19000-03500 PUMP ASSY, INJECTI Denso Cross




Information pump assy, injecti

Nozzle: 0935001700
19000-03500 PUMP ASSY, INJECTI
Rating:
43
Buy PUMP ASSY, INJECTI 19000-03500 genuine, new aftermarket engine parts with delivery

KIT List:

Body assy, injecti 1904400300
Pump assy, fuel fe 1922900060

Components :

001. PUMP ASSY, INJECTI 19000-03500
002. BODY ASSY, INJECTI 09010-01762
003. PUMP ASSY, FUEL FE 09210-00561

Scheme ###:

000. [01] 19000-03500 PUMP ASSY, INJECTI 34461-01010
005. [01] 09010-01762 BODY ASSY, INJECTI 30661-51100
006. [01] 09080-05780 GOVERNOR ASSY, MEC
007. [01] 09001-80081 COVER, CONTROL RAC 09001-80081
008. [01] 94905-02450 NUT, HEXAGON 94905-02450
009. [01] 94913-00190 KEY, WOODRUFF 94913-00190
010. [01] 94901-50500 WASHER, SPRING 94901-50500
012. [01] 09210-00561 PUMP ASSY, FUEL FE 30661-51200
013. [06] 94904-70620 BOLT, W/WASHER
014. [01] 90200-06511 WASHER, PLATE

Include in #3:

19000-03500 as PUMP ASSY, INJECTI

Cross reference number



Part num Firm num Firm Name
19000-03500  34461-0101  PUMP ASSY, INJECTI
34461-01010    MITSUBISHI PUMP ASSY, INJECTI




Information:

Start By:a. remove fuel injection lines
Keep all parts clean from contaminants. Contaminants put into the system may cause rapid wear and shortened component life.
1. Remove bolts (1) and fan guard (2). 2. Loosen bolts (7), (9) and (10). Remove belts (8).3. Remove bolt (4) to clip. Remove grease line (3).4. Remove nuts (6). Remove cover (5) and the gasket. 5. Loosen bolt (12) enough to leave a gap of 3.18 mm (.125 in) between washers (11) and the fuel pump drive gear.6. Install tool (A) as shown. Tighten the stud to pull the fuel pump drive gear loose from the taper on the fuel injection pump camshaft.7. Remove tool (A), bolt (12), and washer (11). 8. Identify and disconnect wires (13).9. Remove tube assemblies (15) and (18).10. Remove two bolts (14), fuel transfer pump (17), and the O-ring seal.11. Remove bolts (16), the filter base, the gasket, and filter (19). 12. Fasten the fuel injection pump housing and governor to a hoist.13. Remove two bolts (22), three nuts (21), and the fuel injection pump housing and governor. The weight of the fuel injection pump housing and governor is 29 kg (64 lb.).14. Remove the two O-ring seals from the bottom of the fuel injection pump housing and governor. 15. Loosen screw (25). Remove two screws (26), control assembly (23) and spacers (24).Install Fuel Injection Pump Housing And Governor
Start By:a. remove fuel injection linesb. remove valve cover Number 1 piston must be set at top dead center (TDC) to perform all timing procedures. The engine is seen from the flywheel end when direction of crankshaft rotation is given. 1. Remove the starter.2. Install tool (B) on flywheel housing as shown.3. To find TDC for No. 1 piston;a. Turn the flywheel clockwise (opposite the direction of engine rotation) approximately 30 degrees. This removes all play from the timing gears. If you go past the bolt hole, you must repeat Step (a).b. Turn the flywheel counterclockwise until a 3/8" - 16 x 2 1/4" NC bolt (27) can be installed in the flywheel through the hole in the flywheel housing. The No. 1 and No. 6 pistons are now at top center position. The No. 1 piston is on the compression stroke when the valves of the No. 1 cylinder are closed. The rocker must be free to move up and down.4. If No. 1 piston is not on the compression stroke, remove the 3/8" - 16 x 2 1/4" NC bolt (27) and turn the flywheel 360° counterclockwise. Install the 3/8" bolt as before. The No. 1 piston is now at TDC.
Typical Example5. Install tooling (C) in the fuel injection pump housing as shown. Push on tooling (C) and turn injection pump camshaft (32). When tooling (C) engages the groove (slot) in the camshaft, the fuel injection pump is in the No. 1 piston TDC position.6. Be sure O-ring seals (28), (29), (30) and (31) are in position on the fuel injection pump housing and governor. Put clean engine oil
