August 31, 2004
O-219
Priority PRODUCT IMPROVEMENT PROGRAM FOR REPLACINGTHE INJECTION ACTUATION PRESSURE SENSOR ON CERTAIN 3126E ENGINES
7755,1925 PI30676
This Program must be administered assoon as possible. When reporting the repair, use "PI30676" as the Partnumber and "7751" as the Group Number, "56" as the Warranty Claim DescriptionCode and "T" as the SIMS Description Code. Exception: If the repair isdone after failure, use "PI30676" as the Part Number, "7751" as the GroupNumber, "96" as the Warranty Claim Description Code, and "Z" as the SIMSDescription Code. The information supplied in this serviceletter may not be valid after the termination date of this program. Donot perform the work outlined in this Service Letter after the terminationdate without first contacting your Caterpillar product analyst.
COMPLETION DATE
TERMINATION DATE
February 28, 2005 August 31, 2005PROBLEM
Replace the injection actuation pressure sensorcertain 3126E engines. The old sensor may leak oil.AFFECTED PRODUCT
Model IdentificationNumber
3126E G3E230-497PARTS NEEDED
Qty
Part Number Description
1 2244536 SENSOR GP-PRACTION REQUIRED
Remove the 194-6726 Pressure Sensor and replaceit with part number 224-4536 Pressure Sensor.OWNER NOTIFICATION
U.S. and Canadian owners will receive the attachedOwner Notification.SERVICE CLAIM ALLOWANCES
Caterpillar Dealer Suggested Customer Suggested
Parts Labor Hrs Parts LaborHrs Parts LaborHrs
100% 1.0 0 0 0 0
This is a 1.0-hour job. U.S. and Canadian Dealers Only - Eligibledealers may enter a Type 2 SIMS ReportPARTS DISPOSITION
Handle the parts in accordance with your WarrantyBulletin on warranty parts handling.MAKE EVERY EFFORT TO COMPLETE THIS PROGRAMAS SOON AS POSSIBLE.Attach. (Owner Notification)COPY OF OWNER NOTIFICATION FOR U.S. AND CANADIAN OWNERS
XYZ Corporation
3240 Arrow Drive
Anywhere, YZ 99999PRIORITY - THE INJECTION ACTUATION PRESSURESENSOR NEEDS TO BE REPLACED.MODELS INVOLVED - CERTAIN 3126E ENGINESDear Caterpillar Product Owner:A new injection actuation pressure sensor needsto be installed on the products listed below. The current sensor may leakoil. You will not be charged for the service performed.Contact your local Caterpillar dealer immediatelyto schedule this service. The dealer will advise you of the time requiredto complete this service. Please refer the dealer to their Service Letterdated August 31, 2004 when scheduling this service.We regret the inconvenience this may causeyou, but urge you to have this service performed as soon as possible toprevent unscheduled downtime.Caterpillar Inc.
Identification #(s)Attached to August 31, 2004 Service Letter
