09250-00670 COUPLING ASSY Denso Cross




Information coupling assy

09250-00670 COUPLING ASSY
Rating:
52
Buy COUPLING ASSY 09250-00670 genuine, new aftermarket engine parts with delivery

Scheme ###:

000. [01] 09250-00670 COUPLING ASSY 22610-1580
001. [01] 09241-50612 FLANGE, COUPLING 22611-1520A
002. [01] 09243-70270 COUPLING, CROSS 22815-2840A
004. [02] 09246-00051 PLATE SUB-ASSY, CO 22601-1200A
005. [02] 94904-06640 BOLT, HEXAGON 22815-2580A
006. [02] 94904-06361 BOLT, HEXAGON 22865-2460A
006. [06] 94904-06361 BOLT, HEXAGON 22865-2460A
007. [04] 94904-06630 BOLT, HEXAGON 22815-2860A
010. [01] 09243-30150 BOLT, HEXAGON 22815-1930A
011. [02] 09243-10130 NUT, COUPLING FLAN 22825-1960A
011. [02] 09243-10181 NUT, COUPLING FLAN
012. [01] 09255-10490 BLOCK, COUPLING

Include in #3:

09250-00670 as COUPLING ASSY

Cross reference number



Part num Firm num Firm Name
09250-00670  22610-1580  COUPLING ASSY
22610-1580A    HINO COUPLING ASSY
22610-1580    HINO COUPLING ASSY
