19000-07312 PUMP ASSY, INJECTI Denso Cross




Information pump assy, injecti

19000-07312 PUMP ASSY, INJECTI
Rating:
13
Buy PUMP ASSY, INJECTI 19000-07312 genuine, new aftermarket engine parts with delivery

Components :

001. PUMP ASSY, INJECTI 19000-07312
002. SWITCH KIT, CONTRO 09009-90300
003. BODY ASSY, INJECTI 09010-04034
004. COVER, BEARING 09020-10410
005. GOVERNOR ASSY, MEC 09080-07161
006. TIMER ASSY, AUTOMA 09180-01210
007. PUMP ASSY, FUEL FE 09210-00920
008. COUPLING ASSY 09250-00270

Scheme ###:

000. [01] 19000-07312 PUMP ASSY, INJECTI 22090-1080
000. [01] 19000-07312 PUMP ASSY, INJECTI 22090-1081
006. [01] 09010-04034 BODY ASSY, INJECTI 22110-1482A
007. [01] 09080-07161 GOVERNOR ASSY, MEC 22310-2210
008. [06] 94904-71150 BOLT, W/WASHER 6 306 1001 00
009. [01] 94904-73910 BOLT, W/WASHER 22815-2820A
011. [01] 09001-80290 COVER, CONTROL RAC 22114-1020A
012. [01] 09180-01210 TIMER ASSY, AUTOMA 22510-1190A
013. [01] 09001-20180 NUT, TIMER ROUND 22511-1070A
014. [01] 94913-00210 KEY, WOODRUFF 22895-1010A
015. [01] 94901-50590 WASHER, SPRING 22877-1620A
016. [01] 09210-00920 PUMP ASSY, FUEL FE 22570-1250A
017. [01] 09006-10020 COVER, PRIMING PUM 22561-1020
018. [01] 09250-00270 COUPLING ASSY 22610-1080A
020. [01] 09031-00130 VALVE ASSY, OVERFL 22107-1090A
022. [02] 94901-02480 WASHER 22847-1940A
023. [03] 90160-06051 NUT, HEXAGON 22825-1480A
024. [03] 90258-06001 WASHER, SPRING 28219-1110A
025. [01] 09009-90300 SWITCH KIT, CONTRO 22690-1200A

Include in #3:

19000-07312 as PUMP ASSY, INJECTI
19000-07312

Cross reference number



Part num Firm num Firm Name
19000-07312  22090-1080  PUMP ASSY, INJECTI
