105410-8930 ZEXEL F 019 Z2F 116 BOSCH GOVERNOR f019z2f116 1054108930

Introduction
This technical bulletin pertains to balancing the lubrication to the pin joints on the 994F Wheel Loader.Problem
There is a lack of lubrication to the A-pin.Solution
Increase the amount of grease to the A-pin by decreasing the interval of the lube cycle from 15 minutes (factory setting) to 8 minutes. Decrease the cycle time to 8 minutes by using the VIMS keypad.Adjust the injectors at all other pin joints in order to reduce the grease flow. This will prevent having excess grease at the other pin joints.See the table for each injector setting.
Table 1
Pin Joint Location     # Injectors     Number of Turns Out     Lubricant Volume (in3)     Lubricant Volume (mL)     mL/Hour
        0     0.014     0.2294     0.0000
Hitches (2)
Trunnions (4)
Fan Drive/Belt (2)     8     1     0.022     0.3605     21.6309
F (2)
G (2)     4     2     0.030     0.4916     14.7484
E (2)
Steering Cylinders (4)     6     3     0.038     0.6227     28.0219
B (4)
C (2)
D (2)
K (2)
Y (2)     12     4     0.046     0.7538     67.8424
        5     0.054     0.8849     0.0000
        6     0.062     1.0160     0.0000
        7     0.070     1.1471     0.0000
A (4)     4     8     0.078     1.2782     38.3457
    Total mL/Hour     170.5893
