09250-00631 COUPLING ASSY Denso Cross




Information coupling assy

09250-00631 COUPLING ASSY
Rating:
23
Buy COUPLING ASSY 09250-00631 genuine, new aftermarket engine parts with delivery

Scheme ###:

000. [01] 09250-00631 COUPLING ASSY 22610-1471
001. [01] 09241-50431 FLANGE, COUPLING 22611-1270A
002. [01] 09243-70240 COUPLING, CROSS 22615-1230A
002. [01] 09243-70270 COUPLING, CROSS 22815-2840A
004. [02] 09246-00051 PLATE SUB-ASSY, CO 22601-1200A
005. [02] 94904-06640 BOLT, HEXAGON 22815-2580A
006. [04] 94904-06630 BOLT, HEXAGON 22815-2860A
006. [04] 94904-06361 BOLT, HEXAGON 22865-2460A
007. [02] 90258-10001 WASHER, SPRING 28219-1120A
008. [02] 94904-06630 BOLT, HEXAGON 22815-2860A
009. [02] 94905-04530 NUT, HEXAGON 22825-1750
010. [01] 09243-30150 BOLT, HEXAGON 22815-1930A
011. [02] 09243-10130 NUT, COUPLING FLAN 22825-1960A
011. [02] 09243-10181 NUT, COUPLING FLAN

Cross reference number



Part num Firm num Firm Name
09250-00631  22610-1471  COUPLING ASSY




Information:

2. Turn the crankshaft until two pistons are at bottom center.3. Remove bolts (1) and the bearing caps. Push the rods and pistons up until the rings are out of the cylinder liners. 4. Remove pistons (2) and connecting rods from the cylinder liners.5. Do Steps 1 through 4 for the remainder of the pistons and connecting rods.Install Pistons & Connecting Rod Assemblies
1. Put clean engine oil on piston rings, connecting rod bearings and cylinder liners. 2. Use Tool (A), and install piston (2) and the connecting rod in the cylinder liner.3. Install the bearing cap on the connecting rod with the number on the side of the bearing cap on the same side and same number as on the connecting rod.4. Put 2P2506 Thread Lubricant on the threads of the bolts. Install the nuts, and tighten them to a torque of 90 8 N m (67 6 lb ft). Put a mark on the nuts and cap, and tighten the nuts an extra 90 5 degrees.5. Do Steps 1 through 4 for the remainder of the pistons and connecting rods.End By:a. install piston cooling tubesb. install oil pumpc. install cylinder head assemblyDisassemble & Assemble Pistons & Connecting Rod Assemblies
Start By:a. remove pistons and connecting rod assemblies 1. Remove bearings (3) from the connecting rod and connecting rod cap.2. Remove retainer ring (1) with Tool (A).3. Remove pin (2) and connecting rod (4) from the piston. 4. Remove piston rings (5) from the piston with Tool (B). Clean the piston ring grooves on the pistons with an acceptable ring groove cleaning tool. See, Use Of Piston Bearing Removal And Installation Tools, Special Instructions, SMHS7295.5. Heat connecting rod (4) in an oven to a temperature of 177° to 260°C (350° to 500° F). Never use a direct flame to heat a connecting rod. 6. Put connecting rod (4) in position on the base plate of Tool (C). Put a new rod pin bearing (6) on the adapter part of Tool (C). The old bearing is pushed out by Tool (C) as the new bearing is installed.7. Use Tool (C) to push the new bearing into the connecting rod until the push adapter of Tool (C) makes full contact with the connecting rod surface.8. Use a pin boring machine to make the rod pin bearing the correct size. The bore in the new rod pin bearing must be 50.830 0.008 mm (2.0012 .0003 in).9. Check the clearance between the ends of the piston rings. See the topic, "Pistons & Rings" in Specifications Manual, SENR6470.10. Install the oil ring spring in the oil ring groove of the piston. The oil ring is to be installed over the spring with the oil ring end gap 180° from the oil ring spring joint.11. Install the oil ring on the piston with tool (B).12. Install the second (intermediate) piston ring with the side that has the identification "UP-2" toward the top of the piston. Use Tool (B) to install
