Information pump assy, injecti
Rating:
Components :
| 001. | PUMP ASSY, INJECTI | 09450-03780 |
Scheme ###:
| 000. | [01] | 09450-03780 | PUMP ASSY, INJECTI | 19090-12401 |
| 001. | [01] | 09011-01721 | HOUSING SUB-ASSY, | 14911-51081 |
| 002. | [01] | 09013-10280 | HOLDER, DELIVERY V | 15601-51221 |
| 002. | [01] | 09013-10520 | HOLDER, DELIVERY V | |
| 003. | [01] | 09013-60230 | SPRING, DELIVERY V | 15221-51231 |
| 004. | [01] | 09013-70061 | GASKET, DELIVERY V | 15221-51241 |
| 004. | [01] | 09013-70130 | GASKET, DELIVERY V | 11420-51241 |
| 005. | [01] | 09014-00410 | VALVE SUB-ASSY, IN | 15221-51031 |
| 006. | [01] | 09015-03870 | ELEMENT SUB-ASSY, | |
| 008. | [01] | 09016-30082 | SEAT, SPRING, UPR | 15221-51271 |
| 009. | [01] | 09016-40170 | SPRING, PUMP PLUNG | 15221-51281 |
| 010. | [01] | 09016-10210 | SLEEVE, PLUNGER CO | 15221-51382 |
| 011. | [01] | 09017-00170 | TAPPET SUB-ASSY,IN | 15221-51071 |
| 011-001. | [01] | 09017-10022 | TAPPET, INJECTION | 15021-51990 |
| 011-002. | [01] | 09217-60010 | ROLLER, FEED PUMP | 15109-52931 |
| 011-003. | [01] | 09017-60020 | PIN, INJECTION PUM | 15021-51970 |
| 012. | [01] | 09021-00342 | RACK ASSY, CONTROL | 14911-51061 |
| 015. | [01] | 94918-00610 | SCREW, HOLLOW | 14911-51321 |
| 016. | [02] | 09024-10010 | WASHER, AIR BLEEDE | 15021-51481 |
| 017. | [01] | 09018-30041 | PIN, INJECTION PUM | 15221-51251 |
| 017. | [01] | 09018-30130 | PIN, INJECTION PUM | |
| 018. | [01] | 09030-10060 | SEAT, SPRING, LWR | 14109-51290 |
| 019. | [01] | 94907-20830 | RING, SNAP | 14911-51431 |
| 020. | [01] | 09013-90410 | O-RING | |
| 020. | [01] | 90802-20150 | O-RING | 14611-51201 |
| 022. | [1C] | 09031-10300 | PLATE, TAPPET ADJU | |
| 022. | [1C] | 09031-10280 | PLATE, TAPPET ADJU | |
| 022. | [1C] | 09031-10170 | PLATE, TAPPET ADJU | |
| 022. | [1C] | 09031-10160 | PLATE, TAPPET ADJU | |
| 022. | [1C] | 09031-10140 | PLATE, TAPPET ADJU | |
| 022. | [1C] | 09031-10130 | PLATE, TAPPET ADJU | 15221-51491 |
| 022. | [1C] | 09031-10120 | PLATE, TAPPET ADJU | |
| 022. | [1C] | 09031-10110 | PLATE, TAPPET ADJU | |
| 022. | [1C] | 09031-10010 | PLATE, TAPPET ADJU | 14109-51301 |
| 022. | [1C] | 09031-10310 | PLATE, TAPPET ADJU |
Include in #3:
09450-03780
as PUMP ASSY, INJECTI
Cross reference number
| Part num | Firm num | Firm | Name |
| 09450-03780 | 19090-1240 | PUMP ASSY, INJECTI | |
| 19090-12401 | KUBOTA | PUMP ASSY, INJECTI |
Information:
Illustration 1 g06045444
Typical example
Illustration 2 g03821967
Typical example
(3) Existing fuel injection pump
(4) Existing advance boxA new fuel injection pump (1) has been introduced. The new fuel injection pump has an improved design of advance box (2) that is more robust against air in fuel.Adaptable To: New 483-2326 Fuel Injection Pump replaces 462-8111 Fuel Injection PumpNew 483-2329 Fuel Injection Pump replaces 248-2366 Fuel Injection Pump.To remove the existing fuel injection pump, refer to Disassembly and Assembly, "Fuel Injection Pump - Remove" for the correct procedure.To install a new fuel injection pump, refer to Disassembly and Assembly, "Fuel Injection Pump - Install" for the correct procedure.Ensure that the fuel system is primed. Refer to Service Magazine, SEPD1541, "Alternative Fuel System Prime Procedure for 3054C, C4.4 (Mech), and C3.3 Machine Engines with a Delphi Fuel Injection Pump Installed".
