19100-05791 PUMP ASSY, INJECTI Denso Cross




Information pump assy, injecti

19100-05791 PUMP ASSY, INJECTI
Rating:
56
Buy PUMP ASSY, INJECTI 19100-05791 genuine, new aftermarket engine parts with delivery

Components :

001. PUMP ASSY, INJECTI 19100-05791
002. BODY ASSY, INJECTI 09010-04232
003. COVER, BEARING 09020-10410
004. TIMER ASSY, AUTOMA 09180-01210
005. PUMP ASSY, FUEL FE 09210-00920
006. COUPLING ASSY 09250-00270
007. GOVERNOR ASSY, MEC 19080-01530
008. SWITCH KIT, CONTRO 09009-90390

Scheme ###:

000. [01] 19100-05791 PUMP ASSY, INJECTI 22010-5451
004. [01] 09031-00130 VALVE ASSY, OVERFL 22107-1090A
005. [02] 94901-02480 WASHER 22847-1940A
006. [01] 09001-80290 COVER, CONTROL RAC 22114-1020A
007. [06] 94904-70620 BOLT, W/WASHER 22815-1620A
008. [01] 09010-04232 BODY ASSY, INJECTI 22110-1590C
009. [01] 09210-00920 PUMP ASSY, FUEL FE 22570-1250A
010. [01] 19080-01530 GOVERNOR ASSY, MEC 22310-3740A
011. [01] 94904-73910 BOLT, W/WASHER 22815-2820A
012. [01] 94913-00210 KEY, WOODRUFF 22895-1010A
013. [01] 09250-00270 COUPLING ASSY 22610-1080A
014. [01] 09001-20180 NUT, TIMER ROUND 22511-1070A
015. [01] 09180-01210 TIMER ASSY, AUTOMA 22510-1190A
016. [01] 94901-50590 WASHER, SPRING 22877-1620A
017. [02] 09028-50030 CAP 22323-1210A

Include in #3:

19100-05791 as PUMP ASSY, INJECTI

Cross reference number



Part num Firm num Firm Name
19100-05791  22010-5451  PUMP ASSY, INJECTI




Information:


1-1The serial No. is stamped both on the maker's nameplate (Fig. 1-1) and the crankcase.
1-3Engines of the F3/4/5/6L type have the serial number stamped at the back of the oil filler neck, on the flange for mounting the housing of the fuel injection pump.Fig. 1-3Maker's Nameplate
In addition to the engine serial No., the plate indicates the particular engine model and version respectively. Typical example BF6L 913 C:B = Engine with turbochargerF = Automotive or industrial engine6 = Number of cylindersL = Air-cooled9 = Number of series13 = Stroke of piston in cmThe suffix letters of the engine model designation mean:C = With charge air coolerG = Engine for fork-lift truckT = Mildly turbochargedW = Two-stage combustion system (swirl chamber)Further data of the nameplate:Rated power in kW (HP) and speed in rev/min. Letter "A" denotes continuous power (with overload capacity), both according to DIN 6270.De-rated industrial engines have an additional rating plate.The rating for automotive engines refers to DIN 70020.General Notes On Repair
To be successful, every repair job calls for precision workmanship, in clean and neat surroundings.
1-5The "front end" of the engine is understood to be the end opposite the flywheel, and the other engine faces are designated accordingly. Thus: Cylinder No. 1 is at the rear end = at the flywheel end. The cylinder numbers are applied to the crankcase, below the cylinder seating area. The sense of rotation of the engine is anti-clockwise, when facing the flywheel.Fig. 1-5
1-6The parts of the crankshaft assembly, timing gear, cylinders, pistons and cylinder heads should be numbered in sequence, unless they are already marked. The numbering should commence at the flywheel end.Fig. 1-6As the parts are dismantled, place them where they will not get damaged. Components that are subject to wear should be kept apart and should be gauged individually. If the low tolerances are exceeded, the components have to be replaced or rectified. In any case, fit new gaskets, packings and O-seals.The numbers of spare parts should be taken from the part number catalogue for the respective engine type. A good repair job that is to ensure satisfactory engine performance essentially calls for the use of genuine DEUTZ spare parts.Should bearing or pistons be damaged, the crankshaft and connecting rods should be inspected for cracks, if possible by the Magnaflux testing method. It is very important that the cause of the damage is established. Testing, repairs and/or reworking can be undertaken by the manufacturers or their appointed repair shops.
1-8For the repair work to be carried out on the removed engine, mounting on a swivelling assembly stand, special fixture No. 6067, is recommended.Fig. 1-8Tightening Instructions For Bolts And Studs
All bolts and studs tabulated shall first be hand-tightened to approx 30 Nm and then locked down alternately in stages until the specified angle degrees are obtained. Before assembling the bolts and studs, wet the threads and the bearing faces of the heads with motor oil. 1. Preloading
1-9Hold wrench so the thumb touches the end.Fig. 1-9Use a torque wrench for torques above 30
