1. Put the fuel injection pump housing and governor in position on tool (A).2. Remove bolt (3) to disconnect the lever and link.3. Remove bolts (2) and remove control linkage (1) from the governor shaft. 4. Remove bolts (4) and plate (5). 5. Remove cover assembly (6), plate (9), and shutoff solenoid (7) from rear governor housing (8).6. Remove the bolts, rear governor housing (8) and gasket from the front governor housing. 7. Remove the governor spring (10) and seat from the guide in the rear governor housing.8. Remove bolt (11) that holds lever assembly (12) to the shaft. There is a key in the (slot) groove of the shaft assembly that must be removed before the shaft assembly is removed from the rear governor housing.9. Remove shaft (13), lever (12), lever (14) and the spacer from the rear governor housing. 10. Remove plug (16) and lip-type seal (15) from the housing. Spacers (17) and (19) are different sizes. Make sure they are assembled in the correct position.11. Use needle nose pliers, and remove the shaft. Remove spacer (17), lever (18) and spacer (19) from the governor housing. 12. Remove two setscrews and locknuts (20) if necessary. 13. Release spring (21) from the notch in the housing. Remove snap ring (22), and remove shaft (23) from the housing. Remove lever (24) and spring (21). 14. Remove lip-type seal (25) from the housing. 15. If necessary, remove the screws, cover (26) and the gasket from the governor housing. 16. Remove high idle cover (27) and three O-ring seals (28). 17. Remove lip-type seal (30), dashpot valve (31), fitting (29), insulator and high idle adjustment (32) from the rear housing. 18. Remove two bolts (33), housing (34) and the gasket from the fuel pump housing. 19. Remove bolts (35), and remove torque control group (36) from the block.
Depending on the different engine applications, torque control groups will vary. Inspect all parts for wear and damage, and make a note of the correct sequence of the parts for assembly purposes.
For additional information, see Specifications For 3406B Diesel Engine Generator set. 20. Remove the bolts and block (37) for the full load stop from the housing. 21. Remove the bolt that holds collar (39) to bolt (40).22. Remove collar (39) and spring (38) from bolt (40). Remove bolt (40) from the block.23. If necessary, remove the stop screw and the power setting screw from collar (39). It may be necessary to turn the piston to remove the servo from the rack.24. Remove the three bolts and governor servo (41) from the fuel injection pump housing. 25. Remove lockring (47), seat (46), spring (45) and sleeve (44) from valve (43). Remove lockring (42) from the groove in the center of valve (43). 26. Remove sleeve (48), valve (49) and piston (50) from the governor servo. Remove O-ring seal (54) from sleeve (48). Remove pin (51) and lever (52) from cylinder (53). 27. Use tool (C) to hold spring (55) under compression so the
