105407-7630 ZEXEL 9 420 614 995 BOSCH GOVERNOR 9420614995 1054077630 me755159




Information governor

BOSCH 9 420 614 995 9420614995
ZEXEL 105407-7630 1054077630
MITSUBISHI ME755159 me755159
105407-7630 GOVERNOR
Rating:
21
Buy GOVERNOR 105407-7630 zexel genuine, new aftermarket engine parts with delivery

Scheme ###:

GOVERNOR HOUSING
1. [1] 154004-2822 GOVERNOR HOUSING
2. [1] 154007-2900 CAPSULE
3. [1] 154358-2500 SEAL RING
4. [1] 154064-4500 COVER
5. [4] 020006-1640 BLEEDER SCREW M6P1L16 4T
8. [1] 029632-5070 O-RING
9. [1] 154350-6000 PLATE
10. [8] 020106-2040 BLEEDER SCREW M6P1L20
10. [8] 020106-2040 BLEEDER SCREW M6P1L20
12. [1] 154010-1100 FLAT-HEAD SCREW
13. [2] 154011-0100 HEXAGON NUT
13. [2] 154011-0100 HEXAGON NUT
16. [1] 155004-3600 LEVER SHAFT
18. [1] 155003-2101 CONTROL LEVER
19. [1] 155006-0700 BLEEDER SCREW
20. [1] 139308-0900 PLAIN WASHER D16&8T1
20. [1] 139308-0900 PLAIN WASHER D16&8T1
20B. [1] 139308-1000 PLAIN WASHER D16&8T1.5
20B. [1] 139308-1000 PLAIN WASHER D16&8T1.5
23. [1] 025520-1210 SPLIT PIN
24. [1] 154206-2000 BUSHING
25. [1] 154327-4200 COILED SPRING
26. [1] 154381-7900 CONTROL LEVER
27. [1] 014110-8440 LOCKING WASHER
28. [1] 013020-8040 UNION NUT M8P1.25H7
29. [1] 139408-1500 SHIM
29B. [0] 139408-1400 SHIM
29C. [0] 139408-1500 SHIM
30. [2] 029620-8050 PACKING RING
30. [2] 029620-8050 PACKING RING
35. [1] 154022-7920 GOVERNOR COVER
38. [1] 154031-1300 FLAT-HEAD SCREW
39. [1] 139206-0600 UNION NUT
47. [1] 154036-0300 CAPSULE
51. [6] 020106-5040 BLEEDER SCREW
53. [1] 154010-0200 FLAT-HEAD SCREW
65. [1] 154612-9220 RACK SENSOR ASSY
65/1. [1] 479742-4720 RACK SENSOR
65/2. [1] 154614-2300 JOINT CONNECTION
65/3. [1] 026524-3040 GASKET
65/4A. [0] 029310-6220 SHIM D11.5&6.5T0.10
65/4B. [0] 029310-6230 SHIM D11.5&6.5T0.20
65/4C. [0] 029310-6240 SHIM D11.5&6.5T0.25
65/4D. [0] 029310-6260 SHIM D11.5&6.4T1.00
65/4E. [0] 029310-6270 SHIM D11.5&6.4T1.20
65/4F. [0] 029310-6280 SHIM D11.5&6.4T1.50
65/5. [1] 154614-1900 UNION NUT
80. [1] 154063-1400 COVER
82. [2] 029020-6210 BLEEDER SCREW
83. [2] 020006-1640 BLEEDER SCREW M6P1L16 4T
100. [1] 154101-0020 FLYWEIGHT ASSEMBLY
101. [1] 025803-1310 WOODRUFF KEY
102. [1] 029321-2020 LOCKING WASHER
103. [1] 029231-2030 UNION NUT
117. [1] 154123-2320 SLIDING PIECE
118/1. [0] 029311-0010 SHIM D14&10.1T0.2
118/1. [0] 029311-0180 SHIM D14&10.1T0.3
118/1. [0] 029311-0190 SHIM D14&10.1T0.40
118/1. [0] 029311-0210 SHIM D14&10.1T1
118/1. [0] 139410-0000 SHIM D14.0&10.1T0.5
118/1. [0] 139410-0100 SHIM D14.0&10.1T1.5
118/1. [0] 139410-3000 SHIM D14&10.1T2.0
118/1. [0] 139410-3100 SHIM D14&10.1T3.0
118/1. [0] 139410-3200 SHIM D14&10.1T4.0
132. [1] 154154-0500 COILED SPRING
135. [1] 154158-0820 HEADLESS SCREW
136. [1] 029201-2290 UNION NUT
137. [2] 026512-1540 GASKET D15.4&12.2T1.50
138. [1] 154159-1200 CAP NUT
140. [1] 154177-2320 HEADLESS SCREW
141. [1] 029201-6010 UNION NUT
150. [1] 154200-6920 SWIVELLING LEVER
151. [1] 154204-4300 BUSHING
152. [2] 029631-8020 O-RING
152. [2] 029631-8020 O-RING
153. [2] 016010-1640 LOCKING WASHER
153. [2] 016010-1640 LOCKING WASHER
154. [1] 139611-0000 PACKING RING
155. [1] 139411-0000 SHIM
156. [0] 029311-1070 SHIM D16&11T0.5
157. [1] 154204-4400 BUSHING
159. [1] 025803-1310 WOODRUFF KEY
160. [1] 154206-2800 BUSHING
161. [0] 154206-0200 PLAIN WASHER D19.5&11.2T1.0
170. [1] 154217-2920 FORK LEVER
171. [1] 016010-0540 LOCKING WASHER
172. [3] 029310-5170 SHIM D8&5.3T0.5
172. [3] 029310-5170 SHIM D8&5.3T0.5
173. [2] 025520-1210 SPLIT PIN
173. [2] 025520-1210 SPLIT PIN
174. [1] 154234-6920 STRAP
175. [1] 154232-2420 CONNECTOR
176. [1] 159231-4900 BEARING PIN
177. [1] 155402-3800 SAFETY PIN
181. [1] 154239-3320 TENSIONING LEVER
182. [1] 154237-1100 BEARING PIN
190. [1] 154340-0120 CONTROL LEVER
236. [1] 154371-5600 GASKET
237. [1] 154390-0300 GASKET
238. [1] 029635-2020 O-RING
253. [1] 029320-5020 LOCKING WASHER
254. [1] 010535-1040 FLAT-HEAD SCREW M5P0.8L10
255. [1] 154400-7420 DIAPHRAGM
256. [1] 154400-4800 STOP PIN
257. [2] 029330-8050 GASKET
257. [2] 029330-8050 GASKET
258. [1] 139308-0700 LOCKING WASHER
259. [1] 013030-6040 UNION NUT M6P1H3.6
260. [1] 154401-3620 CONTROL LEVER
261. [1] 154401-1320 STRAP
262. [1] 026510-1440 GASKET D13.9&10.2T1
263. [1] 154401-2100 BLEEDER SCREW
264. [1] 016010-0540 LOCKING WASHER
265. [1] 154222-6200 BEARING PIN
266. [1] 029300-4010 PLAIN WASHER
267. [1] 154416-2100 COILED SPRING
268. [1] 154404-5000 COVER
269. [2] 020106-2540 BLEEDER SCREW M6P1L25
270. [1] 154034-1900 FLAT-HEAD SCREW
271. [1] 013030-6040 UNION NUT M6P1H3.6
273. [1] 029731-0180 EYE BOLT
274. [2] 026510-1340 GASKET D13.4&10.2T1
275. [0] 029312-0180 SHIM D25.5&20T0.5
275B. [0] 029312-0210 SHIM D25.5&20T0.2
276. [1] 154035-1900 CAP NUT
277. [1] 014110-6440 LOCKING WASHER
278. [2] 154413-2600 GASKET
278. [2] 154413-2600 GASKET
279. [2] 026506-1040 GASKET D9.9&6.2T1
283. [1] 016010-0440 LOCKING WASHER
285. [1] 029010-6310 BLEEDER SCREW
300. [1] 154358-9420 BRACKET
301. [1] 020118-1640 BLEEDER SCREW
303. [1] 154011-1100 UNION NUT
304. [1] 029300-8320 SHIM
335. [2] 026506-1040 GASKET D9.9&6.2T1
336. [1] 154035-1600 CAP NUT
353. [4] 029310-9080 SHIM D16&9T1.7
900S. [1] 025803-1310 WOODRUFF KEY
901S. [1] 025803-1610 WOODRUFF KEY

Include in #1:

106676-2430 as GOVERNOR

Cross reference number

Zexel num
Bosch num
Firm num
Name
105407-7630
9 420 614 995
NP-EP/RSV200-1350PQ49/311
ME755159  MITSUBISHI
GOVERNOR
K 14JB MECHANICAL GOVERNOR GOV RSV GOV




Information:


FIVE RING PISTON(1) First (top) compression ring: Width of compression

Have questions with 105407-7630?





Group cross 105407-7630 ZEXEL

105407-7600



Nissan-Diesel

105407-7610
F 019 Z4E 386
NP-EP/RSV200-1600PQ21/332
1910197463
GOVERNOR
105407-7620



Mitsubishi

105407-7630
9 420 614 995
NP-EP/RSV200-1350PQ49/311
ME755159
GOVERNOR
105407-7640
F 019 Z3E 652
NP-EP/RSV200-1300PQ44C301
ME755162
GOVERNOR

Hino

105407-7650

105407-7651
9 420 614 994
223205130A
GOVERNOR
105407-7651


GOVERNOR

Hino

105407-7660
F 019 Z4E 387
NP-EP/RSV200-1300PQ44C312
223205230A
GOVERNOR
105407-7670

105407-7671
F 019 Z2E 622
223204970A
GOVERNOR
105407-7671
F 019 Z1E 950
NP-EP/RSV200-1300PQ39C302
223204960A
GOVERNOR
105407-7680
F 019 Z4E 388
NP-EP/RSV200-1300PQ39C312
223205180A
GOVERNOR
105407-7690
9 420 614 875
NP-EP/RSV200-1350PQ49C302
223204800A
GOVERNOR
