2-12.2 Turn the crankshaft in the direction of engine rotation until the valves opposite the cylinder to be adjusted overlap.Fig. 2-1 and table below
2-2 Note for Refitment:The exhaust valve is left-hand as viewed from the exhaust air side.Fig. 2-2
2-33. Release locknut of adjusting screw and adjust rocker arm/valve stem clearance.Retighten locknut.Fig. 2-34. Recheck clearance and readjust if necessary.
2-45. Apply sealing compound to new gaskets for rocker chamber cover(s) and fit cover(s).Fig. 2-4 Checking The Compression Pressure
The specified pressure applies to min. 150/min starting speed of engine and 20°C reference temperature at sea-level. Prior to checking, run up engine briefly to medium speed, so the combustion chamber will be sufficiently sealed by an oil film. Perform check at zero delivery of injection pump.
2-51. Remove injector and in its place insert and secure adapter with seal.Fig. 2-5, left Attention:In the case of FL 912 W, remove heater plug and in its place insert adapter for compression pressure recorder.Fig. 2-5, right
2-62. Connect compression pressure gauge.Fig. 2-6
2-73. Take the compression pressure reading.Fig. 2-7
2-8 Important:Check that the individual compression pressures are within the range specified and about equal for all cylinders. Any deviations in pressure between cylinders should not exceed 15%.Fig. 2-8Determining TDC With Setting Device
1. Remove No. 1 rocker chamber cover.2. Turn crankshaft until valves overlap, then give crankshaft another half turn.
