107069-1150 ZEXEL 9 410 614 009 BOSCH FUEL-INJECTION PUMP 9410614009 1070691150 16703z5860




Information fuel-injection pump

BOSCH 9 410 614 009 9410614009
ZEXEL 107069-1150 1070691150
NISSAN-DIESEL 16703Z5860 16703z5860
107069-1150 FUEL-INJECTION PUMP
Rating:
35
Buy FUEL-INJECTION PUMP 107069-1150 zexel genuine, new aftermarket engine parts with delivery

Scheme ###:

1. [1] 135000-0920 PUMP HOUSING
1/30. [3] 029040-6020 STUD
1/45. [1] 134311-0000 SPACER RING
1/50. [12] 135024-0000 STUD
7. [6] 135130-0920 PLUNGER-AND-BARREL ASSY
7/1. [6] 135176-0920 PLUNGER-AND-BARREL ASSY M10
7/3. [6] 135182-0120 VALVE MM3
7/4. [6] 135116-0100 FITTING
7/5. [6] 029632-0030 O-RING
7/6. [6] 134117-2100 FILLER PIECE
7/7. [6] 134112-2800 COILED SPRING
7/13. [6] 135134-0000 O-RING
7/14. [6] 135134-0500 O-RING
12. [1] 135227-0020 CONTROL ROD
13. [1] 134227-1400 BEARING PLATE
14. [1] 134227-0300 BUSHING
18. [1] 135227-1000 CONNECTOR
19. [1] 139005-0300 HEX-SOCKET-HEAD CAP SCREW
20. [1] 139320-0000 PLAIN WASHER
23/1. [0] 139415-0000 SHIM D19&10T0.500
23/1. [0] 139415-0100 SHIM D19&10T0.525
23/1. [0] 139415-0200 SHIM D19&10T0.550
23/1. [0] 139415-0300 SHIM D19&10T0.575
23/1. [0] 139415-0400 SHIM D19&10T0.600
23/1. [0] 139415-0500 SHIM D19&10T0.625
23/1. [0] 139415-0600 SHIM D19&10T0.650
23/1. [0] 139415-0700 SHIM D19&10T0.675
23/1. [0] 139415-0800 SHIM D19&10T0.700
23/1. [0] 139415-0900 SHIM D19&10T0.725
23/1. [0] 139415-1000 SHIM D19&10T0.750
23/1. [0] 139415-1100 SHIM D19&10T0.775
23/1. [0] 139415-1200 SHIM D19&10T0.800
23/1. [0] 139415-1300 SHIM D19&10T0.825
23/1. [0] 139415-1400 SHIM D19&10T0.850
23/1. [0] 139415-1500 SHIM D19&10T0.875
23/1. [0] 139415-1600 SHIM D19&10T0.900
23/1. [0] 139415-1700 SHIM D19&10T0.925
23/1. [0] 139415-1800 SHIM D19&10T0.950
23/1. [0] 139415-1900 SHIM D19&10T0.975
23/1. [0] 139415-2000 SHIM D19&10T1.000
23/1. [0] 139415-2100 SHIM D19&10T1.025
23/1. [0] 139415-2200 SHIM D19&10T1.050
23/1. [0] 139415-2300 SHIM D19&10T1.075
23/1. [0] 139415-2400 SHIM D19&10T1.100
23/1. [0] 139415-2500 SHIM D19&10T1.125
23/1. [0] 139415-2600 SHIM D19&10T1.150
23/1. [0] 139415-2700 SHIM D19&10T1.175
23/1. [0] 139415-2800 SHIM D19&10T1.200
23/1. [0] 139415-2900 SHIM D19&10T1.225
23/1. [0] 139415-3000 SHIM D19&10T1.250
23/1. [0] 139415-3100 SHIM D19&10T1.275
23/1. [0] 139415-3200 SHIM D19&10T1.300
23/1. [0] 139415-3300 SHIM D19&10T1.325
23/1. [0] 139415-3400 SHIM D19&10T1.350
23/1. [0] 139415-3500 SHIM D19&10T1.375
23/1. [0] 139415-3600 SHIM D19&10T1.400
23/1. [0] 139415-3700 SHIM D19&10T1.425
23/1. [0] 139415-3800 SHIM D19&10T1.450
23/1. [0] 139415-3900 SHIM D19&10T1.475
23/1. [0] 139415-4000 SHIM D19&10T1.500
23/1. [0] 139415-4100 SHIM D19&10T1.525
23/1. [0] 139415-4200 SHIM D19&10T1.550
23/1. [0] 139415-4300 SHIM D19&10T1.575
23/1. [0] 139415-4400 SHIM D19&10T1.600
23/1. [0] 139415-4500 SHIM D19&10T1.625
23/1. [0] 139415-4600 SHIM D19&10T1.650
23/1. [0] 139415-4700 SHIM D19&10T1.675
23/1. [0] 139415-4800 SHIM D19&10T1.700
23/1. [0] 139415-4900 SHIM D19&10T1.725
23/1. [0] 139415-5000 SHIM D19&10T1.750
23/1. [0] 139415-5100 SHIM D19&10T1.775
23/1. [0] 139415-5200 SHIM D19&10T1.800
23/1. [0] 139415-5300 SHIM D19&10T1.825
23/1. [0] 139415-5400 SHIM D19&10T1.850
23/1. [0] 139415-5500 SHIM D19&10T1.875
23/1. [0] 139415-5600 SHIM D19&10T1.900
23/1. [0] 139415-5700 SHIM D19&10T1.925
23/1. [0] 139415-5800 SHIM D19&10T1.950
23/1. [0] 139415-5900 SHIM D19&10T1.975
24. [12] 134132-0300 PLAIN WASHER
26. [12] 139210-0200 UNION NUT
30. [2] 134001-0000 BUSHING
30. [2] 134001-0000 BUSHING
32. [1] 135256-0700 CONTROL RACK
33. [1] 024030-2030 BEARING PIN
34. [1] 134222-0000 BUSHING
41. [6] 135241-0020 CONTROL SLEEVE
43. [6] 135216-0000 SLOTTED WASHER
44. [6] 135215-0000 COMPRESSION SPRING
45. [6] 135217-0000 SLOTTED WASHER
47. [4] 135200-0120 TAPPET
47/2. [4] 135204-0000 ROLLER
47/3. [4] 135205-0000 BUSHING
47/4. [4] 135203-0000 BEARING PIN
47/5. [4] 135206-0000 SLIDER
47/6. [4] 135208-0000 LOCKING WASHER
48. [2] 135200-0020 TAPPET
48/2. [2] 135204-0000 ROLLER
48/3. [2] 135205-0000 BUSHING
48/4. [2] 135203-0000 BEARING PIN
48/5. [2] 135206-0000 SLIDER
48/6. [2] 135208-0000 LOCKING WASHER
59. [1] 016650-2230 BEARING PLATE 4T-32205(NSK)
64/1. [0] 134303-0000 SHIM D59.8&43T1.2
64/1. [0] 134303-0100 SHIM D59.8&43T1.5
64/1. [0] 134303-0200 SHIM D59.8&43T1.8
64/1. [0] 134303-0300 SHIM D59.8&43T2.0
64/1. [0] 134303-0400 SHIM D59.8&43T0.6
67. [4] 139006-4100 BLEEDER SCREW
71. [1] 135360-0500 CAMSHAFT
74. [3] 135306-0000 BEARING SHELL
75. [6] 010206-2540 HEX-SOCKET-HEAD CAP SCREW
76. [6] 026506-1040 GASKET
79. [1] 016650-2230 BEARING PLATE 4T-32205(NSK)
80. [1] 135316-0100 COVER
81. [1] 139625-0100 PACKING RING
82/1. [0] 135314-0000 SHIM T0.10
82/1. [0] 135314-0100 SHIM T0.12
82/1. [0] 135314-0200 SHIM T0.14
82/1. [0] 135314-0300 SHIM T0.16
82/1. [0] 135314-0400 SHIM T0.18
82/1. [0] 135314-0500 SHIM T0.3
82/1. [0] 135314-0600 SHIM T0.5
83. [1] 029635-5050 O-RING
84. [1] 134563-0900 SLIDING PIECE
85. [6] 135034-0000 CAPSULE
85. [6] 135034-0000 CAPSULE
88. [6] 135045-0000 CAPSULE
89. [6] 026522-2740 GASKET
90. [7] 135045-0100 CAPSULE
91. [7] 026514-1840 GASKET
93. [3] 139206-0400 UNION NUT
95. [1] 131041-0800 GASKET
96. [6] 134047-0000 CAPSULE
98. [1] 029470-5010 WOODRUFF KEY
118. [1] 135496-0000 POINTER
119. [2] 010206-1240 HEX-SOCKET-HEAD CAP SCREW
132. [1] 135430-0000 EYE BOLT
142. [1] 139810-1400 EYE BOLT
162. [1] 134424-4120 OVER FLOW VALVE

Include in #1:

107692-0560 as FUEL INJECTION PUMP

Cross reference number

Zexel num
Bosch num
Firm num
Name
107069-1150
9 410 614 009
NP-TC6MD110/32ARS2
16703Z5860  NISSAN-DIESEL
FUEL-INJECTION PUMP
