PROBLEM
The existing diesel exhaust fluid manifold can fail on certain 2570D, 2670D, 563D, and 573D Wheel Feller Bunchers, and 525D, 535D, 545D, and 555D Wheel Skidders. If the existing DEF manifold fails it can lead to inducements and eventual engine shutdown.
AFFECTED PRODUCT
Model Identification Number
2570D D2500112-00114
2670D D2600208-00211
525D GKP00477-00524, 527
535D MTP00386-00448, 450-453
545D KGP00254-00284, 287
555D PGY00153-00159
563D D6300115-00146
573D D7300209-00226
PARTS NEEDED
Qty
Part Number Description
1 3915262 GASKET
1 5280527 MANIFOLD GP
1 DCUSOFTWARE DCU SOFTWARE
1 ENGSOFTWARE ENGINE SOFTWARE
In order to allow equitable parts availability to all participating dealers, please limit your initial parts order to not exceed 29% of dealership population. This is an initial order recommendation only, and the ultimate responsibility for ordering the total number of parts needed to satisfy the program lies with the dealer.
ACTION REQUIRED
Update the Engine and DCU software files to the latest available in SIS Web. Replace the existing diesel exhaust fluid manifold with the 528-0527 diesel exhaust fluid manifold. Use a new 391-5262 gasket when installing a new manifold.
SERVICE CLAIM ALLOWANCES
Product smu/age whichever comes first Caterpillar Dealer Suggested Customer Suggested
Parts % Labor Hrs% Parts % Labor Hrs% Parts % Labor Hrs%
0-6000 hrs,
0-36 mo 100.0% 100.0% 0.0% 0.0% 0.0% 0.0%
6001-8000 hrs,
37-48 mo 33.0% 50.0% 0.0% 0.0% 50.0% 50.0%
This is a 2.0-hour job
PARTS DISPOSITION
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
