105354-0770 ZEXEL F 019 Z1E 521 BOSCH GOVERNOR f019z1e521 1053540770




Information governor

BOSCH F 019 Z1E 521 f019z1e521
ZEXEL 105354-0770 1053540770
105354-0770 GOVERNOR
Rating:
82
Buy GOVERNOR 105354-0770 zexel genuine, new aftermarket engine parts with delivery

Scheme ###:

GOVERNOR HOUSING
1. [1] 153002-2600 GOVERNOR HOUSING
2. [2] 153005-0800 CAPSULE
3. [2] 153006-0100 GASKET
4. [2] 021008-2520 FLAT-HEAD SCREW
5. [2] 029040-8070 STUD
6. [2] 014020-8120 PLAIN WASHER D16&8.5T1.2
7. [2] 014110-8440 LOCKING WASHER
8. [2] 013020-8020 UNION NUT M8P1.25H7
10. [1] 153013-0100 PLATE
11. [2] 026506-1040 GASKET D9.9&6.2T1
12. [2] 029010-6620 BLEEDER SCREW
13. [1] 153014-0200 PIPE
14. [1] 153016-0200 ADAPTOR
15. [1] 029202-6010 UNION NUT
16. [1] 026518-2240 GASKET D21.9&18.2T1
18. [1] 029851-2020 HINGED LID
19. [1] 153018-0100 GASKET
31. [1] 029111-8060 CAPSULE
32. [1] 029331-8010 GASKET
40. [1] 153106-1410 GOVERNOR COVER
41. [1] 026510-1340 GASKET D13.4&10.2T1
42. [1] 029111-0030 CAPSULE
43. [1] 010006-2840 BLEEDER SCREW M6P1L28
44. [3] 013020-6040 UNION NUT M6P1H5
44. [3] 013020-6040 UNION NUT M6P1H5
44. [3] 013020-6040 UNION NUT M6P1H5
55. [1] 153120-0200 LEVER SHAFT
56. [1] 153123-0300 CONTROL LEVER
57. [1] 153124-0200 CONNECTOR
58. [1] 153125-0300 BEARING PIN
59. [1] 153125-0400 BEARING PIN
60. [2] 024020-1230 BEARING PIN
61. [2] 015130-2090 TAPER PIN
62. [1] 153127-0300 CAM PLATE
63. [1] 021006-2540 FLAT-HEAD SCREW
64. [1] 024040-2430 BEARING PIN
65. [1] 024040-1030 BEARING PIN
77. [1] 153141-0600 FLAT-HEAD SCREW
78. [1] 153142-0120 CAP
79. [1] 021006-1040 FLAT-HEAD SCREW
81. [2] 029631-1030 O-RING
81. [2] 029631-1030 O-RING
82. [2] 029301-1060 PLAIN WASHER
82. [2] 029301-1060 PLAIN WASHER
83. [1] 025520-2010 SPLIT PIN
85. [4] 020106-2240 BLEEDER SCREW
86. [1] 025803-1310 WOODRUFF KEY
115. [1] 153207-3620 FLYWEIGHT ASSEMBLY
115/1. [1] 153207-0010 FLYWEIGHT
115/9. [1] 153227-0100 BUSHING
115/10. [2] 153231-0400 COILED SPRING
115/11. [2] 153233-7600 COILED SPRING
115/12. [2] 153236-2400 GOVERNOR SPRING
115/13. [2] 153240-1700 SLOTTED WASHER
115/13B. [2] 153240-1800 SLOTTED WASHER
115/13C. [2] 153240-1900 SLOTTED WASHER
115/14. [2] 153241-0300 UNION NUT
115/15. [2] 153242-0100 HEXAGON NUT
115/16. [2] 153243-0200 SLOTTED WASHER
115/17. [2] 153244-0100 UNION NUT
115/25. [1] 153252-0300 TOOTHED GEAR
115/26/1. [0] 029311-5020 SHIM D20.5&15T0.05
115/26/1. [0] 029311-5030 SHIM D20.5&15T0.1
115/26/1. [0] 029311-5050 SHIM D20.5&15T0.2
115/26/1. [0] 029311-5060 SHIM D20.5&15T0.4
115/26/1. [0] 029311-5080 SHIM D20.5&15T0.5
115/26/1. [0] 029311-5120 SHIM D20.5&15T0.3
115/27. [1] 028001-5010 BEARING PLATE
115/28/1. [0] 029312-4050 SHIM D33&24T0.6
115/28/1. [0] 153556-2900 SHIM D33&24T0.1
115/28/1. [0] 153556-3000 SHIM D33&24T0.2
115/28/1. [0] 153556-3100 SHIM D33&24T0.3
115/29. [1] 028012-4010 BEARING PLATE
115/30. [4] 153257-0120 STRAP
115/31. [1] 153270-0300 FLAT-HEAD SCREW
115/32. [4] 029220-6010 UNION NUT
115/33. [2] 153271-0100 TAB WASHER
115/34. [0] 029312-5120 SHIM D33&25T0.2
115/34. [0] 029312-6150 SHIM D33&26T0.5
116. [1] 025805-1910 WOODRUFF KEY
117. [1] 153300-0320 TERMINAL STUD
118. [1] 153316-0300 CROSS-HEAD
119. [1] 153320-0720 TOOTHED GEAR
119/1. [1] 153320-0620 TOOTHED GEAR
119/2. [1] 153260-0320 BUSHING
119/3. [4] 153251-0200 DAMPER
119/4. [1] 153321-0100 PLAIN WASHER
119/5. [1] 016020-4010 LOCKING WASHER
120. [1] 014111-8410 LOCKING WASHER
121. [1] 013121-8140 UNION NUT M18P1.5H15
122. [1] 153322-0120 PLATE
123. [1] 153323-0200 SLOTTED WASHER
124. [1] 153324-0100 COILED SPRING
140. [1] 153400-0200 SLOTTED WASHER
141. [1] 153401-0300 COILED SPRING
142. [1] 153402-0300 CONNECTOR
143. [1] 010006-1840 BLEEDER SCREW M6P1L18 4T
144. [1] 014110-6440 LOCKING WASHER
145. [1] 153405-0520 STRAP
146. [2] 025060-1620 BEARING PIN
147. [2] 029310-6040 SHIM
148. [2] 025515-1510 SPLIT PIN
150. [1] 153410-0300 VARIABLE-FULCRUM LEVER
151. [1] 153413-0100 BRACKET
152. [1] 153418-0100 FORK LINK
153. [1] 153419-0100 BEARING PIN
154. [1] 015320-2540 SPLIT PIN
165. [1] 153500-0220 CONTROL LEVER
190. [1] 029622-5010 PACKING RING
192. [1] 154350-1000 GASKET
193. [1] 153550-3000 GASKET
196. [4] 021006-2040 FLAT-HEAD SCREW

Include in #1:

103662-1630 as GOVERNOR

Cross reference number

Zexel num
Bosch num
Firm num
Name
105354-0770
F 019 Z1E 521

GOVERNOR
* K




Information:

Caterpillar: Confidential Yellow
PSP FOR INSTALLING NEW ROCKER ARM BUTTONS THAT OPERATE WITH INJECTOR TAPPETS THAT ARE NOT FLAT ON CERTAIN 3606, 3608, 3612 AND 3616 ENGINES - PS0417 - MAILED US AND CANADA, CACO, COFA, BRAZIL, LIMITED CFEL, LIMITED COSA
  The information supplied in this service letter may not be valid after the termination date of this program.   Do not perform the work outlined in this Service Letter after the termination date without first contacting your Caterpillar product analyst.
U-232 A-149 AU-150 B-38 E-99.1 O-142.1 1123 PS0417 This Program can only be administered after a failure occurs. The decision whether to apply the Program is made by the dealer. When reporting the repair, use "PS0417" as Part Number, "7755" as Group Number, and "96" as Description Code. This Program cancels and replaces the April 24, 1989 Service Letter - PS0374. Termination Date
December 31, 1991
Problem
The 4W9294 Rocker Arm Button may break and fall off the fuel injector rocker arm. New buttons can be installed that will operate with injector tappets that are not flat. It is no longer necessary to change injectors when circular wear patterns show up on the rocker arm buttons.
Affected Product
Model Identification Number 3606 8RB306-335 3608 6MC246-264 3612 9RC16-46 3616 1PD18-23
Parts Needed
Note: Quantities Per Cylinder ***** Parts for use on failed cylinders only ***** 1 - 0R5738 Fuel Injector Group or 1 - 0R5510 Fuel Injector Group 1 - 7W7226

Have questions with 105354-0770?





Group cross 105354-0770 ZEXEL

105354-0730
F 019 Z1E 871

GOVERNOR
105354-0760



105354-0770
F 019 Z1E 521

GOVERNOR

Mitsubishi

105354-0790
F 019 Z1E 522
NP-RQUV250-900ZA15NP222
0425080270
GOVERNOR
