19010-01123 BODY ASSY, INJECTI Denso Cross




Information body assy, injecti

19010-01123 BODY ASSY, INJECTI
Rating:
6
Buy BODY ASSY, INJECTI 19010-01123 genuine, new aftermarket engine parts with delivery

Scheme ###:

BODY ASSY, INJECTI
000. [01] 19010-01123 BODY ASSY, INJECTI
001. [01] 09011-04431 HOUSING SUB-ASSY,
001. [01] 09011-05730 HOUSING SUB-ASSY,
001-001. [03] 94904-30010 BOLT, STUD 85265-00057
002. [06] 09013-00540 HOLDER SUB-ASSY, D
002. [06] 09013-00311 HOLDER SUB-ASSY, D
003. [06] 09013-60730 SPRING, DELIVERY V
004. [06] 94914-02570 O-RING 94914-02570
005. [06] 09014-02440 VALVE SUB-ASSY, IN
006. [06] 09015-05354 ELEMENT SUB-ASSY,
006. [06] 09015-06460 ELEMENT SUB-ASSY,
007. [06] 09016-00150 SLEEVE SUB-ASSY, C 09016-00150
008. [01] 09021-20700 RACK, CONTROL
009. [06] 09016-30160 SEAT, SPRING, UPR 09016-30160
010. [06] 09016-40250 SPRING, PUMP PLUNG
011. [06] 09016-50150 SEAT, SPRING, LWR
012. [06] 09017-00320 TAPPET SUB-ASSY,IN
013. [ C] 09043-80471 SHIM, ELEMENT HOLD
013. [ C] 09043-80481 SHIM, ELEMENT HOLD
013. [ C] 09043-80491 SHIM, ELEMENT HOLD
013. [ C] 09043-80501 SHIM, ELEMENT HOLD
013. [ C] 09043-80901 SHIM, ELEMENT HOLD
013. [ C] 09043-80911 SHIM, ELEMENT HOLD
013. [ C] 09043-80461 SHIM, ELEMENT HOLD
013. [ C] 09043-80451 SHIM, ELEMENT HOLD
013. [ C] 09043-80441 SHIM, ELEMENT HOLD
013. [ C] 09043-80431 SHIM, ELEMENT HOLD
013. [ C] 09043-80421 SHIM, ELEMENT HOLD
013. [ C] 09043-80411 SHIM, ELEMENT HOLD
013. [ C] 09043-80401 SHIM, ELEMENT HOLD
013. [ C] 09043-80391 SHIM, ELEMENT HOLD
014. [12] 90196-08651 NUT, HEXAGON
015. [12] 94901-35880 WASHER, PLATE, SK
016. [12] 90258-08001 WASHER, SPRING CSA915D100
017. [01] 09020-60240 GASKET, BEARING CO
018. [18] 09013-90020 O-RING
018. [12] 09013-90340 O-RING
019. [06] 94901-81730 WASHER, COPPER PLA
020. [01] 09019-11560 CAMSHAFT, INJECTIO
021. [01] 94910-10140 BEARING, ROLLER
022. [01] 09019-30050 RING, CAMSHAFT ADJ
023. [3C] 09019-40070 PLATE, CAMSHAFT SH 09019-40070
023. [3C] 09019-40410 PLATE, CAMSHAFT SH
023. [3C] 09019-40360 PLATE, CAMSHAFT SH
023. [3C] 09019-40350 PLATE, CAMSHAFT SH
023. [3C] 09019-40340 PLATE, CAMSHAFT SH
023. [3C] 09019-40100 PLATE, CAMSHAFT SH 09019-40100
023. [3C] 09019-40090 PLATE, CAMSHAFT SH 09019-40090
023. [3C] 09019-40080 PLATE, CAMSHAFT SH 09019-40080
025. [01] 94915-02820 SEAL, OIL
026. [01] 09020-10501 COVER, BEARING
027. [04] 91418-06201 BOLT, W/WASHER 91418-06201
028. [01] 09043-30020 RETAINER, BEARING
029. [01] 09036-10180 BEARING, CENTER 09036-10180
029. [01] 09036-10240 BEARING, CENTER
030. [02] 94900-66510 SCREW
030. [02] 94900-67300 SCREW
031. [04] 09024-80010 WASHER, DRAIN SCRE 09024-80010
032. [01] 09021-50060 SCREW, RACK GUIDE 09021-50060
033. [01] 09031-70140 PLUG, SCREW
034. [01] 94910-10130 BEARING, ROLLER
035. [01] 09019-30060 RING, CAMSHAFT ADJ
036. [04] 09022-20070 WASHER, FUEL PIPE 85265-00079
038. [01] 94918-00310 SCREW, HOLLOW 85265-00078
038. [01] 09024-50390 SCREW, HOLLOW
039. [3C] 09019-40420 PLATE, CAMSHAFT SH
039. [3C] 09019-40390 PLATE, CAMSHAFT SH
039. [3C] 09019-40380 PLATE, CAMSHAFT SH
039. [3C] 09019-40370 PLATE, CAMSHAFT SH
039. [3C] 09019-40330 PLATE, CAMSHAFT SH
039. [3C] 09019-40320 PLATE, CAMSHAFT SH
039. [3C] 09019-40310 PLATE, CAMSHAFT SH
039. [3C] 09019-40300 PLATE, CAMSHAFT SH
040. [02] 09011-40110 BUSHING, CONTROL R
041. [01] 09036-70040 BUSHING, CONTROL R
046. [01] 94914-00380 O-RING 85265-00084
047. [03] 90258-06001 WASHER, SPRING 90258-06001
048. [03] 90160-06051 NUT, HEXAGON 85265-00085
049. [02] 09024-40160 SCREW, AIR BLEEDER
055. [01] 09031-00210 VALVE ASSY, OVERFL
059. [01] 94901-80350 WASHER, COPPER PLA 94901-80350

Include in #3:

09200-02612 as BODY ASSY, INJECTI
19010-01123

Cross reference number



Part num Firm num Firm Name
19010-01123    BODY ASSY, INJECTI




Information:

References
Safety
Before starting the procedure of mounting the fuel injection pump and tooling onto the test stand, make sure the Emergency Stop button is pushed IN. Another recommended safety precaution is to turn the power OFF and lock-out the electrical box. An SEHS7332 "Warning: Do Not Operate" tag should also be placed on the electrical box.
Illustration 1. Place Tag On Electrical Box When Working On Or Around Rotating PartsNomenclature
135-2916 Adapter Group
The parts in Charts A, B, and C are part of the 135-2916 Adapter Group and required to test 3406B, 3406C, and 3406 PEEC Engines.
Illustration 2. 135-2916 Adapter Group (front mounting hardware). Refer to Chart A for item identification.
Illustration 3. 135-2916 Adapter Group (rear mounting hardware). Refer to Chart B for item identification.
Illustration 4. 135-2916 Adapter Group (injection pump hardware). Refer to Chart C for item identification.
Illustration 5. Front and rear support clamping hardware. (Common to many mounting groups.) Drive Adapters
The drive adapters listed in Chart E are used on the original 25 mm (1.0 in) 4C-8723 Jaw Assembly or the new 4C-8192 Heavy-Duty Coupling Group. Refer to the Installation section and the charts below to determine the correct adapter. Refer to Charts F and G and Illustrations 6 and 7 for a list of drive adapters and associated hardware.
Illustration 6. Drive adapters with 25 mm (1.0 in) shaft diameters for use with 4C-8723 Jaw Assembly. Refer to Chart F for item identification.
Illustration 7. Drive adapters for use with 4C-8192 Heavy-Duty Coupling and Torque Tube. Refer to Chart G for item identification. Required Pump Testing Tooling
Illustration 8. Rack preload and positioning assembly for 3406 PEEC Engines. Refer to Chart H for item identification.
Illustration 9. Injection Pump Testing Tooling. Refer to Chart I for item identification.
Illustration 10. TMI screen. Refer to procedure below to obtain pump specifications.TMI Specifications
Delivery specifications are published "on-line" in TMI. To access these specifications, use the following procedure. For additional information on TMI, refer to NEHS0594.Finding Test Specification Data When Engine Arrangement Level, Pump Group, and Governor Group Part Numbers Are Known
The Step numbers below correspond to the item callouts in Illustration 11.1. Type "GNK401". The cursor will automatically move to the next field.2. Type in "12". Press "Enter".3. Type in the pump part number in the "ARRG/GP NUMBER" field and press "Enter". This example shows a 6I-3060 part number.4. Find the correct line number.5. Type in the line number; "011". Press "Enter".6. Scroll through the data using the "Enter" key.Installation
This procedure was written using the 4C-8192 Heavy-Duty Coupling Group, which is the preferred coupling. Refer to Charts E, F, and G for the correct adapter and associated hardware depending on which coupling group is used on the test stand.1. Push the Emergency Stop button IN.
Make sure the puller hole in the plug is facing out when the plug is installed. If the puller hole is facing in, the plug and possibly the fuel injection pump will be damaged when the plug is removed.
Illustration 11. Install Plug. Example of 8T-2849 Plug.
(A) Hole. (B) Threaded puller hole.
