09801-00010 OVER-HAUL KIT, DIS Denso Cross




Information over-haul kit, dis

09801-00010 OVER-HAUL KIT, DIS
Rating:
5
Buy OVER-HAUL KIT, DIS 09801-00010 genuine, new aftermarket engine parts with delivery

Components :

001. OVER-HAUL KIT, DIS 09801-00010

Scheme ###:

000. [01] 09801-00010 OVER-HAUL KIT, DIS
013. [01] 09822-90010 GASKET, TIMER PLUG
014. [01] 09806-60060 O-RING, DISTRIBUTI
019. [01] 09805-00011 FILTER SUB-ASSY
020. [01] 09604-90460 O-RING 22193-5B320
021-001. [01] 02947-50170 O-RING
024. [01] 09806-60010 O-RING, DISTRIBUTI
034. [01] 09806-60080 O-RING, DISTRIBUTI
035. [01] 09806-60090 O-RING, DISTRIBUTI
036. [01] 09806-90010 RING, BACKUP
037. [01] 09806-60050 O-RING, DISTRIBUTI
040. [01] 09806-60100 O-RING, DISTRIBUTI
042. [01] 09642-60030 GASKET, DELIVERY V 22149-56200
043-001. [01] 09806-60030 O-RING, DISTRIBUTI 22193-1C170
044-001. [01] 09604-90530 O-RING
046. [01] 09806-60070 O-RING, DISTRIBUTI
047. [01] 09806-50010 GASKET
050. [06] 09846-60011 GASKET, DELIVERY V
057. [01] 09806-60110 O-RING, DISTRIBUTI
060. [01] 09806-60040 O-RING, DISTRIBUTI
062-001. [01] 09806-60030 O-RING, DISTRIBUTI 22193-1C170
062-002. [01] 09806-60020 O-RING, DISTRIBUTI
064. [01] 09806-60030 O-RING, DISTRIBUTI 22193-1C170
066. [04] 09642-60120 GASKET, DELIVERY V 22149-54800
073. [01] 09808-10010 COVER, RUBBER
074. [01] 09808-10020 COVER, RUBBER
075. [01] 09646-80070 CAP RUBBER
076. [06] 09001-40012 CAP, VALVE HOLDER

Include in #3:

Cross reference number



Part num Firm num Firm Name
09801-00010    OVER-HAUL KIT, DIS

Use as kit:

0980000010 0980000010 Pump assy, injecti 0980100010
0980000200 0980000200 Pump assy, injecti 0980100010
0980000330 0980000330 Pump assy, injecti 0980100010
0980000340 0980000340 Pump assy, injecti 0980100010
0980000550 0980000550 Pump assy, injecti 0980100010
0980001020 0980001020 Pump assy, injecti 0980100010
0980002010 0980002010 Pump assy, injecti 0980100010
0980002020 0980002020 Pump assy, injecti 0980100010
0980002200 0980002200 Pump assy, injecti 0980100010




Information:

2. Remove nuts (1) from studs for main bearing caps (2).3. Remove the main bearing caps.4. Install rubber hose over each of the two studs at both ends of the block. This will protect the crankshaft during removal and installation. 5. Remove the crankshaft from the cylinder block. Weight of crankshaft is 300 lb. (136 kg).6. Remove the main bearings from cylinder block and main bearing caps.
If main bearings are not replaced, old bearings must be installed in same location from which they were removed.
Install Crankshaft
1. Put timing marks (1) on all timing gears in alignment.2. Clean surfaces for bearings in cylinder block. Install upper halves of bearings in block. Put clean oil on bearings.
If replacement of the bearings is not made, old bearings must be installed in same location from which they were removed.
3. Clean bearing caps, and install lower halves of bearings in caps. 4. Fasten a hoist to crankshaft and put it into place in the block with "V" mark on crankshaft gear in alignment with "V" mark on cluster gear. 5. Check bearing clearance with wire (A). Install bearing caps, and tighten both nuts to 75 5 lb. ft. (101.7 6.8 N m). Put a mark across the nuts and studs, and turn nuts an additional 120° from mark. Remove caps and check thickness of wire (A) to find bearing clearance. Bearing clearance must be .0035 to .0066 in. (0.089 to 0.168 mm) for new parts. Maximum permissible clearance for used parts is .010 in. (0.25 mm).6. Put clean oil on threads of studs, face of nuts, and lower halves of bearings. Put bearing caps in their respective positions with number on cap same as number on block, and groove in bearing cap on same side as groove in cylinder block. Install nuts and tighten to 75 5 lb.ft. (101.7 6.8 N m). Put a mark across the nuts and studs, and turn nuts an additional 120° from mark. 7. Use indicator group (B) to check the crankshaft end plate as controlled by lower bearing of No. 7 bearing cap. End play with new parts should be .006 to .018 in. (0.15 to 0.46 mm). Maximum permissible end play with used parts is .035 in. (0.89 mm).end by: a) install flywheel housingb) install front coverc) install pistonsd) install engine and torque divider
