104257-1041 ZEXEL 9 410 617 604 BOSCH FUEL-INJECTION PUMP 9410617604 1042571041 e226450100zd

Display
Table 1
Type     Active Matrix Color TFT Display
Display Size     307 mm (12.1 inch)
Nominal Display Area
Horizontal
Vertical     -
246 mm (9.7 inch)
185 mm (7.3 inch)
Resolution     800 X 600 pixels
256K colors
Viewing Angle
Horizontal (typical)
Vertical (typical)     -
60°
+55°/-45°
Response Time     30 msec (typical)
Touchscreen (optional)     Resistive Analog    Mechanical
Table 2
Enclosure     NEMA 4 (indoor) when mounted (built to IP65 standards)
NEMA 4X (stainless steel) optional
Indicators     Red/Green indicator
Weight
307 mm (12.1 inch)     -
7.4 kg (16.2 lb)    Environmental
Table 3
Operating Temperature
5 °C (41 °F) to
50 °C (122 °F) (233 MMX MHz)
Storage Temperature
-25 °C (-13 °F) to
60 °C (140 °F)
Relative Humidity (1)     8% to 80% non-condensing
Operating Altitude (1)     Sea Level to
3048 m (10,000 ft)
Non-Operating Altitude     Sea Level to
12,000 m (40,000 ft)
Operating Shock     15g (1/2 sine, 11 msec)
Non-Operating Shock     30g (1/2 sine, 11 msec)
Operating Vibration     0.006 inch p-p, 10-57 Hz
1.0g peak, 57-150 Hz sine
Non-Operating Vibration     0.012 inch p-p, 10-57 Hz
2.0g peak, 57-150 Hz sine
( 1 ) Applications with touchscreens in high humidity and high temperature environments have additional considerations.Electrical (DC Option)
Table 4
Line Voltage     18-32 VDC
Input Current     6A max
Fuse     8A
Power Consumption     108 watts maximum
