09180-01771 TIMER ASSY, AUTOMA Denso Cross




Information timer assy, automa

09180-01771 TIMER ASSY, AUTOMA
Rating:
78
Buy TIMER ASSY, AUTOMA 09180-01771 genuine, new aftermarket engine parts with delivery

Scheme ###:

000. [01] 09180-01770 TIMER ASSY, AUTOMA 22510-1610
000. [01] 09180-01771 TIMER ASSY, AUTOMA 22510-1610
001. [01] 09181-01060 HUB ASSY, TIMER 22516-1380A
002. [01] 09184-00640 FLANGE, TIMER DRIV 22513-1210A
003. [02] 09183-60350 WEIGHT SUB-ASSY, T
003. [02] 09183-60410 WEIGHT SUB-ASSY, T 22514-1410A
004. [01] 09185-60310 COVER, TIMER 22512-1010A
005. [01] 94915-00980 SEAL, OIL 22827-1080A
009. [02] 94904-04471 BOLT, HEXAGON 22815-2390A
010. [02] 09022-20080 WASHER, FUEL PIPE 22847-1330A
011. [04] 09188-40011 SUPPORT, TIMER SPR 22517-1110A
012. [04] 09181-91320 SPRING, TIMER 22515-1820A
013. [ C] 94901-34210 WASHER, PLATE, SK 22885-1690A
013. [ C] 94901-34200 WASHER, PLATE, SK 22885-1680A
013. [ C] 94901-34190 WASHER, PLATE, SK 22885-1670A
013. [ C] 94901-34180 WASHER, PLATE, SK 22885-1660A
014. [02] 09188-30010 BUSHING, TIMER ROL 22521-1020A
015. [02] 09188-20010 ROLLER, TIMER 22522-1010A
016. [02] 94901-15070 WASHER, STEEL PLAT 22867-1120A
017. [01] 09188-50020 SCREW, TIMER OIL S 22845-1120A
018. [01] 09083-90040 PACKING
018. [01] 09083-90020 PACKING 22847-1190A
019. [01] 94914-01560 O-RING 22817-1150A
022. [02] 94904-32070 BOLT, STUD 22857-1100A
022. [02] 94904-32071 BOLT, STUD 22857-1100A
023. [01] 09031-70060 PLUG, SCREW 22845-1060A
025. [02] 94901-20870 WASHER, CAP 22867-1130A
026. [01] 94901-81500 WASHER, COPPER PLA 22847-1120A

Cross reference number



Part num Firm num Firm Name
09180-01771  22510-1610  TIMER ASSY, AUTOMA
