Illustration 1 g00857824
(1) Side Panel (2) Keyboard Port (3) Mouse Port (4) Mouse (5) KeyboardConnecting A Mouse And Keyboard
Plug the mouse (4) into the mouse port (3) on the side panel (1). Plug the keyboard (5) into the keyboard port (2) on the side panel (1) .DC Power Connections
A standard three-position terminal block is provided for connecting power. Use 12 AWG stranded wire or use 14 AWG stranded wire in order to connect the terminals to a 24 VDC power supply that is stable. The 24 VDC power supply must have a minimum rating of 10 A. Observe the proper polarity. The wiring should be less than 3 meters in length. Ensure that the wires are connected correctly by using standard wiring practices. Twist the wires 1 to 3 twists per inch.Note: The ground connection must be made to an adequate earth ground. Use a short length of wire. A short length of wire eliminates the possibility of radio frequency noise and interference.
Illustration 2 g00857922
Terminal BlockNetwork Connections
The monitor accommodates CAT5 twisted pair Ethernet cables. The cables have RJ45 connectors in order to support 100Mbps network data transfer.Note: The performance of the Ethernet communications will degrade if the unit is exposed to extreme radiated noise or conducted high frequency noise. The performance of the Ethernet communications will degrade if the cables are exposed to extreme radiated noise or conducted high frequency noise. The user is responsible for properly routing the cables. The user is responsible for conditioning the input power in order to improve the reliability of communication. Note: Proper routing of the cable and proper conditioning of the power is required in order to ensure reliable Ethernet communications in industrial environments. All cables should be routed through dedicated metal conduits. Installing ferrite bead filters at cable ends may also improve reliability.
