Information pump assy, injecti
Rating:
Components :
| 001. | PUMP ASSY, INJECTI | 09300-03971 |
| 001. | PUMP ASSY, INJECTI | 09300-03971 |
| 002. | BODY ASSY, INJECTI | 09010-08960 |
| 003. | GOVERNOR ASSY, MEC | 09130-01892 |
| 004. | COVER ASSY, GOVERN | 09145-00231 |
| 005. | COVER ASSY, GOVERN | 09145-00881 |
| 006. | TIMER ASSY, AUTOMA | 09180-02450 |
| 007. | PUMP ASSY, FUEL FE | 09210-01551 |
Scheme ###:
| 000. | [01] | 09300-03970 | PUMP ASSY, INJECTI | ME016973 |
| 000. | [01] | 09300-03971 | PUMP ASSY, INJECTI | ME016973 |
| 001. | [01] | 09010-08960 | BODY ASSY, INJECTI | ME728234 |
| 002. | [01] | 09180-02450 | TIMER ASSY, AUTOMA | ME703463 |
| 003. | [01] | 09006-00320 | COVER SUB-ASSY, TI | ME703649 |
| 004. | [01] | 94914-02840 | O-RING | MH035502 |
| 005. | [04] | 94901-15020 | WASHER, STEEL PLAT | MH005068 |
| 006. | [04] | 90258-10001 | WASHER, SPRING | MC843842 |
| 007. | [04] | 91266-10081 | NUT, HEXAGON | MF430122 |
| 008. | [01] | 09130-01892 | GOVERNOR ASSY, MEC | ME703461 |
| 009. | [01] | 09210-01551 | PUMP ASSY, FUEL FE | ME703037 |
| 013. | [01] | 94913-00210 | KEY, WOODRUFF | ME702047 |
| 014. | [01] | 94901-40210 | WASHER, COUNTERSUN | ME702043 |
| 015. | [01] | 09001-20220 | NUT, TIMER ROUND | ME702033 |
| 016. | [01] | 09001-80090 | COVER, CONTROL RAC | ME702251 |
| 017. | [05] | 94904-72690 | BOLT, W/WASHER | ME702045 |
| 018. | [01] | 91418-06201 | BOLT, W/WASHER | ME702041 |
| 019. | [01] | 94904-73910 | BOLT, W/WASHER | ME703449 |
| 023. | [01] | 09221-70570 | NIPPLE, SWIVEL | ME728184 |
Include in #3:
09300-03971
as PUMP ASSY, INJECTI
Cross reference number
| Part num | Firm num | Firm | Name |
| 09300-03971 | ME016973 | PUMP ASSY, INJECTI |
