104057-3320 ZEXEL 9 410 617 437 BOSCH FUEL-INJECTION PUMP 9410617437 1040573320 74347003a

Introduction
The problem that is identified below does not have a known permanent solution. Until a permanent solution is known, use the solution that is identified below.Problem
Certain F2 series machines installed with Tier II or Tier III engines have reported low power from the engine. After troubleshooting, this low power has been diagnosed as being a faulty fuel injection pump.
Table 1
Required Parts
Part Number Part Name
10R-9707 Fuel Injection Pump Gp
10R-9715 Fuel Injection Pump Gp
20R-4832 Fuel Injection Pump Gp
236-8228 Fuel Injection Pump Gp
237-5213 Fuel Injection Pump Gp
248-2356 Fuel Injection Pump Gp
249-9226 Fuel Injection Pump Gp
266-3712 Fuel Injection Pump Gp
274-4962 Fuel Injection Pump Gp
326-8993 Fuel Injection Pump Gp
326-9147 Fuel Injection Pump Gp
368-5413 Fuel Injection Pump Gp
501-4461 Fuel Priming Pump and Primary Filter Gp Replace failed part with new part for your machine.Solution
Before replacing the fuel injection pump, the following actions can be performed to help ensure that the low-pressure fuel system is in good condition.
There is fuel in the fuel tank
Inspect the fuel filter for excess contamination, if necessary, install a new fuel filter
Check the fuel strainer in the bottom of the fuel tank is not blocked or damaged
Check that the fuel lift pump is delivering fuel to the fuel injection pump.
Check that the fuel tank has been regularly drained of any water contamination, and is clear of any debris that could be restricting the fuel flow. See the Operation and Maintenance Manual for correct maintenance practices.All these issues can cause low fuel pressure problems that could lead to thinking the fuel injection pump is faulty. If the low-pressure fuel system is working correctly, then inspect the fuel injection pump for water damage. Refer to special instruction REHS3767. If the fuel injection pump contains rust, then the root cause of the problem is water in the fuel supply.If necessary, a replacement fuel injection pump may be obtained. Refer to disassembly and assembly, "Fuel Injection Pump - Install" for the correct procedure to install a replacement fuel injection pump.Ensure that the fuel supply is clean and the fuel tank does not contain any water or contamination before installing a new Fuel Injection Pump. Also, replace the fuel filter. If a failure occurs, report the failure to the product group by completing a CPI Feedback Form at the Service Information Management System (SIMSi). Reference CPI 373959 and TIB , M0082583 in the form. The link to SIMSi can be found on the Caterpillar Service Information System (SIS).Note: For machines equipped with 501-4461 Fuel Priming Pump and Primary Filter Gp which has an extra water separation volume. Itis recommended to remove any aftermarket water separator.
