09200-04700 PUMP ASSY, INJECTI Denso Cross




Information pump assy, injecti

Nozzle: 0935006880
09200-04700 PUMP ASSY, INJECTI
Rating:
30
Buy PUMP ASSY, INJECTI 09200-04700 genuine, new aftermarket engine parts with delivery

KIT List:

Pump assy, fuel fe 1922900070

Components :

001. PUMP ASSY, INJECTI 09200-04700
002. GOVERNOR ASSY, MEC 09130-07060
003. LEVER SET 09129-10331
004. TIMER ASSY, AUTOMA 09180-04140
005. PUMP ASSY, FUEL FE 09210-03190
006. COUPLING ASSY 09250-01130
007. BODY ASSY, INJECTI 19010-01730
008. COVER, BEARING 09020-10430

Scheme ###:

000. [01] 09200-04700 PUMP ASSY, INJECTI 22010-8820
003. [01] 19010-01730 BODY ASSY, INJECTI 22110-3620A
004. [01] 09130-07060 GOVERNOR ASSY, MEC 22310-6760A
005. [01] 09180-04140 TIMER ASSY, AUTOMA 22510-3040A
006. [01] 09001-20340 NUT, TIMER ROUND 22825-2240A
007. [01] 09250-01130 COUPLING ASSY 22610-1890A
008. [01] 90458-05750 KEY, WOODRUFF 22891-1070A
009. [01] 09210-03190 PUMP ASSY, FUEL FE 22570-1750A
010. [01] 09001-80381 COVER, CONTROL RAC 22114-1200A
011. [01] 94901-81550 WASHER, COPPER PLA 96542-2150A
012. [01] 94904-76900 BOLT, W/WASHER 22815-3230A
013. [04] 94904-76890 BOLT, W/WASHER 22815-3210A
014. [01] 94904-76910 BOLT, W/WASHER 22815-3240A
015. [02] 94904-76880 BOLT, W/WASHER 22815-3320A
018. [01] 09028-50030 CAP 22323-1210A
019. [01] 09028-50050 CAP 22323-1430A
021. [01] 09031-00360 VALVE ASSY, OVERFL 22107-1480A
022. [02] 94901-02490 WASHER 22877-1100A
025. [02] 91808-08201 BOLT, FLANGE 22815-3390A
026. [01] 09045-30170 STAY, INJECTION PU 11409-1230B

Include in #3:

09200-04700 as PUMP ASSY, INJECTI

Cross reference number



Part num Firm num Firm Name
09200-04700  22010-8820  PUMP ASSY, INJECTI
22010-8820    HINO PUMP ASSY, INJECTI




Information:

Problem
The fuel lines on certain D10N Tractors; 651E And 657E Tractors; 772B Tractors; 773B Trucks; and 992C Loaders may fail. New fuel line groups can be installed that have a longer service life.
Affected Product
Model & Identification Number
Group 1
D10N (2YD442-1937, 2YD1939, 2YD1942)
651E (89Z170-172, 89Z174-187, 89Z189-270)
657E (90Z183-206; 91Z310-434)
772B (64W178-183)
773B (63W2172, 63W2173, 63W2175, 63W2177-3417, 63W3419; 5SC1-140)
992C (49Z1120-1878)
Group 2
D10N (2YD1938, 2YD1940-1941, 2YD1943-2230)
657E (90Z207-208; 91Z435-460)
772B (64W184-208)
773B (63W3418, 63W3420-3686)
992C (49Z1879-2015)
Group 3
D10N (2YD2231-2406)
657E (90Z209-220)
773B (63W3687-3940)
992C (49Z2016-2125)
Parts Needed
Group 1
1 - 7C6589 Clamp 2 - 7C6591 Clamp 2 - 7C7747 Clamp 1 - 7E3539 Lines Group 1 - 6I0347 Bracket Assembly 1 - 6I0361 Lines Group 6 - 9N3388 Screw-Lock2 - 4P3677 Clamp2 - 4P3678 Clamp8 - 5P4939 Screw A2 - 0L2070 Bolt5 - 0S1590 Bolt3 - 8T1296 Washer2 - 9Y3357 Clamp2 - 688438 Spacer1 - 1029228 Clamp AssemblyGroup 2
1 - 6I0347 Bracket2 - 7C6591 Clamp2 - 7C7747 Clamp2 - 4B4274 Washer2 - 9N3388 Screw1 - 6I4813 Clamp Kit1 - 8T1296 Washer2 - 5P4939 Screw1 - 9Y3357 Clamp1 - 1029228 Clamp AssemblyGroup 3
2 - 5P4939 Screw1 - 9Y3357 Clamp1 - 1029228 Clamp AssemblyAction Required
See the attached procedure.
Service Claim Allowances
Group 1 Affected Product
All Group 2 Affected Product
This is a 1-hour job.
All Group 3 Affected Product
This is a .3-hour job. Submit a supplemental claim for Group 3 if a claim for Group 1 or 2 has already been submitted.
Parts Disposition
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
Attach. (1-Rework Procedure)Rework Procedure
Refer to the following instructions and illustrations. Replace the existing fuel lines and their related parts with the new fuel line groups.
To insure correct clamp locations, install left and right fuel line groups as assembled. However, if clamps are removed, mark locations to insure correct positions when reassembling.
On the 992C Wheel Loader, it is necessary to remove the 6N8322 Air Outlet Tube Assembly to be able to install the right bank fuel line group.
Tighten the fuel line clamp screws to a torque of 2.25 N m (20 lb in). Do not over tighten. Use a 6V6069 Torque Screwdriver or similar tool to tighten the screws.
Group 1 Procedure
1. Clean and paint the new 6I0361 and 7E3539 Fuel Line Groups before proceeding to the job site.A) "Tape Off" the number 3, 5, and 6 fuel lines in the area of the tower clamp. (See Illustration 1 - Part 4 of 5, Section C-C)B) Install 5F2807 Plastic Caps and 2F2990 Plastic Plugs on the ends of the fuel lines.C) Clean and paint the fuel line groups.D) After drying completely, remove the tape. Do not remove the plastic caps and plugs until the fuel lines are ready to be installed on the engine. Transport the fuel line groups in their original boxes.2. Remove all mounting bolts from the fuel line brackets at the aftercooler housing. Except for the tower clamp assembly, new mounting bolts and washers will be used. Keep the washers. The washers may be needed later as spacers.3. A) Disassemble the tower clamp assembly behind the fuel injection pump. The 9Y3356 Clamp and 9Y3359
