Illustration 8 g01455580
(6) 294-3395 Exhaust Support Assembly
Make four mounting holes for 294-3395 Exhaust Support Assembly (6) in the location (designated with a circle) which is shown in Illustration 8.
Illustration 9 g01456256
(17) 8T-4223 Hard Washers (18) 8T-4244 Nuts (19) 8T-4648 Bolt (20) 8T-4956 Bolt (21) 8T-6868 Bolts
Install exhaust support assembly (6) by using two 8T-6868 Bolts (21), one 8T-4648 Bolt (19), one 8T-4956 Bolt (20), four 8T-4223 Hard Washers (17), and four 8T-4244 Nuts (18). Refer to Illustration 9.
Illustration 10 g01456263
(9) 295-3044 Exhaust Support Groups (Lower half)
Remove the upper clamp from each 295-3044 Exhaust Support Group (9) by removing the two bolts and two hard washers. Keep the four bolts, the four hard washers, and the two upper clamps together. These parts will be reinstalled in Step 15.
Use four 8T-4956 Bolts (20) and four 8T-4223 Hard Washers (17) to install both 295-3044 Exhaust Support Groups (9) to exhaust support assembly (6). Refer to Illustration 10.
Illustration 11 g01456281
(5) 294-3065 Diesel Particulate Filter Group
To facilitate handling, remove the filter units from 294-3065 Diesel Particulate Filter Group (5) by removing the two clamps (including gaskets) closest to the rectangular intake manifold. Place the filter units, clamps, and gaskets aside.Note: Handle the removed filter units with extra care, as the internal structure is subject to damage due to impact, dropping, etc. Do not allow the inside of the filter units to get wet.
Install 294-3065 Diesel Particulate Filter Group (5) by aligning the mounting holes in the intake manifold with the mounting holes in the welded exhaust support assembly (7). Secure the intake manifold to the exhaust support assembly by using two 8T-4956 Bolts (20), two 8T-4223 Hard Washers (17), and two 8T-4244 Nuts (18). Refer to Illustration 11.
Reattach the lower filter unit to the intake manifold by reinstalling the clamp and the gasket that was removed in Step 12. Repeat for the upper filter unit.
Illustration 12 g01456285
Align the mounting holes in the upper half of 295-3044 Exhaust Support Group (9) with the mounting holes in the lower half of the exhaust support group (9). Reinstall the two bolts (9a) and the two hard washers (9b). Repeat for the other exhaust support group (9). Refer to Illustration 12.
Connect the straight end of exhaust tube assembly (8) to the manifold inlet pipe of the Diesel Particulate Filter Group. Use one 190-5341 Clamp (3)
