Fuel injectors
  1. Home
  2. governor
  3. #1053740060

105374-0060 ZEXEL 9 420 614 291 BOSCH GOVERNOR 9420614291 1053740060




Information governor

BOSCH 9 420 614 291 9420614291
ZEXEL 105374-0060 1053740060
105374-0060 GOVERNOR
Rating:
14
Buy GOVERNOR 105374-0060 zexel genuine, new aftermarket engine parts with delivery

Scheme ###:

GOVERNOR HOUSING
1. [1] 153002-0200 GOVERNOR HOUSING
2. [2] 153005-0800 CAPSULE
3. [2] 153006-0100 GASKET
4. [4] 029080-8040 FLAT-HEAD SCREW
5. [1] 153014-0700 PIPE
6. [1] 153015-0200 BUSHING
7. [1] 029242-4020 UNION NUT
8. [1] 153017-1520 CLAMPING BAND
20. [1] 153021-2520 STOPPING DEVICE
35. [1] 153105-0100 GOVERNOR COVER
36. [1] 029851-2020 HINGED LID
37. [1] 026510-1340 GASKET D13.4&10.2T1
38. [1] 029111-0030 CAPSULE
50. [1] 153121-0100 LEVER SHAFT
51. [1] 153121-0200 LEVER SHAFT
52. [2] 153126-0300 SLIDING PIECE
53. [2] 029600-8010 LOCKING WASHER
61. [1] 153130-2020 BUSHING
62. [1] 153130-1500 BUSHING
63. [2] 029631-1020 O-RING
63. [2] 029631-1020 O-RING
64. [4] 029050-6090 FLAT-HEAD SCREW
66. [1] 153135-0120 HEADLESS SCREW
67. [1] 029241-4050 UNION NUT
68. [1] 153138-0900 CAP
70. [4] 021006-2540 FLAT-HEAD SCREW
82. [1] 025803-1310 WOODRUFF KEY
101. [1] 153208-0320 FLYWEIGHT ASSEMBLY
101/1. [1] 153208-0310 FLYWEIGHT
101/1. [1] 153208-0310 FLYWEIGHT
101/9/1. [2] 153229-0600 SLOTTED WASHER T2.4
101/9/1. [2] 153229-0700 SLOTTED WASHER T2.3
101/9/1. [2] 153229-0800 SLOTTED WASHER T2.2
101/9/1. [2] 153229-0900 SLOTTED WASHER T2.1
101/10. [2] 153230-6200 GOVERNOR SPRING
101/11. [2] 153232-0800 GOVERNOR SPRING
101/11. [2] 153232-0800 GOVERNOR SPRING
101/12. [2] 153236-0600 GOVERNOR SPRING
101/13. [2] 153241-0400 UNION NUT
101/14. [2] 153242-0100 HEXAGON NUT
101/15. [2] 153243-0200 SLOTTED WASHER
101/16. [2] 153244-0100 UNION NUT
101/25. [2] 156011-0100 FELT
101/26. [4] 153251-0300 DAMPER
101/27. [1] 153252-0100 TOOTHED GEAR
101/28/1. [0] 029311-8040 SHIM D30&18.4T0.1
101/28/1. [0] 029311-8050 SHIM D30&18.4T0.2
101/28/1. [0] 029311-8060 SHIM D30&18.4T0.3
101/28/1. [0] 029311-8070 SHIM D30&18.4T0.4
101/29. [1] 016681-0040 BEARING PLATE
101/30. [1] 016602-0040 BEARING PLATE
101/31. [1] 153270-0500 FLAT-HEAD SCREW
101/32. [2] 029220-6010 UNION NUT
101/33. [1] 153271-0200 TAB WASHER
102. [1] 025805-1910 WOODRUFF KEY
103. [1] 153300-0400 TERMINAL STUD
104. [1] 153320-0100 TOOTHED GEAR
105. [1] 014111-8410 LOCKING WASHER
106. [1] 029231-8010 UNION NUT
107. [4] 153305-1300 SHIM D22&11T0.951
107. [4] 153305-1300 SHIM D22&11T0.951
107. [4] 153305-1400 SHIM D22&11T0.95
108. [1] 153316-0400 CROSS-HEAD
109. [1] 153312-0200 TAB WASHER
110. [1] 029220-8010 UNION NUT
111. [1] 153313-0200 TAB WASHER
112. [1] 023630-8410 LOCKING WASHER
116. [1] 153402-1720 STRAP
117. [1] 153551-9300 BLEEDER SCREW
118. [1] 029310-6040 SHIM
119. [1] 153271-0400 TAB WASHER
120. [1] 013020-6020 UNION NUT M6P1H5
130. [1] 153410-0400 VARIABLE-FULCRUM LEVER
131. [1] 025060-1620 BEARING PIN
132. [1] 029310-6040 SHIM
133. [1] 025515-1010 SPLIT PIN
134. [1] 153413-0200 BRACKET
135. [1] 153414-0100 PLATE
136. [2] 153415-0100 PLATE
137. [1] 153416-0100 PLATE
138. [2] 153417-0100 BLEEDER SCREW
139. [6] 021006-1820 FLAT-HEAD SCREW M6P1L15.7
140. [1] 153418-0200 FORK LINK
141. [1] 153419-0200 BEARING PIN
142. [1] 025520-2010 SPLIT PIN
143. [1] 153419-0300 BEARING PIN
144. [2] 029300-8050 PLAIN WASHER
145. [2] 025520-1210 SPLIT PIN
146. [1] 153420-0100 COILED SPRING
155. [1] 153501-2220 CONTROL LEVER
156. [1] 153503-1520 CONTROL LEVER
157. [1] 153503-0200 CONTROL LEVER
158. [1] 153506-0600 PLATE
160. [2] 153507-0200 PLAIN WASHER
160. [2] 153507-0200 PLAIN WASHER
161. [2] 029133-2020 RIVET PIN
161. [2] 029133-2020 RIVET PIN
180. [1] 029622-5010 PACKING RING
183. [1] 153550-1300 GASKET
184. [1] 153550-1400 GASKET

Include in #1:

103662-0440 as GOVERNOR

Cross reference number

Zexel num
Bosch num
Firm num
Name
105374-0060
9 420 614 291
NP-RP235/750ZA15N2

GOVERNOR
K 14JA MECHANICAL GOVERNOR GOV RQ GOV




Information:

Caterpillar: Confidential Yellow
PARTS STOCK ACTION ONLY - THE DEFLECTOR SHIELDS ON CERTAIN UNIT INJECTORS IN PARTS STOCK MAY FAIL - PI7278 - MAILED US AND CANADA, CACO, COFA, BRAZIL, CFEL, COSA, MARINE TEPS - REVISED 04/92
  The information supplied in this service letter may not be valid after the termination date of this program.   Do not perform the work outlined in this Service Letter after the termination date without first contacting your Caterpillar product analyst.
March 6, 1992 (Revised April 1992) U-41 A-29 AU-24 B-19 E-23 O-37 TM-3 PARTS STOCK THE DEFLECTOR SHIELDS ON CERTAIN UNIT ACTION ONLY INJECTORS IN PARTS STOCK MAY FAIL 1290 PI7278 This Revised Service Letter replaces the March 6, 1992 Service Letter. Changes have been made to the injector group part numbers listed under Action Required. Termination Date
June 30, 1992
Problem
The deflector shields on certain unit injectors in parts stock may fail. All unit injectors in parts stock need to be inspected for the date code "BO".
Action Required
Remove all of

Have questions with 105374-0060?





Group cross 105374-0060 ZEXEL

105374-0060
9 420 614 291
NP-RP235/750ZA15N2

GOVERNOR
105374-0090
