] | 029310-5200 | SHIM |
65/78. | [1] | 014020-8120 | PLAIN WASHER D16&8.5T1.2 |
65/79. | [1] | 154372-6500 | SAFETY PIN |
65/80. | [0] | 029310-8040 | SHIM D13.5&8T0.2 |
65/80B. | [0] | 029310-8050 | SHIM D13.5&8T0.5 |
65/81. | [1] | 025520-1210 | SPLIT PIN |
65/82. | [2] | 029300-8320 | SHIM |
65/83. | [1] | 154403-9900 | COILED SPRING |
65/84. | [1] | 154406-7700 | CONTROL LEVER |
65/85. | [1] | 014110-8440 | LOCKING WASHER |
65/86. | [1] | 013020-8140 | UNION NUT M8P1.25H6.5 |
80. | [1] | 154064-1700 | COVER |
82. | [2] | 029020-6210 | BLEEDER SCREW |
83. | [2] | 020006-1640 | BLEEDER SCREW M6P1L16 4T |
100. | [1] | 154100-9720 | FLYWEIGHT ASSEMBLY |
101. | [1] | 025803-1310 | WOODRUFF KEY |
102. | [1] | 029321-2020 | LOCKING WASHER |
103. | [1] | 029231-2030 | UNION NUT |
104. | [1] | 154120-0100 | PLAIN WASHER |
106. | [1] | 029602-0020 | LOCKING WASHER |
107. | [1] | 154121-0500 | TOOTHED GEAR |
108. | [1] | 016610-2640 | BEARING PLATE |
109. | [1] | 028102-0010 | BEARING PLATE |
111. | [1] | 154134-0000 | SPACER BUSHING |
112. | [1] | 154122-0100 | COVER |
113. | [1] | 029614-7020 | LOCKING WASHER |
114. | [1] | 025803-1610 | WOODRUFF KEY |
115. | [1] | 029321-2020 | LOCKING WASHER |
116. | [1] | 029231-2030 | UNION NUT |
117. | [1] | 154123-1920 | SLIDING PIECE |
118/1. | [0] | 029311-0010 | SHIM D14&10.1T0.2 |
118/1. | [0] | 029311-0180 | SHIM D14&10.1T0.3 |
118/1. | [0] | 029311-0190 | SHIM D14&10.1T0.40 |
118/1. | [0] | 029311-0210 | SHIM D14&10.1T1 |
118/1. | [0] | 139410-0000 | SHIM D14.0&10.1T0.5 |
118/1. | [0] | 139410-0100 | SHIM D14.0&10.1T1.5 |
118/1. | [0] | 139410-3000 | SHIM D14&10.1T2.0 |
118/1. | [0] | 139410-3100 | SHIM D14&10.1T3.0 |
118/1. | [0] | 139410-3200 | SHIM D14&10.1T4.0 |
119. | [1] | 154130-1820 | TOOTHED GEAR |
119/3. | [4] | 153251-0100 | DAMPER |
119/4. | [1] | 139329-0000 | PLAIN WASHER |
119/5. | [1] | 016020-2810 | LOCKING WASHER |
122. | [3] | 020106-2840 | BLEEDER SCREW |
132. | [1] | 154154-0900 | COILED SPRING |
133. | [2] | 154156-0100 | TUBE |
135. | [1] | 154158-0920 | HEADLESS SCREW |
136. | [1] | 154011-4400 | UNION NUT |
137. | [2] | 026512-1540 | GASKET D15.4&12.2T1.50 |
138. | [1] | 154159-1200 | CAP NUT |
140. | [1] | 154176-3520 | HEADLESS SCREW |
141. | [1] | 029201-6010 | UNION NUT |
150. | [1] | 154200-6321 | SWIVELLING LEVER |
151. | [1] | 154204-2901 | BUSHING |
152. | [2] | 139718-0200 | O-RING |
152. | [2] | 139718-0200 | O-RING |
153. | [2] | 016010-1640 | LOCKING WASHER |
153. | [2] | 016010-1640 | LOCKING WASHER |
154. | [1] | 139612-0100 | PACKING RING |
155. | [1] | 139411-0500 | SHIM |
158. | [1] | 154204-3700 | BUSHING |
159. | [1] | 025803-1310 | WOODRUFF KEY |
170. | [1] | 154211-7620 | FORK LEVER |
174. | [1] | 154235-3120 | STRAP |
175. | [1] | 016010-0540 | LOCKING WASHER |
176. | [1] | 154232-0400 | CONNECTOR |
177. | [2] | 029050-5040 | FLAT-HEAD SCREW M5P0.8L9 |
181. | [1] | 154236-8620 | TENSIONING LEVER |
182. | [1] | 154237-1500 | BEARING PIN |
190. | [1] | 154349-4620 | CONTROL LEVER |
191. | [1] | 154381-0420 | CONTROL LEVER |
192. | [1] | 020006-3240 | BLEEDER SCREW |
195. | [1] | 154314-1800 | COILED SPRING |
201. | [1] | 139710-0500 | O-RING |
207. | [1] | 154326-5020 | CONTROL LEVER |
211. | [0] | 029311-0220 | SHIM D18&10.3T0.2 |
211B. | [0] | 029311-0230 | SHIM D18&10.3T0.5 |
235. | [1] | 029621-7010 | PACKING RING |
236. | [1] | 154371-5600 | GASKET |
237. | [1] | 154371-3500 | GASKET |
238. | [1] | 154390-3600 | GASKET |
255. | [1] | 154213-5100 | BRACKET |
256. | [1] | 020308-1640 | BLEEDER SCREW M8P1.25L16 |
257. | [1] | 014110-8440 | LOCKING WASHER |
335. | [2] | 026506-1040 | GASKET D9.9&6.2T1 |
336. | [1] | 154035-1600 | CAP NUT |
350. | [1] | 154036-1600 | ADAPTOR |
351. | [1] | 139806-0000 | EYE BOLT |
352. | [2] | 029340-6120 | GASKET |
353. | [1] | 026510-1340 | GASKET D13.4&10.2T1 |
900S. | [1] | 025803-1310 | WOODRUFF KEY |
901S. | [1] | 025803-1610 | WOODRUFF KEY |
Include in #1:
106673-4040
as GOVERNOR
Cross reference number
Zexel num
Bosch num
Firm num
Name
Information:
Introduction
The problem that is identified below does not have a known permanent solution. Until a permanent solution is known, use the solution that is identified below.Problem
Some of the 3408E engines and 3412E engines in the above listed machines may experience hard starting or low power due to oil that is leaking past the poppet valve in the injector. The oil leakage is caused by the operating conditions at either low idle or high idle. Excessive oil leakage can reduce actuation pressure to the fuel injector. This may prevent fuel injection.Solution
Electrical shock hazard. The electronic unit injector system uses 90-120 volts.
Follow the proper troubleshooting procedure for the correct engine. If the problem is not located and the symptoms that are listed above continue, remove the engine valve covers. Electrically disable the injectors. Crank the engine. Watch the spill ports of the injector for oil leakage. A small amount of oil leakage is acceptable. A continuous stream of oil may mean leakage from the poppet valve. Excessive leakage from the poppet valve may prevent fuel injection.Note: Normal oil pressure during cranking should be 5 MPa (725 psi). Oil pressure below 5 MPa (725 psi) may indicate excessive oil leakage in injectors. Do not replace the oil pump. Service personnel should replace the injectors that have a continuous flow of oil from the oil ports. Injectors that have a continuous flow of oil and injectors that are within the guidelines of warranty can be returned. Injectors that do not have a continuous flow of oil should not be replaced. Injectors that do not have a continuous flow of oil should not be returned.Note: For additional information on the operation of Hydraulic Electronic Unit Injectors HEUI, refer to CD, RENR1390.
Illustration 1 g01308874
(1) Oil drain portThe oil drain ports are located underneath the solenoid. This will direct the oil flow downward. Some oil may also leak from the rectangular slots at the side of the solenoid. Excess oil leakage will still be visible on the cylinder head.
